Specifications

CPU •
•
Chipset
•
Memory
•
•
•
*Due to the limitation of chipset spec, it supports up to 1866 MHz for
motherboard with a single DIMM per channel.
Expansion
•
Slots •
•
Storage •
Audio
•
•
LAN •
•
•
Rear Panel I/O
•
•
•
•
•
Internal I/O •
Connectors & •
Headers •
•
•
•
•
•
•
•
•
•
•
•
System BIOS
•
•
AP support •
•
Form Factor •
FM1 for AMD A series processors
Supports CPU up to 100W TDP
AMD A55 (Hudson D2)
Dual-channel DDR3 memory architecture
2 x 240-pin DDR3 DIMM sockets support up to 16 GB
Supports DDR3 DDR3 1866*/1600/1333
1 x PCI Express Gen2 x16 slot
2 x PCI Express x1 slots
1 x PCI slot
Supported by AMD A55 (Hudson D2)
6 x Serial ATA 3.0 Gb/s Host Controllers
Realtek ALC662 6-Ch High Definition audio CODEC
Compliant with HD audio specification
Realtek 8111E VL Gigabit LAN
Realtek 8105E VL 10/100 LAN (optional)
1 x D-sub (VGA) port
1 x HDMI port (DVI port optional)
1 x PS/2 keyboard and mouse combo connector
8 x USB 2.0 ports
1 x RJ45 LAN port
1 x Audio port (Line in, microphone in and line out)
1 x 24-pin ATX Power Supply connector
1 x 4-pin ATX Power Supply connector
1 x 4-pin CPU_FAN connector
1 x 3-pin SYS_FAN connector
2 x USB 2.0 headers support additional 4 USB 2.0 ports
6 x Serial ATA 3.0 Gb/s connectors
1 x COM header
1 x LPT header
1 x Front panel audio header
1 x Case Open header
1 x Speaker header
1 x Clear CMOS header
1 x SPDIF out header
AMI BIOS with 16Mb SPI Flash ROM
Supports Multi-language BIOS Utility
Supports ECS M.I.B III Utility
Supports eBLU/eDLU/eSF
Supports EZ Charger
MATX Size, 244mm x 200mm
Introducing the Motherboard
SDRAM
