LED
Hard disk activity
Power

5.25-inch drive bays

The 5.25-inch drive bays provide space for up to five 5.25-inch devices
such as CD-ROM drives, 5.25-inch diskette drives, or tape drives.

Bezel doors and keylock

The top bezel door provides access to the power, reset, and keyboard inhibit
switches, as well as the 3.5-inch diskette drive and the 5.25-inch drive bays.
The lower bezel door provides access to the 3.5-inch low voltage
differential (LVD) SCA drive bays. Both doors can be locked to prevent
unauthorized access.

RAID bay backplane

The RAID bay backplane supports connection of up to six 3.5-inch
hot-swappable, LVD, SCA, SCSI hard drives. The backplane automatically
sets SCSI ID numbers and provides termination. Settings allow you to
divide the backplane into one or two channels and to connect a SCSI
CD-ROM drive to the backplane as well.

3.5-Inch LVD SCA drive bays

The 3.5-inch LVD SCA drive bays allow you to install up to six 1- or
1.6-inch hot-swappable SCSI hard drives. The drives use a guide rail system
that allows easy installation and removal. Cooling for the drive bays is
provided by internal fans.

3.5-inch diskette drive

The standard system is equipped with one half-height 1.44-MB 3.5-inch
diskette.
Meaning When Lit
The corresponding LVD SCA drive is being
accessed.
The system is on.
Warning!
Both upper and lower bezel
doors must be closed and
locked while the system is
running.
System Features 13
