USER'S MANUAL
Model No. RCTL69212.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts
are damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-888-936-4266
Mon.–Fri., 7:30 until 16:30 ET
(excluding holidays)
OR E-MAIL US:
customerservice@iconcanada.ca
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
www.reebokfitness.com
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Competitor Rt 6.0 Treadmill and is the answer not in the manual?

Questions and answers

Related Manuals for Reebok Competitor Rt 6.0 Treadmill

Summary of Contents for Reebok Competitor Rt 6.0 Treadmill

  • Page 1 USER’S MANUAL Model No. RCTL69212.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, PLEASE CONTACT OUR CUSTOMER SERVICE DEPARTMENT DIRECTLY. CALL TOLL-FREE: 1-888-936-4266 Mon.–Fri., 7:30 until 16:30 ET (excluding holidays)

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decals may not be shown at actual size. 256836 REEBOK and the Vector Logo are registered trademarks and service marks of Reebok. This product is manufactured and distributed under license from Reebok International.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 20. The heart rate monitor is not a medical 24. Do not change the incline of the treadmill by device. Various factors, including the user’s placing objects under the treadmill. movement, may affect the accuracy of heart rate readings. The heart rate monitor is 25.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new REEBOK reading this manual, please see the front cover of this ® COMPETITOR RT 6.0 treadmill. The COMPETITOR manual. To help us assist you, note the product model RT 6.0 treadmill provides an impressive selection of number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 6. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing the included hex keys materials until you finish all assembly steps.
  • Page 8 2. Identify the Left Upright (75). Have a second person hold the Left Upright near the Base (80). See the inset drawing. Tie the wire tie in the Wire Left Upright (75) securely around the end of the Upright Wire (70). Then, insert the Upright Wire into the lower end of the Left Upright as you pull the other end of the wire tie out of the upper end Wire...
  • Page 9 4. Identify the Left and Right Base Covers (73, 74). Slide the Left and Right Base Covers onto the Left and Right Uprights (75, 76) as shown. Remove the wire tie from the Upright Wire (70). Wire 5. Identify the left handrail assembly (A). If there is a wire in the left Handrail (71), remove and discard it.
  • Page 10 6. Set the Console Base (83) face down on a soft surface to avoid scratching the Console Base. Remove the two screws (C) from the Pulse Crossbar (31). Remove the Pulse Crossbar and discard the screws. Remove the four 5/16" x 5/8" Screws (7) from the Console Frame (87).
  • Page 11 8. IMPORTANT: To avoid damaging the Pulse Crossbar (31), do not use power tools and do not overtighten the #10 x 3/4" Screws (13). Orient the Pulse Crossbar (31) as shown. Attach the Pulse Crossbar to the Handrails (71) with four #10 x 3/4"...
  • Page 12 10. Set the console assembly on the Handrails (71). Make sure that no wires are pinched. Insert Console the excess Upright Wire (70) behind the Console Assembly Frame (87). Attach the console assembly to the brackets on the Handrails (71) with the four 5/16" x 5/8" Screws (7) that you removed in step 6.
  • Page 13 13. Raise the Frame (49) to the position shown. Have a second person hold the Frame until this step is completed. Orient the Storage Latch (51) so that the large barrel and the latch knob are oriented as shown. Attach the lower end of the Storage Latch (51) to the Base (80) with a 3/8"...

  • Page 14: Operation And Adjustment

    OPERATION AND ADJUSTMENT HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same circuit.
  • Page 15 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’s stereo sound system The treadmill console offers an impressive array of while you exercise. features designed to make your workouts more effec- To turn on the power, see page 16.
  • Page 16 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 17 5. Follow your progress with the displays. To measure your heart The matrix—When rate, stand on the foot rails you select the manual mode, the matrix will and hold the display a track that rep- pulse bar with resents 1/4 mile (400 your palms on m).
  • Page 18 HOW TO USE AN ONBOARD WORKOUT The workout will continue in this way until the last segment of the profile flashes in the display and the 1. Insert the key into the console. last segment ends. The walking belt will then slow to a stop.
  • Page 19 HOW TO USE THE WEIGHT LOSS CENTER 4. Follow your progress with the displays. 1. Insert the key into the console. See step 5 on page 17. Note: The calorie goal is an estimate of the See HOW TO TURN ON THE POWER on page 16. number of calories that you will burn during 2.
  • Page 20 HOW TO USE AN IFIT WORKOUT the button, the treadmill will automatically adjust to the first speed and incline settings of the workout. To purchase iFit cards at any time, go to www.iFit.com Hold the handrails and begin walking. or call the telephone number on the front cover of this manual.
  • Page 21 THE INFORMATION MODE An “E” for English miles or an “M” for metric kilome- The console features an information mode that keeps ters will appear in the right track of the total distance that the walking belt has display. Press the Speed moved and the total number of hours that the treadmill increase button to change has been used.

  • Page 22: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to the lowest position before you fold the treadmill. left.

  • Page 23: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by follow- c. Remove the key from the console, and then ing the simple steps below. Find the symptom that reinsert it. applies, and follow the steps listed. If further assis- tance is needed, see the front cover of this manual. d.
  • Page 24 Lower the treadmill. Next, remove the three begin calibrating, press the Stop button again, and indicated #8 x 3/4" Screws (6). Carefully slide the then press the Incline increase or decrease button Motor Hood (57) off. again. When the incline is calibrated, remove the key from the console.
  • Page 25 SYMPTOM: The walking belt is off-center or slips b. If the walking belt slips when walked on, first when walked on remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller a. If the walking belt is off-center, first remove the screws clockwise, 1/4 of a turn.

  • Page 26: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 27: Part List

    PART LIST Model No. RCTL69212.0 R0912A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Ground Screw Frame Spacer 3/8" x 2 1/2" Bolt Frame 3/8" Nut Right Foot Rail 3/8" x 4" Screw Storage Latch 3/8" Star Washer Right Rear Foot #8 x 3/4"...

  • Page 28: Exploded Drawing

    EXPLODED DRAWING A Model No. RCTL69212.0 R0912A...
  • Page 29 EXPLODED DRAWING B Model No. RCTL69212.0 R0912A...
  • Page 30 EXPLODED DRAWING C Model No. RCTL69212.0 R0912A...
  • Page 31 EXPLODED DRAWING D Model No. RCTL69212.0 R0912A...

  • Page 32: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) • the name of the product (see the front cover of this manual) • t he key number and description of the replacement part(s) (see the PART LIST and the EXPLODED DRAWING near the end of this manual) LIMITED WARRANTY ICON of Canada, Inc.
