Massive Audio KILO 104 Specification

General Features

* Heavy Duty Diamond Polished Cast Aluminum Basket
* High Energry Double Stacked 150 Oz. Strontium Magnet Structure
* Dual Impedance Black Anodized Former With EISV Voice Coil
* Poly Cotton Spider With Woven Round Tinsel Leads
* Semi Pressed Paper Cone
* Custom Tooled Tall/Narrow Foam Edge
* V-Shape Weaved Glassfiber Center Dustcap
* Custom Tooled Rubber Gasket
* Custom Tooled Bottom Plate To Insure Noise Free Ventilation

Specifications

CONFIGURATION KILO 104
Voice Coil DuaI 4 Ohm
Hz
FS 41.57
Qms 2.33
liters
Vas 18.54
Cms um/N 99.05
g
Mms 147.95
Rms Kg/s 16.56
mm
Xmax 10.80
Xmech mm 16.20
mm
Dia. 215.00
Sd sq.m 0.040
liters
Vd 0.39
ELECTRICAL Individual Parallel
Qes 1.08 0.55
Re ohms 3.60 1.80
Le mH 0.66 0.68
BL Tm 11.34 11.46
Pe Watts 250 500
ELECTROMECANICAL Individual Parallel
Qts 0.739 0.433
no % 0.119 0.222
1-W-SPL dB 82.8 85.5
2.8V SPL dB 86.4 92.0
1000
PEAK WATTS
E 8
KILO 10
Mounting Depth (A)
5.7 In.
Mounting Diamter (B)
11.0 In.
Mounting cut diameter (C)
9.4 In.
Net weight (Lb)
Displacement (ft3) 0.0963

Recommended Enclosures:

KILO 104

SEALED

Small
Volume (cub. ft) 0.88
Internal Dimensions (in.)
(width x Height x Depth) 14x12x9
F3 Hz 53
Qtc 0.91

PORTED

Small
Volume (cub ft.) 1.2
Internal Volume ( W x H x D) 18x13x9.5 20x14x9.25
Fb Hz 40

Cabin Gain dB/Hz

7@40
Port round (D x L) 3x8
Port Area sq. in. 11.75
Dual Sub Box Ported
Volume (cub ft.) 2.4
Internal Volume ( W x H x D) 26x18x8.75 26x18x11.25
Port (1) Sq.area in. 19.63
Port Length 10
Fb Hz 40
The port may have to be placed along the back wall facing the side. Place a brace between the subs about 4 inches wide on the inside.
Make sure that the end of the port "inside the box" is at least the same distance away from the back wall as the port diameter. If port is 4" round = 4.5" from wall

Attention:

*Box sizes account for driver and port displacement
*For higher SPL shortning the port length 3 in. will rise frequency +/- 5 Hz
*Box specifications are internal. for external dimensions add the width of the box material to these dimensions.
*A square port (slot) is prefered in high power applications for less vent noise.
*Port area = width x height
*For dual speaker, double the volume and the number of ports but keep the same length.
*If possible use a divided box.
*If a commom chamber box is to be used, internal bracing is highly recommended
*Please contact Massive Audio for custom applications.
KILO 124
DuaI 4 Ohm
40.54
5.494
35.43
98.7
156.1
7.239
10.80
16.200
253
0.0503
0.543
Series Individual Parallel Series
0.61 1.689 0.834 0.879
7.20 3.60 1.80 7.20
3.10 0.678 0.699 3.317
21.74 9.207 9.355 18.1
500 250 500 500
Series Individual Parallel Series
0.496 1.292 0.708 0.76
0.200 0.135 0.263 0.256
85.0 83.44 86.35 86.24
85.6 86.92 92.82 86.69
P.O. Box 252004 Los Angeles, CA 90025 U.S.A.
www.massiveaudio.com
KILO 12
6.1 In.
12.6 In.
11.0 In.
16.0 16.5
0.143
KILO 124
Large Small Large
1.25 0.98 1.85
18x13x9.5 14x14x 8.75 20x14x11.5
50 50 44
0.78 1.1 0.88
Large Small Large
1.45 1.5 1.95
20x14x9.25 20x14x12
37 43 39
9@38 7@65 6@40
3x8 4x8.25 4x7.5
11.75 12.56 12.56
3 3.2 3.9
28x14x13.75 28x16.75x14
19.63 28.27 28.27
9.5 9.5 8.25
37 43 39
Subwoofers
KILO 122
DuaI 2 Ohm
40.43
4.076
35.29
98.3
157.6
9.825
9.00
13.50
253.00
0.0503
0.453
Individual Parallel Series
1.15 0.586 0.646
1.8 0.9 3.6
0.419 0.413 1.839
7.916 8.631 15.63
250 500 500
Individual Parallel Series
0.897 0.502 0.573
0.196 0.313 0.316
85.06 87.1 87.15
91.55 96.59 90.61
For More Customized Box Volume Specifications
Please visit www.massiveaudio.com
KILO 122
Small Large
0.98 1.2
14x14x8.75 18x13x 9.5
62 58
0.8 0.707
Small Large
1.4 1.85
20x14x9.0 24x15x9.25
42 35
6@45 7@38
4x10 4x13
12.56 12.56
2.8 3.7
28x14x12.25 28x14x12.25
28.27 28.27
12.5 13.25
42 35
H
11.0 In.
9.4 In.
KILO 10
12.6 In.
11.0 In.
KILO 12
B
C
H
D
W
W
A
D
