Massive Audio Rebel 15 Quick Manual Specifications

1 5
Basket: Custom Stamp Steel Basket W/ Sandblast Powder Coat Finish
Gasket: EVA Gasket to Secure The Surround Bonding
Magnet: Single 65oz High Intensity Grade Ferrite Ring
Surround: Wave Roll Shaped Foam Surround
Voice Coil: 2" Dual 4 Ohm CCAW Voice Coil On Alum. Former W/ Reinforced Neck Joint
Dust Cap: Vacuum V-Shape Dust Cap W/ Woven Texture
Transducer Parameter
Wiring
NomZ
Sd
Revc
Levc
BL
Vas
Cms
Mms
Fo
Qms
Qes
Qts
no
SPL@1W
SPL@2.83V
Xmax/Over Hang
Xmech/Suspension
Watt@RMS
Watt@PEAK
Physical Measurements
Frame Diameter
Mounting Hole Diameter
Mounting Depth 177.5 mm
Massive Audio, Inc. P.O. Box 252004 Los angeles, CA 90025 USA www.massiveaudio.com
Quick Guide Specifications

Design Features

Motor: FEMM Engineered Motor Plates W/ White Zinc Finish
Cone: Vacuum Massive Logo Cone W/ Sandblast Black Painted Surface Finish
Spider: Dual Progressive Roll Poly-Cotton Spider W/ Woven Round Tinsel Lead Wire
Parallel
4 / 4
Ohm
sqM 0.085
1.7
Ohm
mH
10.97
TxM
Liter 183.2
uM/N 178.5
Grams 187.6
Hz 27.5
0.458
0.42
0.802
%
dB 91.24
dB 97.97
mm 13.25
mm 20
Watts 500
Watts 1000
Metric
Dispalcement 1.275L
388 mm
350 mm
Overall Depth 195.4 mm
REBEL 15
Series
4 + 4
0.085
6.8
1 1
19.96
183.2
178.5
187.6
27.5
5 5
0.553
0.498
0.664
90.42
91.13
13.25
20
500
1000
Standard
0.045 ft3
15.28"
13.78"
6.99"
7.69"
MAX
R15
Dual 4 Ohms
