MZ-100 Four Channel DSP Zone Amplifier
Introduction:
The MZ-100 is a 4 channel audio amplifier capable of delivering up to 25W RMS
per channel. The Digital Signal Processor (DSP) constantly monitors the output
signal and optimizes it for maximum fidelity. The onboard microcontroller
communicates with external control panels and poly-planar source units to make
a complete networked audio solution. The compact, water resistant design
allows for flexible mounting possibilities, and makes it simple to expand the audio
system capabilities on any vessel or land based application
Uses:
To add additional loudspeakers to a current audio system
To provide amplification for a separate audio zone
As a stand-alone system amplifier for any audio source
Features:
Custom Equalization for optimized sound
Digital Signal Optimization eliminates distortion and maximizes output
Waterproof, corrosion resistant enclosure
Connect up to 4 loudspeakers and 2 subwoofers
Supports Intercom feature
Supports wireless and wired remote control
Expandable for multi-zone use
Includes optional rotary volume knob
PO Box 409 • Hanover, MD 21076 • Tel (410) 761-4000 • www.polyplanar.com
- 1 -
Rev 2.1
Advertisement
Related Manuals for poly-planar MZ-100
Summary of Contents for poly-planar MZ-100
- Page 1 MZ-100 Four Channel DSP Zone Amplifier Introduction: The MZ-100 is a 4 channel audio amplifier capable of delivering up to 25W RMS per channel. The Digital Signal Processor (DSP) constantly monitors the output signal and optimizes it for maximum fidelity. The onboard microcontroller communicates with external control panels and poly-planar source units to make a complete networked audio solution.
- Page 2 MZ100 Amp when turned all the way down. 6) Audio System Connection: This plug is used for hooking the MZ-100 to an extended poly-planar audio network using an RT20 System Router. 7) Control Panel Connection: This plug is used for hooking the MZ-100 to poly-planar displays and control panels.
- Page 3 Controls, Inputs & Outputs (Continued) Right Panel View Power and Speaker Connections: (Refer to diagram on page 4) 7) POWER The Black and Red wires should be connected directly to the 12 Volt battery, power supply or main fuse block using heavy gauge wire (AWG #14 or larger).
- Page 4 Speaker Outputs Battery + Battery - Wire Color Description Battery (+), 12Vdc Battery ( - ), Ground Black Blue Remote Turn On, 12Vdc = ON White Left Channel (+) Left Channel ( - ) White/Black Gray Right Channel (+) Right Channel ( - ) Gray/Black Green Sub 1 Channel (+)
- Page 5 The MZ100 DSP Amp has the unique ability to accomplish this across the full audio spectrum. The chart below shows settings for the broad range of Poly Planar Speakers in Marine and Spa applications. Adding a Subwoofer will further enhance your audio experience.
- Page 6 Connecting the MZ-100 Input (Fixed Gain): For operation without the optional external volume control, connect the amplifier inputs to the VARIABLE LINE OUT of your receiver using shielded RCA patch cables. In this case the amplifier volume will be determined by the volume setting of the source component.
- Page 7 The MZ-100 can be controlled by the RD-44 control panel. Using an extension cable (not shown) the panel can be up to 60 feet away from the amplifier. Plug the RD-44 or its extension cable into the CONTROL PANEL plug on the MZ-100. Be sure to tighten the waterproof connectors.
- Page 8 12V (Red wire). Connecting the MZ-100 to a multi-zone audio system: The MZ-100 is designed to be used in a multi-zone audio system. When combined with the MRD-70 CD/MP3 radio, RD-44 control panel and the RT-20 router, up to 4 independent zones can share sources and have communication through the RD-44’s intercom.
- Page 9 Example of a 4 zone audio system. PO Box 409 • Hanover, MD 21076 • Tel (410) 761-4000 • www.polyplanar.com - 9 -...
- Page 10 Specifications: Speaker Impedance ………………………… 2 – 8 ohm Output Power (2 ohm load) ………………… 25 W RMS per channel (4 ohm load) ………………… 15 W RMS per channel Frequency Response ………………………. 20 Hz – 20 kHz Operating Voltage ………………….. ……… 13.8V (10V – 16V) DC Idle Current (no signal) ………………………...
-
Page 11: Warranty
Troubleshooting: No Audio, Green LED Off 1. Make sure the Blue remote wired is switched to 12 volts. 2. Make sure the inline fuse is not blown. (Red wire) 3. Check that power wires are getting 12 volts from battery. No Audio, Green LED On 1. - Page 12 78.5mm 3.1 in Drill 3mm (0.115 in) hole for included tapping screw 107mm 4.21 in 156mm 6.14 in 168.5mm 6.63 in 78.5mm 3.1 in...
