PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M8 Split Washer
M8 Locknut
M8 x 23mm
M10 Split
Wave Washer
(131)–6
(105)–6
Washer (128)–4
x 1.5mm Washer
(118)–2
(126)–10
M4 x 16mm
M4 x 25mm
M6 x 12mm
M8 x 16mm
Screw (93)–16
Screw (132)–2
Screw (111)–2
Screw (102)–18
M8 x 45mm Button Bolt (104)–6
M8 x 50mm
Button Screw (123)–6
M10 x 120mm Screw (100)–4
5
