- Page 1 M50SL / M75SL Parts Manual American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com www.amdry.com ADC Part No. 450289-2...
-
Page 2: For Your Safety
Retain This Manual In A Safe Place For Future Reference This product embodies advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble free operation. ONLY properly licensed technicians should service this equipment. OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with the dryer. - Page 3 Replacement parts can be obtained from your reseller or the ADC factory. When ordering replacement parts from the factory, you can FAX your order to ADC at (508) 678-9447 or telephone your order directly to the ADC Parts Department at (508) 678-9000. Please specify the dryer model number and serial number in addition to the description and part number, so that your order is processed accurately and promptly.
-
Page 4: Parts Diagram
Parts Diagram American Dryer Corporation 450289 - 2... -
Page 5: Parts List
851376 M75SL Galvanized Tumbler 102410 M50SL / M75SL 15 Rib Drive Belt (for all M75SL and M50SL models mfd. as of February 3, 2006) 102409 M50SL 12 Rib Drive Belt (for M50SL models mfd. prior to February 3, 2006) 887190... - Page 6 Parts Diagram American Dryer Corporation 450289 - 2...
- Page 7 Illus. No. Part No. Qty. Description 851522 Phase 8 Coin Control Panel Assembly Complete 851518 Phase 8 Non-Coin Control Panel Assembly Complete 851521 Phase 8 Coin Control Panel (panel Only) 851517 Phase 8 Non-Coin Control Panel (panel Only) 185121* Lower Panel (painted) 185122 Lower Panel (stainless steel) 160040...
- Page 8 Parts Diagram American Dryer Corporation 450289 - 2...
- Page 9 Radiant Heat Sensor 350217 Burner Funnel Top Lip Bracket 128910 Hot Surface Ignitor 851386 M50SL 60 Hz Natural Gas Dual Burner Assembly 851389 M50SL 50 Hz Natural Gas Dual Burner Assembly 851390 M75SL 60 Hz Natural Gas Dual Burner Assembly 851391...
- Page 10 Parts Diagram American Dryer Corporation 450289 - 2...
- Page 11 M75SL Motor Assembly with Mount (for all 50 Hz models) 851570 M50SL Motor Assembly with Mount (for 60 Hz models mfd. as of February 3, 2006) 851545 M50SL Motor Assembly with Mount (for 50 Hz models mfd. as of February 3, 2006) 851286 M50SL Motor Assembly with Mount (for 60 Hz models mfd.
- Page 12 Parts Diagram American Dryer Corporation 450289 - 2...
- Page 13 Illus. No. Part No. Qty. Description 851395 M50SL Electric Oven Assembly 200-415v 851396 M75SL Electric Oven Assembly 200-415v 119996 M50SL 16 kW Element 119997 M75SL 22 kW Element 350230 Electric Oven Support Bracket 152014 Free Spin Wash Nut 131322 208/240v 30A Contactor 50/60 Hz...
- Page 14 Parts Diagram American Dryer Corporation 450289 - 2...
- Page 15 Gas and Electric Rear Tumbler Support Panel Assembly 851401 Steam Rear Tumbler Support Assembly with Steam Coil 851372 M50SL / M75SL Rear Wheel Bracket Assembly 851562 M50SL / M75SL Rear Wheel Bracket Assembly for Banded 180060 3-1/2” Wheel ONLY 121010 Terminal Lug 851258...
- Page 16 ADC Part No. 450289 2 - 04/28/08 - 0...
