4. Identify the Right Upright (81). Hold the Right
Upright near the Base (91) as shown.
See the inset drawing. Tie the wire tie in the
Right Upright (81) securely around the end of the
Upright Wire (88). Then, pull the other end of the
wire tie until the Upright Wire is routed through
the Right Upright.
5. Hold the Right Upright (81) against the Base
(91). Be careful not to pinch the Upright Wire
(88). Insert two 3/8" x 4" Screws (7) and a 3/8"
x 1 1/2" Screw (8) with three 3/8" Star Washers
(11) into the Right Upright.
Partially tighten the 3/8" x 4" Screws (7) until
the heads of the Screws touch the Right Upright
(81); do not fully tighten the Screws yet.
Partially tighten the 3/8" x 1 1/2" Screw (8).
4
88
Wire Tie
81
Wire
88
Tie
5
81
10
81
88
91
7
8
11
11
88
91
