poly-planar MZ-100 User Manual

78.5mm
3.1 in
Drill 3mm (0.115 in)
hole for included
tapping screw
107mm
4.21 in
156mm
6.14 in
78.5mm
3.1 in
MZ-100 Four Channel DSP Zone Amplifier

Introduction:

The MZ-100 is a 4 channel audio amplifier capable of delivering up to 25W RMS
per channel. The Digital Signal Processor (DSP) constantly monitors the output
signal and optimizes it for maximum fidelity. The onboard microcontroller
communicates with external control panels and poly-planar source units to make
a complete networked audio solution. The compact, water resistant design
allows for flexible mounting possibilities, and makes it simple to expand the audio
system capabilities on any vessel or land based application

Uses:

•
To add additional loudspeakers to a current audio system
•
To provide amplification for a separate audio zone
168.5mm
•
6.63 in
As a stand-alone system amplifier for any audio source

Features:

•
Custom Equalization for optimized sound
•
Digital Signal Optimization eliminates distortion and maximizes output
•
Waterproof, corrosion resistant enclosure
•
Connect up to 4 loudspeakers and 2 subwoofers
•
Supports Intercom feature
•
Supports wireless and wired remote control
•
Expandable for multi-zone use
•
Includes optional rotary volume knob
Poly Planar Group LLC - 520 McCormick Dr. - Glen Burnie MD 21061 - 410-761-4000
12
Rev 2.1
- 1 -
