Garmin GPSMAP 96 Quick Reference Manual

Marking Your Location as a Waypoint

A waypoint is a geographic location that you specify. It can
be your current location, a point on the Map Page, or any
item from the Find Feature database.
1. Press and hold ENTER/
MARK to show the Mark
Waypoint Page. Your
current position is assigned
a map symbol, a unique
identification number, a
date and time of recording,
location coordinates, and
if available, elevation, and
depth.
2. To save the waypoint to
the Waypoints List, press
ENTER.
To personalize the Waypoint, refer to the "Using
Waypoints" section of the owner's manual.
© Copyright 2004, 2006 Garmin Ltd. or its subsidiaries
Part Number: 190-00420-01 Rev. B Printed in Taiwan
Finding an Airport
You can search for a destination in each of the three operating
modes, Aviation, Automotive, and Marine. References to
Marine and Automotive modes, buttons, pages, and fields, are
in parentheses for this section. All operating modes use data
from the Jeppesen database and unit mapping database to find
and navigate to waypoints, airports, aviation navigation aids
like VOR, NDB, intersections, cities, and recent finds. To find
Points of Interest (such as restaurants, lodging, and museums)
and Marine Navigation Aids, you must download detailed
map data from Garmin MapSource .
®
1. Press DIRECT TO for the
D
Go To Page (Find Menu) or press
and hold DIRECT TO for the
Nearest Airport list (Recent Finds
list).
2. Use the ROCKER to select the
Airport Identifier field (Waypoints
icon), and then press ENTER.
The Nearest Page list shows only
Aviation Go To
those nearest to your current
location. Press MENU to view the
list of options.
3. Use the ROCKER to scroll through
the alphanumeric Identifier list until
the desired airport (waypoint) is
selected. Then press ENTER.
4. Use the ROCKER to select Go To
at the bottom of the page. Then
press ENTER to begin navigation
to the airport, navigation aid, Find Menu
waypoint, or map item.
Navigating to an Airport
When using Go To to navigate, the GPSMAP 96/96C creates
a direct to or course to the waypoint. The HSI Page uses the
Course Pointer, Bug Indicator, Compass Ring, and data fields
to direct your navigation efforts.
Course Pointer—indicates the
direction established in creating
the course. If you deviate from
the course, the center section
of the Course Pointer indicates
deviation from the course.
Bug Indicator—guides you
directly to your destination.
HSI Page
Compass Ring—rotates to
indicate directional orientation
when you begin to move.
Data Fields—contain selectable navigation information,
such as speed, distance to go, or elapsed time.
1. Press PAGE repeatedly to show the HSI.
2. Press QUIT to show the Map Page and see your
progress toward the waypoint. A course line appears
on the map, and the Aircraft Symbol moves as you
move.
3. Press QUIT again to move to the Position Page.
This page shows data, such as fuel and flight timers,
location, a trip odometer, and maximum speed.
4. To stop navigation, press MENU with the HSI or Map
Page shown. Select Stop Navigation, and press
ENTER.
GPSMAP ® 96/96C
portable aviation receiver
Bug
Indicator
Course

quick reference guide

Pointer
Course
Deviation
Indicator
To/From
Indicator
Compass
Ring
