- Page 1 Kramer Electronics Ltd. USER MANUAL Sync Processors Models: SG-6 SG-7 SG-9 SG-11 SG-6003B IMPORTANT: Before proceeding, please read paragraph entitled "Unpacking and Contents" KRAMER ELECTRONICS LTD. P/N: 2900-004002...
-
Page 2: Table Of Contents
Getting to Know Your SG-6N Sync Stabilizer Getting to Know Your SG-7 Sync Transcoder Getting to Know Your SG-9 Video Black Burst Restorer Getting to Know Your SG-11 Black Burst/Color Bar Generator Getting to Know Your SG-6003B Sync Processor INSTALLATION... -
Page 3: Introduction
In addition to the Kramer line of high quality processors, such as the one you have just purchased, Kramer also offers a full line of high quality distribution amplifiers, switchers, interfaces, controllers and computer-related products. -
Page 4: Sync Location
In the past, the sync direction instructed the monitor which resolution to choose. Today, most of the monitors are smarter and set the resolution automatically, but nevertheless, the cards still generate those sync signals. Kramer Electronics Ltd. Figure 2: Vertical Sync... -
Page 5: Video Sync Processors
Video Sync Processors Kramer Electronics has a full line of Video Sync Processors that can perform sync stabilization, restoration and conversion n the following categories: Video Sync Generators: Generate standard video sync and black burst for studio genlock. -
Page 6: Specifications
Weight 0.58kg. (1.3lbs.) Approx. Power Source 12VDC, 40mA Kramer Electronics Ltd. SG-6N INPUT CHANNEL 1: One composite sync >0.3Vpp / 75 ohm or 1 TTL level composite sync 5 Vpp/ 47k on a BNC type connector with Hi-Z/75ohm switch, at video frequencies only. -
Page 7: Specifications (Cont.)
(W, D, H) Weight 1.5kg. (3.3lbs.) Approx. Power Source 230VAC, 50/60 Hz (115VAC, U.S.A.) 4.3VA. Kramer Electronics Ltd. SG-11 SG-6003B 1 Green 0.7Vpp/75 ohm One Sync 0.3Vpp/75 ohm on BNCs. 1 Sync on Green 1Vpp / 3 black burst signals, 0.3 Vpp/75 75 ohm on a BNC. -
Page 8: How Do I Get Started
UNPACKING AND CONTENTS The items contained in your Kramer Sync Processor package are listed below. Please save the original box and packaging materials for possible future transportation and shipment. -
Page 9: Sync Processors
In many cases the KRAMER SG-6N can replace or enhance a TBC operation. The SG-6N restores standard sync and blanking information, eliminating instability of the video signal. The SG-6N operates in PAL and NTSC, and a rear panel mounted switch selects operation mode. -
Page 10: Getting To Know Your Sg-7 Sync Transcoder
KRAMER SG-7 is the perfect choice - as it operates simultaneously in all directions. Front/Rear panel features of the SG-7 are described in Figure 4 and Table 3. -
Page 11: Getting To Know Your Sg-9 Video Black Burst Restorer
In many cases the KRAMER SG-9 can replace or enhance a TBC operation. The SG-9 generates standard sync and color information from internal high quality, genlocked, sync and color generators. -
Page 12: Figure 6: Sg-11 Front/Rear Panel Features
Component Video formats - RGB with Sync On Green and RGBS. In many video studios and production centers there is a need to convert from one format to the other and the KRAMER SG-11 is the perfect choice - as it operates simultaneously in both directions. -
Page 13: Getting To Know Your Sg-11 Black Burst/Color Bar Generator
Getting to Know Your SG-6003B Black Burst/Color Bar Generator The KRAMER SG-6003B is a broadcast level Black Burst/Color Bar Generator for video studio applications. The SG-6003B provides three identical Black Burst outputs, a color Subcarrier output, a Color Bar output and two 1 kHz, crystal stabilized audio outputs. State-of-the-art technology is used throughout the SG-6003B - crystal controlled sync and Chroma oscillators, accurate internal sync/Subcarrier genlock, both with long term stability. -
Page 14: Installation
The SG-6N, SG-9 and the SG-11 can be rack mounted using a special adapter (see section 4.1). None of these devices require any specific spacing for ventilation above or below the unit. -
Page 15: Taking Care Of Your Processor
Video Sync Stabilizer's input (SG-6N in this case). The SG-6N removes of unwanted interference and signal distortions and the restored signal is outputted to an appropriate acceptor. Kramer Electronics Ltd. Figure 8: Stabilizing the Video Sync... -
Page 16: Black Burst/Bar Generator Connections
Restoring Black Burst and Image Stability Figure 10 illustrates typical usage of a Kramer Sync processor (SG-9 in this case): an unstable video signal, coming from a video source is connected to the SG-9, in order to restore the bad image. A video acceptor is connected to the SG-9 output and receives the restored image. -
Page 17: Transcoding Various Sync Formats
Channel 3 has two outputs: CS OUT1 is analog only and CS OUT2 is TTL level but can be converted to analog by loading this output with 75ohm load. Cross linking between inputs and outputs is allowed, however some delay will be created due to the long processing chain. Operate source, acceptors and the SG-7. Kramer Electronics Ltd. -
Page 18: Figure 11: Transcoding Various Sync Formats
Figure 11: Transcoding Various Sync Formats Kramer Electronics Ltd. -
Page 19: 10 Troubleshooting
Confirm that power connections are secured at the machine and at the receptacle. Make sure the mains receptacle is active (SG-7, SG-9, SG-11, SG-6003B) or that the DC power supply is operational (SG-6N). For the SG-7, SG-9, SG-11, SG-6003B perform the following:... -
Page 20: Video Signal
Disconnect the affected cable and replace, or insert an isolation transformer in the signal path. Use a video Isolator, such as Kramer OC-1N or a differential amplifier such as Kramer 123V inserted in the video signal path. -
Page 21: Limited Warranty
Any product which is not distributed by Kramer or which is not purchased from an authorized Kramer dealer. If you are uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the web site www.kramerelectronics.com. - Page 22 EXCLUSION OF DAMAGES Kramer’s liability for any defective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
-
Page 23: Kramer Electronics Ltd
The list of Kramer distributors appears on our web site: www.kramerelectronics.com From the web site it is also possible to e-mail factory headquarters. We welcome your questions, comments and feedback. Kramer Electronics Ltd. 3 Am VeOlamo Street. Jerusalem 95463, Israel Tel: (972-2)-654-4000. Fax: (972-2)-653-5369...
