Model No. RBTL09500
Serial No.
Find the serial number in the location
shown below. Write the serial number
in the space above for reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through di-
rect assistance from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
¨
¨
USER'S MANUAL
www.workoutwarehouse.com
¨
new products, prizes,
¨
fitness tips, and much more!
Patent Pending
Visit our website at

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTX455 RBTL09500 and is the answer not in the manual?

Questions and answers

Related Manuals for Reebok RTX455 RBTL09500

Summary of Contents for Reebok RTX455 RBTL09500

  • Page 1 Model No. RBTL09500 Serial No. Find the serial number in the location shown below. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, we will guarantee complete satisfaction through di-...

  • Page 2: Table Of Contents

    HOW TO FOLD AND MOVE THE TREADMILL ........

  • Page 3: Important Precautions

    2. Use the treadmill only as described. 3. Place the treadmill on a level surface, with at least eight feet of clearance behind it. Do not place the treadmill on any surface that blocks air openings.
  • Page 4 SAVE THESE INSTRUCTIONS The decals shown below have been placed on your treadmill. If a decal is missing or illegible, please call our Customer Service Department toll-free to order a free replacement decal (see HOW TO ORDER REPLACEMENT PARTS on page 31).

  • Page 5: Before You Begin

    The model number is RBTL09500. The serial number can be found on a decal attached to the treadmill (see the front cover of this manual for the location). Before reading further, please review the drawing below and familiarize yourself with the parts that are labeled.

  • Page 6: Assembly

    This is a normal condition and does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
  • Page 7 Pin. 6. Make sure that all parts are tightened before you use the treadmill. Keep the included allen wrench in a secure place. The allen wrench is used to adjust the walking belt (see page 23). To protect the floor or carpet from damage, place a mat under the treadmill.
  • Page 8 If you purchase the optional chest pulse sensor (see page 19), follow the steps below to install the receiver included with the chest pulse sensor. 1. Make sure that the power cord is unplugged. Remove the indicated Screws (87) from the back of the Console Base (88).

  • Page 9: Treadmill Operation

    READMILL PERATION THE PERFORMANT LUBE WALKING BELT Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. IMPORTANT: Never apply silicone spray or other substances to the walking belt or the walking plat- form. Such substances will deteriorate the walking belt and cause excessive wear.

  • Page 10: Console Diagram

    When the console is in the manual mode, the speed and incline of the treadmill can be changed with a touch of a button. As you exercise, the console will display continuous exercise feedback.

  • Page 11: How To Turn On The Power

    0.5%. The incline range is 1.5% to 10%. Note: After the buttons are pressed, it may take a moment for the treadmill to reach the selected incline setting. Follow your progress with the LED track and the displays.
  • Page 12 When you are finished exercising, remove the key. Step onto the foot pads, press the Stop button, and adjust the incline of the treadmill to the lowest setting. The incline must be at the low- est setting when the treadmill is folded to the storage position or the treadmill will be dam- aged.
  • Page 13 When the program has ended, make sure that the incline of the treadmill is at the lowest set- ting. Next, remove the key from the console and put it in a safe place. Note: If the displays and...
  • Page 14 B. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the LINE OUT jack on your CD player.
  • Page 15 B. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the included adapter. Plug the adapter into the LINE OUT jack on your stereo.
  • Page 16 CONNECT YOUR HOME STEREO on page 15. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the included adapter. Plug the adapter into the AUDIO OUT jack on your VCR.
  • Page 17 CD or video program, press the Stop button or re- move the key and go to step 1 on page 16. Note: If the speed or incline of the treadmill does not change when a ÒchirpÓ is heard: ¥ make sure that the iFIT.com indicator is lit and that the Time/Segment Time display is not flashing.
  • Page 18 Our new internet site at www.iFIT.com allows you to access a selection of programs that interactively con- trol your treadmill to help you achieve your specific ex- ercise goals. In addition, you can play iFIT.com audio and video programs directly from the internet. By adding an optional upgrade module to the console, you can use virtually endless features on our internet site.
  • Page 19 ÒdemoÓ mode. This mode is intended to be used only when a treadmill is displayed in a store. When the console is in the demo mode, the power cord can be plugged in, the key can be removed from the...

  • Page 20: How To Fold And Move The Treadmill

    2. Move your right hand to the position shown and hold the treadmill firmly. Using your left hand, pull the latch knob to the left and hold it. Raise the treadmill until the latch pin is aligned with the hole in the catch. Insert the latch pin into the catch.
  • Page 21 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the pin.

  • Page 22: Trouble-Shooting

    PROBLEM: The power turns off during use SOLUTION: a. Check the circuit breaker located on the treadmill frame near the power cord (see c. above). If the circuit breaker has tripped, wait for five minutes and then press the switch back in.
  • Page 23 4 inches off the walking platform. Be careful to keep the walking belt centered. Plug in the power cord, in- sert the key and run the treadmill for a few minutes. Repeat until the walking belt is properly tightened. c. If the walking belt still slows when walked on, please call our Customer Service Department, toll-free.
  • Page 24 Switch is about 1/8Ó. If necessary, loosen the 1/2Ó Screw (67) and move the Reed Switch slightly. Retighten the Screw. Re-attach the hood, and run the treadmill for a few minutes to check for a correct speed reading. 1/8Ó Top View...

  • Page 25: Reebok University

    EEBOK NIVERSITY Reebok University was launched in 1993 to fulfill a vision to establish a Òuniversity without wallsÓ that develops quality, researched, state-of-the-art fitness programming for the fitness industry throughout the world. Working with the worldÕs best professionals, Reebok University has created a host of original programs, such as Step Reebok ¨...
  • Page 26 Several studies have reported that regular walking at moderate to brisk speeds appears to increase bone density. Specifically, Fradin and his colleagues that 70-year-old subjects who walked at least 30 min- utes per day had higher bone mineral content than subjects who walked less than 30 minutes per day.

  • Page 27: Exercise Guidelines

    For maximum fat burning, adjust the speed and incline of the treadmill until your heart rate is near the middle number in your training zone. Aerobic Exercise If your goal is to strengthen your cardiovascular sys- tem, your exercise must be Òaerobic.Ó...

  • Page 28: Exercise Frequency

    EXERCISE FREQUENCY To maintain or improve your condition, complete three workouts each week, with at least one day of rest be- SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretchÑnever bounce. 1.
  • Page 29 OTES...

  • Page 30: Part List

    ÑM ODEL To locate the parts listed below, refer to the EXPLODED DRAWING attached in the center of this manual. No. Qty. Description Foot Pad (Left) Deck Pad (Left) Foot Pad (Right) Deck Pad (Right) Frame Pivot Bolt Frame Pivot Spacer Magnet Front Roller/Pulley Frame Pivot Nut...

  • Page 31: How To Order Replacement Parts

    ¥ The NAME of the product (REEBOK ¨ RTX 455 treadmill) ¥ The SERIAL NUMBER of the product (see the front cover of this manual) ¥ The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST on page 30).

  • Page 34: Limited Warranty

    IMITED ARRANTY WHAT IS COVEREDÑThe entire REEBOK ¨ RTX 455 (ÒProductÓ) is warranted to be free of all defects in material and workmanship. WHO IS COVEREDÑThe original purchaser or any person receiving the Product as a gift from the original purchaser. HOW LONG IS IT COVEREDÑICON Health &...
