Massive Audio V104 Specification

General Features

* 10 mm Top Plate for Additional Motor Force.
* High Energry Strontium Magnet Structure
* Dual Impedance Black Anodized Aluminum Former
* Poly Cotton Spider With Woven Round Tinsel Leads
* Mica Filled Polyproplin Cone
* Custom Tooled N-Rolled Tall/Narrow Foam Edge
* V-Shape Weaved Glassfiber Center Dustcap

Specifications

CONFIGURATION V 104
Voice Coil Dual 4 Ohm
Fs 35
Hz
Qms 6.7
Vas 47.0
liters
Cms 254.9
um/N
Mms 80.0
g
Rms 2.7
Kg/s
Xmax 10.0
mm
Xmech 14.0
mm
Dia. 215.0
mm
Sd 0.036
sq.m
Vd 0.360
liters
ELECTRICAL Individual Parallel
Qes
1.50 0.68
Re
4 2
Ohms
Le
1.1 0.8
mH
6.9
BL 7.20
Tm
Pe 300 600
Watts
ELECTROMECANICAL Individual Parallel
Qts
1.20 0.61
no
0.129 0.30
%
1-W-SPL
84 86
dB
2.8V SPL
86 88
dB
E 8
Mounting Depth (A) Mounting Depth (A) 4.56 In.
Mounting Diamter (B)
10.08 In.
Mounting cut diameter (C) 9.06 In.
Net weight (Lb)
Displacement (ft3) 0.0901
V 104
Sealed Volume (Ft3)
0.75
F3 (HZ)
46
Hight (H) 12
Width (W) 12
Depth (D) 14
Ported Volume (Ft3) 1
Hight (H)
12
Width (W)
17
Depth (D) 14
Tuning (Hz) 44
F3 (Hz)
38
Port Diameter (in)
3
Port length (in) 8
Number of Ports 1
* All measurments are rounded for ease of fabrication.
* All external dimentions using 3/4" MDF.
* All measuremnts are in inches.
E 8
V 102
Dual 2 Ohm
34
4.3
51.2
273.6
78.9
3.979
10.0
14.0
215.0
0.036
0.363
Series Individual Parallel Series Individual Parallel
0.74 0.47 0.31 0.32
8 2 1 4
3.1 0.6 0.5 1.9
8.4
13.30 7.40 14.70
600 300 600 600
Series Individual Parallel Series Individual Parallel
0.67 0.427 0.29 0.30
0.32 0.41 0.64 0.63
82 86 88 84
82 88 90 86
P.O. Box 252004 Los Angeles, CA 90025 U.S.A.
www.massiveaudio.com
V10 V12
5.12 In.
12.2 In.
10.94 In.
9.1 9.8
0.952
Single Sub Enclosure
V 102 V 124 V 122
0.75 1 1
46 45 45
12 14 14
12 14 14
14 14 14
1 1.5 1.5
12 14 14
17 16 16
14 17.5 17.5
44 43 43
38 36 36
3 4 4
8 8 8
1 1 1
P.O. Box 252004 Los Angeles, CA 90025 U.S.A.
www.massiveaudio.com
Subwoofers
V 124 V 122
Dual 4 Ohm Dual 2 Ohm
32 34
6.7 5.6
90.0 72.2
208.30 167.10
114.0 130.0
3.56 5.002
12.0 12.0
18.0 15.0
265.0 265.0
0.055 0.055
0.661 0.661
Series Individual Parallel
2.10 0.93 0.92 1.67 0.75
4 2 8 2 1
1.1 0.8 3.1 0.6 0.5
6.70 7.50 14.20 5.80 6.00
300 600 600 300 600
Series Individual Parallel
1.58 0.80 0.80 1.29 0.66
0.14 0.27 0.32 0.16 0.37
84 86 83 86 89
86 89 83 89 92
For More Customized Box Volume Specifications
Please visit www.massiveaudio.com
Dual Sub Enclosure
V 104 V 102 V 124
1.5 1.5 2
46 46 45
11 11 14
21 21 25
12 12 15
2 2 3
11 11 14
25 25 30
18 18 18
44 44 42
37 37 34
3 3 4
8 8 8
2 2 2
H
ø310
ø134
ø278
Series
0.79
ø256
4
1.9
10.40
600
Series
0.68
0.46
84
ø134
86
ø230
B
C
V 122
2
45
14
25
15
H
3
14
30
18
W
42
34
4
8
2
W
A
D
D
