Getting Acquainted with the Meter

To become familiar with the features and functions of the
meter, study the following figures and tables.
Figure 2 and Table 2 describe the input/output jacks.
Figure 3 and Table 3 describe the input functions of
the first six rotary function switch positions.
6
A mA
1
2
Figure 2. Input/Output Jacks
Figure 4 and Tables 4 and 5 describe the output
functions of the last three rotary function switch
positions.
Figure 5 and Table 6 describe the functions of the
pushbuttons.
Figure 6 and Table 7 explain what all the elements of
the display indicate.
V
COM
3
4
anw001f.eps
