GPS Accuracy
Satellite Array
"Sky View"
Signal Strength
Bars
Satellite Page
Press MENU to view options for Simulator, WAAS,
Track Up/North Up, Multicolor screen, and New
Location to use the Map Page to establish your
approximate location. Once the receiver has collected
information from and is fixed on at least three
satellites, the unit is "Ready to Navigate" and you can
advance to the Map Page.
96/96C Owner's Manual

Status Bar

At the top of each page, a Status Bar provides the
Current
current status for several unit features that are not
Location
otherwise noticeable when operational.
Acquiring
Satellites
B
System Symbols
Battery
Auxiliary
Backlight
Power
Power
USB
Alarm Set
Connected
Satellite Status Symbols
3-D
2-D
Navigation
Navigation
Navigation Mode Symbols
Aviation
Automotive
Mode
Mode
o >
aSIc peratIon
On
Simulating
Navigation
Marine
Mode
