Reebok Competitor Rt 5.1 Treadmill User Manual page 14

14. Set the console assembly on the Left Handrail
(84) and the Right Handrail (85). Be careful not
to pinch any wires. Insert the excess Upright
Wire (not shown) into the Right Handrail.
Attach the console assembly with six #8 x 1/2"
Screws (16), four 1/4" x 1/2" Screws (3), four
5/16" Flat Washers (108), and four 5/16" Star
Washers (13) as shown. Start all ten Screws
and then tighten them.
See step 9. Fully tighten the four 5/16" x 1"
Screws (5) and the two 5/16" x 1 1/4" Bolts (2).
15. Firmly tighten the four 3/8" x 4" Screws (7) and
the two 3/8" x 1 1/2" Screws (8) (only one side is
shown).
Slide the Left Base Cover (86) and the Right
Base Cover (87) downward.
14
85
13
108
3
16
16
15
86
14
Console
Assembly
84
13
108
3
16
16
87
8
7
