poly-planar ME-400 Installation Instructions Manual

Poly-Planar Warranty
Poly-Planar products are warranted to be free of defects in materials and workmanship
for a period of two years. No finished goods or parts may be returned for repair or
replacement without Poly-Planar authorization. Goods received for any reason other
than out-of-box defect will be returned freight collect. To qualify as an out-of-box
defect, the product must be found defective within 30 days of retail sale. Please call
Poly-Planar Customer Service for authorization, which will take the form of an RMA
(Return Merchandise Authorization) number. Warranty is subject to proper installation
and operation within published specifications. Poly-Planar will repair or replace, at its
discretion, any unit returned to its factory and determined to be defective. Poly-Planar
is not liable for consequential damages.
POLY-PLANAR • PO Box 409 • Hanover, MD 21076
12
Tel: (410) 761-4000 • Fax: (410) 761-6274 • www.polyplanar.com
ME-400 Marine Amplifier
Introduction
The ME-400 four channel, marine-grade amplifier provides 400 watts of crisp, clean
audio power. The amplifier can be easily configured to enhance your listening pleasure.
Both crossover circuits and high pass and low pass filters are fully adjustable so you can
power your subwoofer as well as your standard speakers. Gold plated connections
resist corrosion. Rubber mounting feet isolate vibration. Efficient heat sink design
ensures uninterrupted operation. Built from the ground up to withstand the rigors of
the marine environment, the ME-400 will be an outstanding addition to your vessel's
audio system.
ME-400 Features
• Circuit board and connectors optimized for marine use
• Mosfet PWM power supply
• 2 ohm stable stereo outputs
• Bridgeable outputs
• Variable input level controls for each pair of channels
• Variable High-pass, Low-pass and All-pass crossover.
• Variable Bass Boost circuit
• Thermal and overload protection circuitry
• Gold-plated RCA jacks and terminals
• Rubber isolation mounting feet
PLEASE READ THIS MANUAL BEFORE
INSTALLATION AND USING AMPLIFIER
POLY-PLANAR • PO Box 409 • Hanover, MD 21076
Tel: (410) 761-4000 • Fax: (410) 761-6274 • www.polyplanar.com
1
