Ikegami ISD-M71 Nightwolf Product Features And Specification

ISD-M71 Nightwolf
WDR Digital Sensor Bullet Camera
690
HTVL
Effective
0Lux
[ Features ]
PIXIM 1/3" High Sensitivity Digital Sensor
High Resolution : 690TVL Effective (Color), 800TVL Effective (B/W)
Min. Illumination : 0Lux with IR LED
Sens-Up (2x~64x)
Vari-Focal Auto Iris Lens (2.8~10mm/F1.2, 5~50mm/F1.4)
Powerful WDR (Wide Dynamic Range)
DNR for saving storage
Private Masking (12 Zones)
Motion Detection
OSD remote control via RS-485 (optional)
OSD control by coaxial cable via pelco coaxitron
Digital Zoom (8x)
Focus, Viewing Angle & OSD menu adjustment externally
Photo Sensor & IR LED (30pcs)
Viewable Distance at Night : 25m
VBS-EXTRA for connection to LCD monitor
Weatherproof (IP67)
Heater optional (-40 C ~ +50 C)
UTC controller optional
[ Dimensions ]
100
IP67
162.5
146.4
(241.5)
(unit:mm)
ISD-M71
(Nightwolf)
[ Specifications ]
ITEM
Power Consumption
24VAC/12VDC (Max.400mA/Max.650mA)
Image Sensor
PIXIM 1/3" High Sensitivity Digital Sensor
Effective Pixels
Dynamic Range
Horizontal Resolution
690TVL Effective(Color), 800TVL Effective (B/W)
Min. Illumination
Day & Night
White Balance
Auto / AWB / Indoor / Outdoor / Manual
WB Range
Shutter Speed
Sens-up
Auto / Off (Selectable x2 ~ x64)
DNR
Privacy Masking
Remote Control
AGC
Image Flip
Camera ID
S/N Ratio
Video Output
Composite video output 75ohm terminated
OSD
Sync. System
Operating Humidity
Operating Temp.
Weight
ISD-M71
12VDC Only (Max.500mA)
758(H) x 540(V)
120dB(Max), 102dB(Typical)
0Lux with IR LED (30pcs)
COLOR / B/W / AUTO
2000 K~11,000 K
1/25(f/1.2) ~ 1/30,720 sec.
Low / Middle / High / Off
12 Zones
RS-485
Low / Middle / High / Off
Horizontal and Vertical
On / Off
More than 50dB
Built-in
Internal / Line Lock
30% ~ 90% RH
-10 C to 50
Approx. 1,130g
