Summary of Contents for Kramer PT-2C
- Page 1 USER MANUAL MODEL: PT‑2C Extended EDID Processor www.kramerAV.com P/N: 2900-300494 Rev 3...
-
Page 2: Table Of Contents
Kramer Electronics Ltd. Contents Introduction Getting Started Overview Overview Defining the PT‑2C Extended EDID Processor Connecting the PT‑2C Configuring the PT‑2C EDID loading/storing Default EDID Technical Specifications Supported Resolutions PT‑2C – Contents... -
Page 3: Introduction
Safety Instructions Caution: There are no operator serviceable parts inside the unit Warning: Use only the Kramer Electronics power supply that is provided with the unit Warning: Disconnect the power and unplug the unit from the wall before installing Recycling Kramer Products... -
Page 4: Overview
Kramer Electronics Ltd. arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/support/recycling. Overview Congratulations on purchasing your Kramer PT‑2C Extended EDID Processor. This product, which incorporates HDMI™ technology, is ideal for: •... -
Page 5: Overview
Kramer Electronics Ltd. Overview PT‑2C is an EDID processor for HDMI signals. It allows you to pass or block HDCP, deep audio or deep color signals that may or may not be compatible with the display. PT‑2C features: • A maximum data rate of 10.2Gbps (3.4Gbps per data channel) •... -
Page 6: Defining The Pt-2C Extended Edid Processor
Kramer Electronics Ltd. Defining the PT‑2C Extended EDID Processor Figure 1 defines the front and rear panels of the PT‑2C. Figure 1: PT‑2C Front and Rear Panels Feature Function EDID DESIGNER/F/W UPDATE Connect to a PC/laptop running EDID Designer to modify the... -
Page 7: Connecting The Pt-2C
Kramer Electronics Ltd. Connecting the PT‑2C Always switch off the power to each device before connecting it to your PT‑2C. After connecting your PT‑2C, connect its power and then switch on the power to each device. Figure 2: Connecting the PT‑2C Extended EDID Processor... -
Page 8: Configuring The Pt-2C
Kramer Electronics Ltd. Configuring the PT‑2C 1. The 8-way Program DIP-switch on the rear panel is used to configure the PT‑2C according to the following table. Note that all the DIP-switches are set to off (up) by default. Feature Function On (down) —... -
Page 9: Edid Loading/Storing
When in the lock mode the audio setup is determined by the DIP-switch 3 Audio setup. You can connect a PC to the EDID DESIGNER/F/W UPDATE Mini USB port to modify the EDID via the Kramer EDID designer software. Note that when using EDID designer to modify the EDID (in the Lock mode), the DIP-switch 3 status is ignored. -
Page 10: Default Edid
Kramer Electronics Ltd. Default EDID Monitor Model name....PT-2C Manufacturer..... KMR Plug and Play ID..KMR1200 Serial number.... n/a Manufacture date..2015, ISO week 255 Filter driver.... None ------------------------- EDID revision.... 1.3 Input signal type..Digital Color bit depth..Undefined Display type..... - Page 11 Kramer Electronics Ltd. 832 x 624p at 75Hz - Apple Mac II 1024 x 768i at 87Hz - IBM 1024 x 768p at 60Hz - VESA 1024 x 768p at 70Hz - VESA 1024 x 768p at 75Hz - VESA...
- Page 12 Kramer Electronics Ltd. Date generated... 2/16/2016 Software revision..2.60.0.972 Data source....Real-time 0x0041 Operating system..6.1.7601.2.Service Pack 1 Raw data 00,FF,FF,FF,FF,FF,FF,00,2D,B2,00,12,00,00,00,00,FF,19,01,03,80,34,20,78,EA,B3,25,AC,51,30,B4,26, 10,50,54,FF,FF,80,81,8F,81,99,A9,40,61,59,45,59,31,59,71,4A,81,40,01,1D,00,72,51,D0,1E,20,6E,28, 55,00,07,44,21,00,00,1E,00,00,00,FD,00,38,4C,1E,53,11,00,0A,20,20,20,20,20,20,00,00,00,FC,00,50, 54,2D,32,43,20,20,20,20,20,20,20,20,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,01,CD, 02,03,1B,F1,23,09,07,07,48,10,05,84,03,02,07,16,01,65,03,0C,00,10,00,83,01,00,00,02,3A,80,18,71, 38,2D,40,58,2C,45,00,07,44,21,00,00,1E,01,1D,80,18,71,1C,16,20,58,2C,25,00,07,44,21,00,00,9E,01, 1D,00,72,51,D0,1E,20,6E,28,55,00,07,44,21,00,00,1E,8C,0A,D0,8A,20,E0,2D,10,10,3E,96,00,07,44,21, 00,00,18,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,47 PT‑2C – Default EDID...
-
Page 13: Technical Specifications
Kramer Electronics Ltd. Technical Specifications INPUT: 1 HDMI connector OUTPUT: 1 HDMI connector PORTS: 1 Mini USB MAX DATA RATE: 10.2Gbps (3.4Gbps per data channel) STANDARDS SUPPORTED: Supports HDMI and HDCP CONTROLS: 8 DIP-switches HDMI with Deep Color, x.v.Color™ and 3D STANDARDS: HDCP—works with sources that support HDCP repeater mode... -
Page 14: Supported Resolutions
Kramer Electronics Ltd. Supported Resolutions Resolution Refresh Rate Comments 640x480p 85Hz; 75Hz; 72Hz; 60Hz; 59.95Hz 59.95Hz is available on quantum 780B 720x480p 60Hz 720x576p 50Hz 800x600p 85Hz; 75Hz; 72Hz; 60Hz “CVT(R)0860H” on quantum 848x480p 60Hz 852x480p 60Hz available on quantum 780B 1024x768p 85Hz;... - Page 15 Electronics products, this product must be insured during shipment, with the insurance and shipping charges prepaid by you. If this product is returned uninsured, you assume all risks of loss or damage during shipment. Kramer Electronics will not be responsible for any costs related to the removal or re- installation of this product from or into any installation.
- Page 16 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback.
