Summary of Contents for Kramer PT-2C
- Page 1 PDF provided by Conference Room AV Kramer PT-2C Extended EDID Processor 4K, HDMI, HDCP Supported...
- Page 2 USER MANUAL MODEL: PT-2C Extended EDID Processor P/N: 2900-300494 Rev 1 www.kramerAV.com...
-
Page 4: Table Of Contents
Overview Defining the PT-2C Extended EDID Processor Connecting the PT-2C Configuring the PT-2C EDID loading/storing Default EDID Technical Specifications Supported Resolutions Figures Figure 1: PT-2C Front and Rear Panels Figure 2: Connecting the PT-2C Extended EDID Processor PT-2C – Contents... -
Page 5: Introduction
Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and GROUP 14: Collaboration. Congratulations on purchasing your Kramer PT-2C Extended EDID Processor. This product, which incorporates HDMI™ technology, is ideal for: •... -
Page 6: Getting Started
Avoid interference from neighbouring electrical appliances that may adversely influence signal quality • Position your PT-2C away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. -
Page 7: Recycling Kramer Products
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/support/recycling/. -
Page 8: Overview
Overview The PT-2C is an EDID processor for HDMI signals. It allows you to pass or block HDCP, deep audio or deep color signals that may or may not be compatible with the display. The PT-2C features: • A maximum data rate of 10.2Gbps (3.4Gbps per data channel) •... -
Page 9: Defining The Pt-2C Extended Edid Processor
Defining the PT-2C Extended EDID Processor Figure 1 defines the front and rear panels of the PT-2C. Figure 1: PT-2C Front and Rear Panels Feature Function EDID DESIGNER/F/W Connect to a PC/laptop running EDID Designer to UPDATE Mini USB modify the EDID, or to update the firmware of the... -
Page 10: Connecting The Pt-2C
2. Connect the HDMI OUT connector to an HDMI acceptor (for example, a display). 3. Connect the USB port to a laptop running EDID Designer to modify the EDID, or to a PC to upgrade the firmware of the PT-2C. PT-2C - Connecting the PT-2C... -
Page 11: Configuring The Pt-2C
Delay before 5V output cut-off Always on The PT-2C can power off the HDMI 5V output to let the connected device enter the sleep mode if there is no source connected. The power off delay time is controlled by DIP-switches 6 and 7 (0 = up/Off; 1 = down/On) -
Page 12: Edid Loading/Storing
(a display in the following examples) is automatically loaded to the PT-2C. If the display is replaced, the PT-2C captures the new EDID from the new display. Any change in the output automatically changes the EDID that is stored in the PT-2C. -
Page 13: Default Edid
Native/preferred timing.. 1280x720p at 60Hz (16:10) Modeline...."1280x720" 74.250 1280 1390 1430 1650 720 725 730 750 +hsync +vsync Standard timings supported 720 x 400p at 70Hz - IBM VGA 720 x 400p at 88Hz - IBM XGA2 PT-2C - Default EDID... - Page 14 720 x 480p at 60Hz - EDTV (4:3, 8:9) 720 x 480i at 60Hz - Doublescan (16:9, 32:27) 720 x 576i at 50Hz - Doublescan (16:9, 64:45) 640 x 480p at 60Hz - Default (4:3, 1:1) NB: NTSC refresh rate = (Hz*1000)/1001 PT-2C - Default EDID...
- Page 15 Front left/right center.. No Rear left/right center... No Rear LFE....No Report information Date generated... 2/16/2016 Software revision..2.60.0.972 Data source....Real-time 0x0041 Operating system..6.1.7601.2.Service Pack 1 Raw data 00,FF,FF,FF,FF,FF,FF,00,2D,B2,00,12,00,00,00,00,FF,19,01,03,80,34,20,78,EA,B3,25,AC,51,30,B4,26, 10,50,54,FF,FF,80,81,8F,81,99,A9,40,61,59,45,59,31,59,71,4A,81,40,01,1D,00,72,51,D0,1E,20,6E,28, 55,00,07,44,21,00,00,1E,00,00,00,FD,00,38,4C,1E,53,11,00,0A,20,20,20,20,20,20,00,00,00,FC,00,50, 54,2D,32,43,20,20,20,20,20,20,20,20,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,01,CD, 02,03,1B,F1,23,09,07,07,48,10,05,84,03,02,07,16,01,65,03,0C,00,10,00,83,01,00,00,02,3A,80,18,71, 38,2D,40,58,2C,45,00,07,44,21,00,00,1E,01,1D,80,18,71,1C,16,20,58,2C,25,00,07,44,21,00,00,9E,01, 1D,00,72,51,D0,1E,20,6E,28,55,00,07,44,21,00,00,1E,8C,0A,D0,8A,20,E0,2D,10,10,3E,96,00,07,44,21, 00,00,18,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,47 PT-2C - Default EDID...
-
Page 16: Technical Specifications
85Hz; 75Hz; 70Hz; 60Hz 1280x960 60Hz 1280x1024p 75Hz; 60Hz 1280x768p 60Hz available on quantum 780B 1280x800p 60Hz “DMR(T)1260D” on quantum 1920x1080p 50Hz; 60Hz; 30Hz; 24Hz; “1080p30” on quantum 1920x1080p 60Hz; Deep color 1920x1080i 50Hz; 60Hz; 1600x1200p 60Hz PT-2C - Technical Specifications... - Page 17 Resolution Refresh Rate Comments 1600x900p 60Hz “DMR1660H” on quantum 1152x864p 75Hz 1440x900p 60Hz 1680x1050p 60Hz 1360x768p 60Hz 1366x768 60Hz; 50Hz 1400x1050p 60Hz 720x480i 30Hz available on quantum 780B 3840x2160 30Hz 4096x2160 30Hz PT-2C - Technical Specifications...
- Page 19 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site to find updates to this user manual. We welcome your questions, comments, and feedback.
