  • Page 1 Kramer Electronics, Ltd. Preliminary USER MANUAL Model: SP-11D Digital Video Processor...
  • Page 2: Table Of Contents

    Figure 4: Connecting the SP-11D Digital Video Processor Tables Table 1: Front Panel SP-11D Digital Video Processor Table 2: Rear Panel SP-11D Digital Video Processor Table 3: DIP-switch Settings Table 4: Test Signals Table 5: Technical Specifications of the SP-11D Digital Video Processor Table 6: Protocol Definitions...
  • Page 3: Introduction

    GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products 2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com 3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com...
  • Page 4: Quick Start

    Getting Started Quick Start This quick start chart summarizes the basic setup and operation steps. KRAMER: SIMPLE CREATIVE TECHNOLOGY...
  • Page 5: Overview

    1 All output formats are always available 2 The SP-11D can be used for conversion to any video standard 3 RGB and YUV inputs, RGB and YUV outputs, and independent control of RED, GREEN and BLUE; and Y, R-Y and B-Y...
  • Page 6: Your Sp-11D Digital Video Processor

    (often associated with low quality cables). • Avoid interference from neighboring electrical appliances that may adversely influence signal quality and position your Kramer SP-11D away from moisture, excessive sunlight and dust Your SP-11D Digital Video Processor...
  • Page 7: Figure 1: Sp-11D Digital Video Processor

    Your SP-11D Digital Video Processor Figure 1: SP-11D Digital Video Processor...
  • Page 8: Table 1: Front Panel Sp-11D Digital Video Processor

    Your SP-11D Digital Video Processor Table 1: Front Panel SP-11D Digital Video Processor Feature Function POWER Switch Illuminated switch for turning the unit ON or OFF INPUT STANDARD LEDs Cycle between PAL B, PAL N, PAL M, NTSC 3, NTSC 4, and SECAM.
  • Page 9: Table 2: Rear Panel Sp-11D Digital Video Processor

    Press to increase the level 33 FREEZE Button Pauses the output video 34 PANEL LOCK Button Disengages the front panel buttons Table 2: Rear Panel SP-11D Digital Video Processor Feature Function CV BNC Connector Connects to the composite video source...
  • Page 10: Installing On A Rack

    Installing on a Rack Installing on a Rack This section provides instructions for rack mounting the 1U unit. KRAMER: SIMPLE CREATIVE TECHNOLOGY...
  • Page 11: Connecting Your Sp-11D Digital Video Processor

    (not illustrated in Figure 1 All output formats are always available. However, when only one output is required, connect that output of the SP-11D, and leave the other outputs unconnected 2 Switch OFF the power on each device before connecting it to your SP-11D. After connecting your SP-11D, switch on its power and then switch on the power on each device 3 Pushed in terminates the input.
  • Page 12: Connecting A Pc

    Connecting Your SP-11D Digital Video Processor Connecting a PC You can connect to the unit via a crossed RS-232 connection, using for example, a PC. A crossed cable or null-modem is required as shown in method A and B respectively. If a shielded cable is used, connect the shield to pin 5.
  • Page 13: Dip-Switch Settings

    Connecting Your SP-11D Digital Video Processor DIP-Switch Settings The SP-11D DIP-switch settings are defined in Table 3 Table Table 3: DIP-switch Settings DIP-Switch Set as follows: Pedestal ON for pedestal of output signal (7.5 IRE offset selection for NTSC); OFF for no...
  • Page 14: Operating The Sp-11D Digital Video Processor

    • RS-232 serial commands transmitted by a touch screen system, PC, or other serial controller To operate the SP-11D using the front panel buttons, do the following: Turn on the power and after it has completed its warm-up sequence, press the INPUT button to select the source—CV, YC, YUV, RGB/S, or SDI—...
  • Page 15 2 Item 19 in Table 2 3 The SP-11D has a full range of color control features in both YUV and RGB color spaces with independent control of RED, GREEN and BLUE; and Y, R-Y and B-Y 4 Using the V-SHARP and H-SHARP buttons...
  • Page 16: Storing/Recalling Setups

    Operating the SP-11D Digital Video Processor  Press the + button or – button once to gradually increase or decrease the current level by one unit (the 7-segment display shows the new level) To increase or decrease the current level rapidly, press and hold down the + button or –...
  • Page 17: Locking The Front Panel

    Locking the Front Panel To prevent changing the settings unintentionally or tampering with the front panel, lock your SP-11D. Unlocking releases the protection mechanism. To lock the SP-11D: • Press the PANEL LOCK button (for about 2 seconds) until it illuminates —...
  • Page 18: Technical Specifications

    Technical Specifications Table 5 includes the technical specifications: Table 5: Technical Specifications of the SP-11D Digital Video Processor INPUTS: 1 composite video: 1Vpp/75Ω on a BNC connector; 1 Y/C: 1Vpp/75Ω (Y), 0.3Vpp/75Ω (C) on a 4‑pin connector; 1 component: Y/R‑Y/B‑Y (or RGB/S) 1Vpp/0.7Vpp/0.7Vpp/75Ω...
  • Page 19: Communication Protocol

    Communication Protocol Communication Protocol This protocol, which enables RS-232 communication between the SP-11D and the PC, uses 4 bytes of information, and data is at 9600 baud. Table 6: Protocol Definitions First byte options RESET VIDEO READ PARAMETER WRITE PARAMETER...
  • Page 20 PC -> I = 34;D = 0;E = PROGRAMM NUMBER -> MACHINE PC <- I = 34;D = 0;E = PROGRAMM NUMBER <- MACHINE PROGRAMM NUMBER - 0 = PROGRAMM 1 PROGRAMM NUMBER - 1 = PROGRAMM 2 PROGRAMM NUMBER - 15 = PROGRAMM 16 KRAMER: SIMPLE CREATIVE TECHNOLOGY...
  • Page 21 Communication Protocol STORE PC -> I = 35;D = 0;E = PROGRAMM NUMBER -> MACHINE PC <- I = 34;D = 0;E = PROGRAMM NUMBER <- MACHINE (RECALL) IDENTIFY MACHINE MACHINE NAME PC -> I = 61;D = 1;E = 0 -> MACHINE PC <- I = 61;D = MACHINE NAME HIGH;E = MACHINE NAME LOW <- MACHINE SOFTWARE VERSION PC ->...
  • Page 22 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
  • Page 23 For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com, where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
