Reebok 610 Bike Manual

English manual

Hide thumbs

Table Of Contents

www.reebokfitness.com

Model No. RBEX06013.0

USER’'S MANUAL

Serial No.

Write the serial number in the space

above for reference.

Serial Number

Decal

ACTIVATE YOUR

WARRANTY

To register your product and

activate your warranty today,

go to www.reebokservice.com/

registration.

CUSTOMER CARE

For service at any time, go to

www.reebokservice.com.

Or call 1-877-994-4999

Mon.––Fri. 6 a.m.––6 p.m. MT

Sat. 8 a.m.––4 p.m. MT

Please do not contact the store.

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Keep this manual

for future reference.

Table of Contents

Need help?

Do you have a question about the 610 Bike and is the answer not in the manual?

Questions and answers

Victor H. Diaz

July 9, 2025

I have lost the original power adapter for my Reebok 610 Bike. What are the characteristics (for a 110 input outlet) of a Power Adapter or What would be the best replacement for it?

Summary of Contents for Reebok 610 Bike

Page 1 www.reebokfitness.com Model No. RBEX06013.0 USER’’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.reebokservice.com/ registration. CUSTOMER CARE For service at any time, go to www.reebokservice.com.
Page 2: Table Of Contents
Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. REEBOK and the Vector Logo are registered trademarks and service marks of Reebok. This product is manufactured and distributed under license from Reebok International.
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
Page 5 STANDARD SERVICE PLANS...
Page 6: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the revolutionary REEBOK ® manual. To help us assist you, note the product model 610 exercise bike. The 610 exercise bike provides an number and serial number before contacting us. The impressive selection of features designed to make your model number and the location of the serial number workouts at home more effective and enjoyable.
Page 7: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.
Page 8: Assembly
ASSEMBLY •• To hire an authorized service technician to •• To identify small parts, see page 7. assemble this product, call 1-800-445-2480. •• In addition to the included tool(s), assembly •• Assembly requires two persons. requires the following tools: one Phillips screwdriver ••...
Page 9 3. While a second person lifts the rear of the Frame (1), attach the Rear Stabilizer (16) to the Frame with two M10 x 105mm Screws (65). 4. Orient the Seat Frame (52) as shown. Attach the Seat Frame (52) to the Seat Carriage (41) with four M8 x 16mm Screws (69).
Page 10 5. Tip: Avoid damaging the wires inside the Seat Handlebar (11) during this step. Attach the Seat Handlebar (11) to the Seat Frame (52) with two M8 x 65mm Bolts (70) and two M8 Locknuts (86). 6. Plug the Seat Pulse Wire (10) into the receptacle in the Right Rear Shield (97).
Page 11 7. Attach the Seat (9) to the Seat Frame (52) with four M6 x 38mm Screws (25) and four M6 Washers (88) (only two Screws and two Washers are shown). 8. Attach the Backrest (8) to the Seat Frame (52) with four M6 x 38mm Screws (25) and four M6 Washers (88).
Page 12 9. Attach the Backrest Cover (103) to the Backrest (8) with two M6 x 18mm Screws (75). 10. Orient the Upright (2) and the Top Shield (44) as shown. Slide the Top Shield upward onto the Wire Ties Upright. Have a second person hold the Upright (2) and the Top Shield (44) near the Frame (1) until Wire step 11.
Page 13 11. Tip: Avoid pinching the wires. Slide the Upright (2) onto the Frame (1). Avoid pinching the wires Attach the Upright (2) with four M10 x 16mm Screws (67) and four M10 Split Washers (100). Tip: Tighten the two Screws in the front of the Upright, and then tighten the other two Screws.
Page 14 13. Identify and orient the Rear Upright Cover (57) as shown. Attach the Rear Upright Cover (57) to the Upright (2) with an M4 x 16mm Screw (77). 14. Untie and discard the wire ties on the Main Wire (43), the Frame Pulse Wire (42), and the Receiver Wire (40).
Page 15 16. Identify the Right Pedal (21). Using an adjustable wrench, firmly tighten the Right Pedal (21) clockwise into the Right Crank Strap Arm (23). Post Firmly tighten the Left Pedal (not shown) counterclockwise into the Left Crank Arm (not shown). If necessary, press the right strap onto the post on the Right Pedal (21).
Page 16: The Chest Heart Rate Monitor
THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR •• Do not expose the heart rate monitor to direct sun- light for extended periods of time; do not expose it to The heart rate temperatures above 122° F (50° C) or below 14° F monitor consists of (-10°...
Page 17: How To Use The Exercise Bike
HOW TO USE THE EXERCISE BIKE HOW TO PLUG IN THE POWER ADAPTER HOW TO LEVEL THE EXERCISE BIKE IMPORTANT: If the exercise bike has been exposed If the exercise bike to cold temperatures, allow it to warm to room rocks slightly on temperature before plugging in the power adapter.
Page 18 CONSOLE DIAGRAM FEATURES OF THE CONSOLE The advanced console offers an array of features designed to make your workouts more effective and enjoyable. When you use the manual mode of the console, you can change the resistance of the pedals with the touch of a button.
Page 19 HOW TO USE THE MANUAL MODE Distance (Dist.)——This display mode will show the distance that you have pedaled in miles or 1. Begin pedaling or press any button on the kilometers. console to turn on the console. Pulse——This display mode will show your heart rate When you turn on the console, the display will turn when you use the handgrip heart rate monitor or on.
Page 20 Press the Home button to return to the default rate will be shown. For the most accurate heart menu (see HOW TO CHANGE CONSOLE rate reading, hold the contacts for at least 15 SETTINGS on page 25 to set the default menu). seconds.
Page 21 HOW TO USE AN ONBOARD WORKOUT the next segment, the resistance level and/or target speed will appear in the display for a few seconds 1. Begin pedaling or press any button on the to alert you. The resistance of the pedals will then console to turn on the console.
Page 22 HOW TO USE A SET-A-GOAL WORKOUT Note: The calorie goal is an estimate of the number of calories that you will burn during 1. Begin pedaling or press any button on the the workout. The actual number of calories that console to turn on the console.
Page 23 HOW TO USE AN IFIT WORKOUT To compete in a race that you have previously scheduled, press the Compete button. You must have an iFit module to use an iFit workout. To re-run a recent iFit workout from your sched- To purchase an iFit module at any time, go to ule, first press the Track button.
Page 24 6. Follow your progress with the display. 7. Measure your heart rate if desired. See step 4 on page 19. See step 5 on page 20. The My Trail tab will show a map of the trail you are 8. Turn on the fan if desired. walking or running or it will show a track and the number of laps you complete.
Page 25 HOW TO CHANGE CONSOLE SETTINGS If no module is connected, the display will show the words NO IFIT MODULE. If no module is con- The console features a user mode that allows you to nected, go to step 10. view usage information, select a unit of measurement, and adjust the contrast level of the display.
Page 26: Fcc Information
FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 27: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the exercise bike regu- Locate the Reed Switch (46). Rotate the Pulley (29) larly. Replace any worn parts immediately. until a Pulley Magnet (30) is aligned with the Reed Switch. Loosen, but do not remove, the indicated M4 To clean the exercise bike, use a damp cloth and a x 16mm Screw (77).
Page 28 HOW TO ADJUST THE DRIVE BELT Loosen the M6 x 20mm Hex Screw (84). Tighten the M10 x 50mm Hex Screw (83) until the Drive Belt (47) If the pedals slip while you are pedaling, even while the is tight. When the Drive Belt is tight, tighten the M6 x resistance is adjusted to the highest setting, the drive 20mm Hex Screw.
Page 29: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
Page 30 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch; never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
Page 31 NOTES...
Page 32: Part List
PART LIST Model No. RBEX06013.0 R0113A Key No. Qty. Description Key No. Qty. Description Frame Drive Belt Upright Rear Stabilizer Cover Front Stabilizer Cover Handlebar Grip Console Flange Screw Rail Power Adapter Adjustment Bar Seat Frame Left Handlebar Resistance Rod Assembly Backrest Small Snap Ring Seat...
Page 33 Key No. Qty. Description Key No. Qty. Description M6 Bright Locknut M10 Split Washer M5 Washer M10 Locknut Steel Washer Backrest Cover M6 Split Washer Heart Rate Monitor/Strap Right Rear Shield Receiver Wire Left Rear Shield –– Assembly Tool Tree Fastener ––...
Page 34: Exploded Drawing
EXPLODED DRAWING A Model No. RBEX06013.0 R0113A...
Page 35 EXPLODED DRAWING B Model No. RBEX06013.0 R0113A...
Page 36: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: •• the model number and serial number of the product (see the front cover of this manual) ••...
