Ikegami ISD-F11 Pixim Seawolf Specifications

ISD-F11
Pixim Seawolf Camera
0.1Lux
[ Features ]
P IXIM 1/3" High Sensitivity Digital Sensor
H igh Resolution : 690TVL Effective
M in. Illumination : 0.1Lux
F ixed Lens (2.5 mm)
Sens-Up (2x~32x)
Powerful WDR (Wide Dynamic Range)
Digital Day & Night for surveillance 24 hours
Private Masking (12 Zones)
Motion Detection
OSD for user convenience
Digital Zoom (4x)
Aluminum & Poly-Carbonated Material Housing (IP66)
[ Dimensions ]
57.0
IP66
[ Specifications ]
Power Consumption
Image Sensor
Effective Pixels
Dynamic Range
Horizontal Resolution
Min. Illumination
Day & Night
White Balance
WB Range
Shutter Speed
Sens-up
Privacy Masking
AGC
Image Flip
Camera ID
S/N Ratio
Video Output
OSD
Sync. System
Operating Humidity
Operating Temp.
ISD-F11
(unit:mm)
ISD-F11
I
ITEM NTSC
12VDC Only (Max.150mA)
PIXIM 1/3" High Sensitivity Digital Sensor
758(H) x 540(V)
120dB(Max), 102dB(Typical)
690TVL Effective
Auto / Color / B/W
Auto / AWB / Indoor / Outdoor / Manual
2000 K~11,000 K
up to 1/30, 720 sec
Auto / Off (Selectable x2 ~ x32)
Low / Auto / High / Off
Horizontal and Vertical
More than 50dB
Composite video output 75 ohm terminated
Internal / Line Lock
30% ~ 90% RH
10 C to 50
MINI
VALDAL DOME
PAL
0.1Lux
12 Zones
On / Off
Builtin
