Table of Contents
Advertisement
Quick Links
Copyright
Copyright © 2012 MiTAC International Corporation. All rights reserved. No part of
this manual may be reproduced or translated without prior written consent from
MiTAC International Corporation.
Trademark
All registered and unregistered trademarks and company names contained in this
manual are property of their respective owners including, but not limited to the
following.
®
TYAN
is a trademark of MiTAC International Corporation.
®
Intel
is a trademark of Intel
AMI, AMI BIOS are trademarks of AMI Technologies.
®
Microsoft
, Windows
®
Winbond
is a trademark of Winbond Electronics Corporation.
Notice
Information contained in this document is furnished by MiTAC International
Corporation and has been reviewed for accuracy and reliability prior to printing.
MiTAC assumes no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of TYAN
warranties relating to fitness for a particular purpose or merchantability. MiTAC
retains the right to make changes to product descriptions and/or specifications at
any time, without notice. In no event will MiTAC be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other
malady resulting from errors or inaccuracies of information contained in this
document.
S7052
Version 1.0
®
Corporation.
®
are trademarks of Microsoft Corporation.
http://www.tyan.com
®
products including liability or
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TYAN S7052
Summary of Contents for TYAN S7052
- Page 1 Corporation and has been reviewed for accuracy and reliability prior to printing. MiTAC assumes no liability whatsoever, and disclaims any express or implied ® warranty, relating to sale and/or use of TYAN products including liability or warranties relating to fitness for a particular purpose or merchantability. MiTAC retains the right to make changes to product descriptions and/or specifications at any time, without notice.
- Page 2 http://www.tyan.com...
-
Page 3: Table Of Contents
3.7 Server Management ................ 88 3.8 Event Logs..................91 3.9 Save & Exit ..................92 Chapter 4: Diagnostics................95 4.1 Flash Utility ..................95 4.2 AMIBIOS Post Code (Aptio) ............96 Appendix: Fan and Temp Sensors............103 Glossary....................107 Technical Support .................. 113 http://www.tyan.com... -
Page 4: Before You Begin
6 x SATA Cable 1 x COM Port Bracket Cable 1 x USB dual-port Bracket Cable 1 x IO shielding 1 x S7052 User’s manual 1 x S7052 Quick reference guide ® 1 x TYAN Driver CD IMPORTANT NOTE: Sales sample may not come with the accessory listed above. -
Page 5: Chapter 1: Instruction
S7052 is capable of offering scalable 32 and 64-bit computing, high-bandwidth memory design, and lightning-fast PCI-E bus implementation. The S7052 not only empowers you in today’s demanding IT environment but also offers a smooth path for future application upgradeability. All of these rich feature sets provides the S7052 with the power and flexibility to meet demanding requirements for today’s IT environments. - Page 6 Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3 /PXE boot / ACPI 2.0 power management /Power BIOS Feature on mode after power recovery / User-configurable H/W monitoring / Auto-configurable of hard disk types Form Factor Physical SSI EEB Dimension Board Dimension 12"x13" (305x330mm) http://www.tyan.com...
- Page 7 Please visit the Tyan’s Web site for the latest Operating System OS supported list update. FCC (DoC) Class A Regulation CE (DoC) Operating Temp. 10° C ~ 35° C (50° F~ 95° F) Non-operating Operating - 40° C ~ 70° C (-40° F ~ 158° F) Temp.
- Page 8 H/W monitoring / Auto-configurable of hard disk types Form Factor Physical SSI EEB Dimension Board Dimension 12"x13" (305x330mm) Please visit the Tyan’s Web site for the latest Operating System OS supported list update. FCC (DoC) Class A Regulation CE (DoC)
- Page 9 Environment In/Non-operating 90%, non-condensing at 35° C Humidity RoHS 6/6 RoHS Compliant Motherboard (1) S7052 Motherboard (1) Quick Ref. Guide / (1) I/O Shield Quick Ref. Manual Guide Installation CD (1) TYAN installation CD Package Contains I/O Shield (1) I/O Shield...
- Page 10 Brand / ROM size 8MB / AMI Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3 /PXE boot / ACPI 2.0 power management /Power BIOS on mode after power recovery / User-configurable Feature H/W monitoring / Auto-configurable of hard disk types http://www.tyan.com...
- Page 11 Form Factor Physical SSI EEB Dimension Board Dimension 12"x13" (305x330mm) Please visit the Tyan’s Web site for the latest Operating System OS supported list update. FCC (DoC) Class A Regulation CE (DoC) Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
- Page 12 (BMC) / Supports storage over IP and Feature remote platform-flash / USB 2.0 virtual hub Server AST2300 iKVM 24-bit high quality video compression / Dual 10/100 Management Feature Mb/s MAC interfaces Supports storage over IP and remote platform-flash AST2050 IPMI Feature http://www.tyan.com...
-
Page 13: Software Specifications
H/W monitoring / Auto-configurable of hard disk types Form Factor Physical SSI EEB Dimension Board Dimension 12"x13" (305x330mm) Please visit the Tyan’s Web site for the latest Operating System OS supported list update. FCC (DoC) Class A Regulation CE (DoC) Operating Temp. - Page 14 NOTE http://www.tyan.com...
-
Page 15: Chapter 2: Board Installation
Caution! To avoid damaging the motherboard and associated components, do not use torque force greater than 7kgf/cm (6.09 lb/in) on each mounting screw for motherboard installation. Do not apply power to the board if it has been damaged. http://www.tyan.com... -
Page 16: Board Image
2.1 Board Image S7052 This picture is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the above picture. http://www.tyan.com... -
Page 17: Block Diagram
2.2 Block Diagram S7052 Block Diagram http://www.tyan.com... -
Page 18: Board Parts, Jumpers And Connectors
The board you receive may not look exactly like the above diagram. But for the DIMM number please refer to the above placement for memory installation. For the latest board revision, please visit our web site at http://www.tyan.com. http://www.tyan.com... - Page 19 SSI 8-pin CPU0 Power Connector SATA SGPIO Pin Header BIOS Overwrite Jumper ME Firmware Update Header SAS Software RAID Key Header SATA0/SATA1 SATA3 Connector SATA2/SATA3/SATA4/SATA5 SATA2 Connector Jumper Legend OPEN - Jumper OFF Without jumper cover CLOSED - Jumper ON With jumper cover http://www.tyan.com...
- Page 20 http://www.tyan.com...
- Page 21 J42: Port 80 Header Signal Signal P3V3 FRAME LAD0 LAD1 RESET LAD2 LAD3 J22: Front Panel Connector Signal Signal PWRLED+ +3VSB IDLED+ PWRLED- IDLED- HDLED+ WLED+ HDLED- WLED- PWRSW+ LAN1LED+ LAN1LED- RSTSW SMBDAT SMBCLK IDLED_SW INTRD# LAN2LED+ NMI_SW- LAN2LED- http://www.tyan.com...
- Page 22 J24/J25/J33 http://www.tyan.com...
- Page 23 TACH7 TACH3 TACH8 TACH4 TACH9 TACH5 TACH10 NO PIN PWM2 PWM1 TACH11 TACH12 V3AUX PWM3 J10: IPMB Connector Signal Signal SMB_BMC_SDA2 SMB_BMC_SCL2 J63: PSMI Connector Signal SMBus CLK SMBUs Data Reserve Power J24/J25/J33: LAN3/LAN4/LAN5 LED Header Signal LAN+ LED- http://www.tyan.com...
- Page 24 LED1/J5 SATA0/1 SATA2/3 SATA4/5 J57/J58 http://www.tyan.com...
- Page 25 System identified System not identified NOTE: IPMI can activate ID LED from remote site. http://www.tyan.com Please visit the TYAN Web Site at to download the latest AST2300 Software Configuration Guide for IPMI settings. J27: Vertical (Type A) USB Connectors Signal...
- Page 26 http://www.tyan.com...
- Page 27 Clear CMOS. 4. Put jumper cap back to Pin_1 and Pin_2 (Default setting). 5. Reconnect power connectors to the motherboard and Clear CMOS power on system. J59: SAS SMBUS Pin Header Signal Signal Power SMBus Clock Ground SMBus Data Fault http://www.tyan.com...
- Page 28 http://www.tyan.com...
- Page 29 Signal PCH_RAID_KEY J54: Patsburg Upgrade ROM Header Signal PCH_SKU_KEY Patsburg Upgrade ROM Key Installation Follow the steps described later to install the Patsburg Upgrade ROM Key. Take out the Patsburg Upgrade ROM Key. Locate the Patsburg Upgrade ROM Header. http://www.tyan.com...
- Page 30 Insert the Upgrade ROM Key in the direction as the arrow shows. You have completed the Patsburg Upgrade ROM Key installation. http://www.tyan.com...
-
Page 31: Installing The Processor And Heat Sink
2.4 Installing the Processor and Heat sink ® The S7052 supported Intel processors are listed in section Hardware http://www.tyan.com Specifications on page 5. Check our website at for latest processor support. NOTE: MiTAC is not liable for damage as a result of operating an unsupported configuration. - Page 32 Place the CPU in the CPU socket and make sure that the gold arrow is located in the right direction with two notches properly aligned. Close the socket cover and press the CPU socket lever down to lock the CPU in place. The CPU installation is now complete. http://www.tyan.com...
- Page 33 . Please refer to the Intel website: http://www.intel.com ® The following diagram illustrates how to install the heatsink on the Intel Sandy Bridge Socket R. Place the heat sink on top of the CPU and secure it to the motherboard with screws. http://www.tyan.com...
-
Page 34: Thermal Interface Material
CPU lid (applying too much will actually reduce the cooling). NOTE: Always check with the manufacturer of the heat sink & processor to ensure that the thermal interface material is compatible with the processor and meets the manufacturer’s warranty requirements. http://www.tyan.com... -
Page 35: Tips On Installing Motherboard In Chassis
If there are any studs missing, you will know right away since the motherboard will not be able to be securely installed. http://www.tyan.com... - Page 36 Some chassis include plastic studs instead of metal. Although the plastic studs are usable, MiTAC recommends using metal studs with screws that will fasten the motherboard more securely in place. Below is a chart detailing what the most common motherboard studs look like and how they should be installed. http://www.tyan.com...
-
Page 37: Installing The Memory
2.7 Installing the Memory Before installing memory, ensure that the memory you have is compatible with the motherboard and processor. Check the TYAN Web site at http://www.tyan.com for details of the type of memory recommended for your motherboard. Sandy Bridge-EP/EX processor supports 4 DDR3 channels ... - Page 38 DIMM per channel. 6. Always install with DIMM_A0 Slot first, following the alphabetical order (starting with DIMM_A0, DIMM_B0, DIMM_C0, DIMM_D0), and then the numerical order (starting with DIMM_A1, DIMM_B1, DIMM_C1, DIMM_D1, DIMM_A2, DIMM_B2, DIMM_C2, DIMM_D2). http://www.tyan.com...
- Page 39 5. Un-buffered DIMM can offer slightly better performance than registerd DIMM if populating only a single DIMM per channel. 6. Always install with CPU0 and DIMM_A0 Slot first (for example: CPU0_DIMM_A0, CPU1_DIMM_A0, CPU0_DIMM_B0, CPU1_DIMM_B0), following the alphabetical order, and then the numerical order (for example: CPU0_DIMM_A1, CPU1_DIMM_A1, CPU0_DIMM_A2, CPU1_DIMM_A2). http://www.tyan.com...
- Page 40 The speeds are estimated targets and will be verified through simulation. For 3SPC/3DPC -Rank Multiplication (RM) >= 2. DDP -Dual Die Package DRAM stacking. P –Planer monolithic DRAM Die. Romley-EP/EX platform does not support 3DPC when using E5-2400 LRDIMMs. http://www.tyan.com...
- Page 41 Command Address Timing is 1N. QR RDIMM are supported but not validated by Intel/PMO in a homogenous environment. The coverage will have limited system level testing, no signal integrity testing, and no interoperability testing. The passing QR RDIMMs will be web posted. http://www.tyan.com...
-
Page 42: Memory Installation Procedure
Memory Installation Procedure Follow these instructions to install memory modules into the S7052. Press the locking levers in the direction shown in the following illustration. Align the memory module with the socket. The memory module is keyed to fit only one way in the socket. -
Page 43: Attaching Drive Cables
2.8 Attaching Drive Cables Attaching Serial ATA Cables six (6) S7052 is equipped with Serial ATA (SATA) channel. Connections for the drives are very simple. There is no need to set Master/Slave jumpers on SATA drives. If you are in need of SATA/SAS cables or power adapters please contact your place of purchase. -
Page 44: Installing Add-In Cards
Doing so allows air to circulate within the chassis more easily, thus improving cooling for all installed devices. NOTE: You must always unplug the power connector to the motherboard before performing system hardware changes to avoid damaging the board or expansion device. http://www.tyan.com... -
Page 45: Connecting External Devices
10/100/1000 Mbps LAN Link/Activity LED Scheme Left LED Right LED Link Green Amber 10 Mbps Active Blinking Green Green Link Green Amber 100 Mbps Active Blinking Green Green Link Green Amber 1000 Mbps Active Blinking Green Green No Link http://www.tyan.com... -
Page 46: Installing The Power Supply
2.11 Installing the Power Supply three (3) There are power connectors on your S7052 motherboard. The S7052 supports EPS 12V power supply. J53: ATX 24-Pin Power Connector Signal Signal +3.3V +12V +3.3V +3.3V PS-ON# PWR OK 5VSB +12V +12V +3.3V... -
Page 47: Chapter 3: Bios Setup
Select the previous value/setting of the field <+> Select the next value/setting of the field <F8> Load Fail Safe default configuration values of the menu <F3> Load the Optimal default configuration values of the menu <F4> Save and exit <Enter> Execute command or select submenu http://www.tyan.com... - Page 48 The following pages provide the details of BIOS menu. Please be noticed that the BIOS menu are continually changing due to the BIOS updating. The BIOS menu provided are the most updated ones when this manual is written. Please visit TYAN’s website at http://www.tyan.com for the information of BIOS updating. http://www.tyan.com...
-
Page 49: Main Menu
It displays BIOS related information. Memory Information This displays the total memory size. System Date Adjust the system date. MM (Months): DD (Days): YYYY (Years) System Time Adjust the system clock. HH (24 hours format): MM (Minutes): SS (Seconds) Access Level Read only. http://www.tyan.com... -
Page 50: Advanced Menu
3.3 Advanced Menu This section facilitates configuring advanced BIOS options for your system. ACPI Settings System ACPI Parameters. CPU Configuration CPU Configuration Parameters. SATA Configuration SATA Devices Configuration. SAS Configuration SAS Devices Configuration. Onboard Device Configuration Onboard Device Configuration. http://www.tyan.com... - Page 51 USB Configuration USB Configuration Parameters. Hardware Health Configuration Hardware health Configuration Parameters. Super IO Configuration System Super IO Chip Parameters. Serial Port Console Redirection Serial Port Console Redirection. http://www.tyan.com...
- Page 52 Enable or disable System ability to Hibernate (OS/S4 Sleep State). This option may not be effective with some OS. Disabled / Enabled ACPI Sleep State Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed. Suspend Disabled / S1 (CPU Stop Clock) http://www.tyan.com...
- Page 53 Enabled / Disabled Active Processor Cores Number of cores to enable in each processor package. All / 1 / 2 / 3 / 4 / 5 / 6 / 7 Limit CPUID Maximum Disabled for Windows XP. Disabled / Enabled http://www.tyan.com...
- Page 54 Intel Virtualization Technology When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology. NOTE: Once the lock bit is set, the contents of this register can not be modified until S5 reset occurs. Enabled / Disabled http://www.tyan.com...
- Page 55 3.3.2.1 Socket 0/1 CPU Information Read only. http://www.tyan.com...
- Page 56 Disabled / Enabled P-STATE Coordination Change P-State coordination type. HW_ALL / Disabled CPU C3 Report Enable/Disable CPU C3 (ACPI C2) report to OS. Enabled / Disabled CPU C6 Report Enable/Disable CPU C6 (ACPI C3) report to OS. Enabled / Disabled http://www.tyan.com...
- Page 57 Long duration power limit in Watts. Factory Long Duration Maintained Read only. Long Duration Maintained Time window which the long duration power is maintained. Recommended short duration power limit Read only. Short duration power limit Short duration power limit in Watts. http://www.tyan.com...
- Page 58 3.3.3 SATA Configuration SATA Mode Select SATA Mode. IDE Mode / AHCI Mode / RAID Mode / Disabled Port 0/1/2/3/4/5 Hot Plug Enable/Disable SATA Ports Hot Plug Support. Enabled / Disabled http://www.tyan.com...
- Page 59 3.3.4 SAS Configuration Read only. http://www.tyan.com...
- Page 60 Disabled / PXE / ISCSI NOTE: The ISCSI function is only supported in LAN1. LAN2 Option ROM Enabled/Disabled the LAN Option ROM in the Chipset. Disabled / PXE LAN3 Option ROM Enabled/Disabled the LAN Option ROM in the Chipset. Disabled / PXE http://www.tyan.com...
- Page 61 LAN4 Option ROM Enabled/Disabled the LAN Option ROM in the Chipset. Disabled / PXE LAN 82574 Enable or disable the LAN controller. Enabled / Disabled LAN5 Option ROM Enabled/Disabled the LAN Option ROM in the Chipset. Disabled / PXE http://www.tyan.com...
- Page 62 Maximum time the device will take before it properly reports itself to the Host Controller. AUTO uses default value: for a Root port it is 100 ms, for a Hub port the delay is taken from Hub descriptor. Auto / Manual http://www.tyan.com...
- Page 63 On / Off 3.3.7.1 Sensor Data Register Monitoring When you enter the Sensor Data Register Monitoring submenu, you will see the following dialog window pop out. Please wait 8~10 seconds. NOTE 1: SDR can not be modified. Read only. http://www.tyan.com...
- Page 64 http://www.tyan.com...
- Page 65 3.3.8 Super IO Configuration Super IO Chip Read only. http://www.tyan.com...
- Page 66 / IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; / IO=3E8h, IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; / IO=2E8h, IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; Change Settings SUART clock source. 24MHZ/13 / 24MHz http://www.tyan.com...
- Page 67 Serial Port for Out-Of-Band Management/Windows Emergency Services (EMS) Console Redirection Console redirection enable or disable. Disabled / Enabled Console Redirection Settings The settings specify how the host computer (which the user is using) will exchange data. Both computers should have the same or compatible settings. http://www.tyan.com...
- Page 68 1’s in the data bits is odd. Mark: parity bit is always 1. Space: parity bit is always 0. Mark and Space parity do not allow for error detection. None / Even / Odd / Mark / Space http://www.tyan.com...
- Page 69 Disabled / Enabled Legacy OS Redirection Resolution On Legacy OS, the number of rows and columns supported redirection. 80x24 / 80x25 Putty KeyPad Select FunctionKey and KeyPad on Putty. VT100 / LINUX / XTERMR6 / SCO / ESCN / VT400 http://www.tyan.com...
- Page 70 ‘stop’ signal can be sent to stop the data flow. Once the buffers are empty, a ‘start’ signal can be sent to restart the flow. Hardware flow control uses two wires to send start/stop signal. None / Hardware RTS/CTS http://www.tyan.com...
- Page 71 Stop Bits Stop bits indicate the end of a serial data packet. (A start bit indicates the beginning). The standard setting is 1 stop bit. Communication with slow devices may require more than 1 stop bit. 1 / 2 http://www.tyan.com...
-
Page 72: Chipset Menu
3.4 Chipset Menu North Bridge North Bridge Parameters. South Bridge South Bridge Parameters. WatchDog Timer Configuration WatchDog Timer Configuration. http://www.tyan.com... - Page 73 3.4.1 North Bridge http://www.tyan.com...
- Page 74 Auto / 1 Way / 2 Way / 3 Way / 4 Way Rank Interleaving Select different Bank Interleaving setting. Auto / 1 Way / 2 Way / 4 Way / 8 Way Patrol Scrub Enable/Disable Patrol Scrub. Enabled / Disabled http://www.tyan.com...
- Page 75 Valid Offset 25 - 100. This is a percentage of the peak bandwidth allowed for OLTT. Altitude The system altitude above the sea level in meters. 300 M / Auto / 900 M / 1500 M / 3000 M http://www.tyan.com...
- Page 76 Allow to select Auto/Manual. When Auto option is selected PCI resource allocation across multiple IOHs is optimized automatically based on the PCI devices present. With Manual option user can force the PCI resource allocation across multiple IOHs based on the ratios selected. Auto / Manual http://www.tyan.com...
- Page 77 MMIOH Size Select number of 1GB contiguous regions to be assigned MMIOH space per CPU. 64G / 1G / 2G / 4G / 8G / 16G / 32G / 64G / 128G http://www.tyan.com...
- Page 78 Enable/Disable VT-d Engine Interrupt Remapping Support. Enabled / Disabled Coherency Support Enable/Disable VT-d Engine Coherency Support. Disabled / Enabled ATS Support Enable/Disable VT-d Engine Address Translation Services support. Disabled / Enabled Pass-through DMA Enable/Disable VT-d Engine Pass through DMA support. Enabled / Disabled http://www.tyan.com...
- Page 79 QPI Link Frequency Select Select the QPI Link Frequency. Auto / 6.4GT/s / 7.2GT/s / 8.0GT/s QPI LinkOs Enable/Disable QPI LinkOs. Enabled / Disabled QPI LinkOp Enable/Disable QPI LinkOp. Enabled / Disabled QPI Link1 Enable/Disable QPI Link1. Enabled / Disabled http://www.tyan.com...
- Page 80 3.4.1.3 DIMM Information Submenu Read only. http://www.tyan.com...
- Page 81 Restore AC Power Loss Specify what state to go to when power is re-applied after a power failure (G3 state). Power On / Power Off / Last State SLP_S4 Assertion Stretch Enable Enabled/Disabled SLP_S4# Assertion Stretch. Enabled / Disabled http://www.tyan.com...
- Page 82 Enable/Disable onboard SATA RAID option rom if Launch Storage OpROM is enabled. Enabled / Disabled High Precision Timer Enable/Disable the High Precision Event Timer. Enabled / Disabled Chassis Intrusion Detection Enabled: When a chassis open event is detected, the BIOS will display the event. Disabled / Enabled http://www.tyan.com...
- Page 83 Express Port 4 / PCI Express Port 5 / PCI Express Port 6 / PCI Express Port 7 / PCI Express Port 8 DMI Vc1 Control Enable/Disable DMI Vc1. Enabled / Disabled DMI Vcp Control Enable/Disable DMI Vcp. Enabled / Disabled DMI Vcm Control Enable/Disable DMI Vcm. Enabled / Disabled http://www.tyan.com...
- Page 84 Disabled / POST / OS / PowerON NOTE: Watch Dog Timer will appear when Watch Dog Mode is set to [Enabled]. Watch Dog Timer Watch Dog Timer Help. 2 MINS / 4 MINS / 6 MINS / 8 MINS / 10 MINS http://www.tyan.com...
-
Page 85: Boot
Quiet Boot Enable or disable Quiet Boot option. Disabled / Enabled Option ROM Messages Select display mode for Option ROM. Force BIOS / Keep Current Interrupt 19 Capture Enabled: allows Option ROMs to trap Int. 19. Enabled / Disabled http://www.tyan.com... - Page 86 Endless Boot Enable or disable Endless Boot. Disabled / Enabled Boot Option #1 Select the first boot device. Device Name / Disabled http://www.tyan.com...
-
Page 87: Security
Confirm New Password window will pop out to ask for confirmation. User Password Set user password in the Create New Password window. After you key in the password, the Confirm New Password window will pop out to ask for confirmation. http://www.tyan.com... -
Page 88: Server Management
3.7 Server Management Press <Enter> to change the SEL event log configuration. Enable/Disable interfaces to communicate with BMC. http://www.tyan.com... - Page 89 Choose options for reactions to a full SEL. No Nothing / Erase Immediately Log EFI Status Codes Disable the logging of EFI Status Codes or log only error code or only progress code or both. Both / Disabled / Error Code / Progress Code http://www.tyan.com...
- Page 90 3.7.2 BMC Network Configuration Configuration Address Source Select the configure LAN channel parameters statically or dynamically (by BIOS or BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. Unspecified / Static / Dynamic-Obtained by BMC http://www.tyan.com...
-
Page 91: Event Logs
3.8 Event Logs Read only. http://www.tyan.com... -
Page 92: Save & Exit
Save Options Read only. Save Changes Save changes done so far to any of the setup options. Discard Changes Discard changes done so far to any of the setup options. Restore Defaults Restore/Load Default values for all the setup options. http://www.tyan.com... - Page 93 Save as User Defaults Save the changes done so far as User Defaults. Restore User Defaults Restore the User Defaults to all the setup options. http://www.tyan.com...
- Page 94 NOTE http://www.tyan.com...
-
Page 95: Chapter 4: Diagnostics
BIOS flash failure, you must contact your dealer for a replacement BIOS. There are no exceptions. TYAN does not have a policy for replacing BIOS chips directly with end users. In no event will TYAN be held responsible for damages done by the end user. -
Page 96: Amibios Post Code (Aptio)
South Bridge initialization before microcode loading 0x05 OEM initialization before microcode loading 0x06 Microcode loading 0x07 AP initialization after microcode loading 0x08 North Bridge initialization after microcode loading 0x09 South Bridge initialization after microcode loading 0x0A OEM initialization after microcode loading 0x0B Cache initialization http://www.tyan.com... - Page 97 Memory initialization. Configuring memory 0x2F Memory initialization (other) 0x30 Reserved for ASL (see ASL Status Codes section below) 0x31 Memory Installed 0x32 CPU post-memory initialization is started. 0x33 CPU post-memory initialization. Cache initialization CPU post-memory initialization. Application Processor(s) (AP) 0x34 initialization http://www.tyan.com...
- Page 98 S3 Resume Progress Codes 0xE0 S3 Resume is started (S3 Resume PPI is called by the DXE IPL). 0xE1 S3 Boot Script execution 0xE2 Video repost 0xE3 OS S3 wake vector call 0xE4 – 0xE7 Reserved for future AMI progress codes http://www.tyan.com...
- Page 99 DXEIPL was not found. DXE Core Firmware Volume was not found. Recovery failed S3 Resume failed Reset PPI is not available. DXE Phase Status Code Description 0x60 DXE Core is started. 0x61 NVRAM initialization 0x62 Installation of the South Bridge Runtime Services http://www.tyan.com...
- Page 100 PCI Bus Hot Plug Controller initialization 0x94 PCI Bus Enumeration 0x95 PCI BUS Request Resources 0x96 PCI Bus Assign Resources 0x97 Console output devices connect 0x98 Console Input devices connect 0x99 Super IO initialization 0x9A USB initialization is started. http://www.tyan.com...
- Page 101 0xC0 – 0xCF OEM BDS initialization codes DXE Error Codes 0xD0 CPU initialization error 0xD1 North Bridge initialization error 0xD2 South Bridge initialization error 0xD3 Some of the Architectural Protocols are not available 0xD4 PCI resource allocation error. Out of Resources http://www.tyan.com...
- Page 102 System is waking up from the S3 sleep state. 0x40 System is waking up from the S4 sleep state. System has transitioned into ACPI mode. Interrupt controller is in 0xAC APIC mode. System has transitioned into ACPI mode. Interrupt controller is in 0xAA APIC mode. http://www.tyan.com...
-
Page 103: Appendix: Fan And Temp Sensors
(rpm) Temp Sensor: CPU1_MOS_Area, PCH_Area and PCI-E_Air_Inlet. They detect the system temperature around. NOTE: The system temperature is measured in a scale defined by Intel, not in Fahrenheit or Celsius. http://www.tyan.com... - Page 104 BIOS Temp Sensor Name Explanation: http://www.tyan.com...
- Page 105 Temperature of CPU1 DIMM C0 Slot CPU1_DIMM_C1 Temperature of CPU1 DIMM C1 Slot CPU1_DIMM_C2 Temperature of CPU1 DIMM C2 Slot CPU1_DIMM_D0 Temperature of CPU1 DIMM D0 Slot CPU1_DIMM_D1 Temperature of CPU1 DIMM D1 Slot CPU1_DIMM_D2 Temperature of CPU1 DIMM D2 Slot http://www.tyan.com...
- Page 106 NOTE http://www.tyan.com...
-
Page 107: Glossary
(reading to or writing from a disk drive a single time is much faster than doing so repeatedly) there is the possibility of losing your data should the system crash. Information in a buffer is temporarily stored, not permanently saved. http://www.tyan.com... - Page 108 (like soundcards or keyboards) to access the main memory without involving the CPU. This frees up CPU resources for other tasks. As with IRQs, it is vital that you do not double up devices on a single line. Plug-n-Play devices will take care of this for you. http://www.tyan.com...
- Page 109 EEPROM (Electrically Erasable Programmable ROM): also called Flash BIOS, it is a ROM chip which can, unlike normal ROM, be updated. This allows you to keep ® up with changes in the BIOS programs without having to buy a new chip. TYAN ’s BIOS updates can be found at http://www.tyan.com...
- Page 110 PXE (Preboot Execution Environment): one of four components that together make up the Wired for Management 2.0 baseline specification. PXE was designed to define a standard set of preboot protocol services within a client with the goal of allowing networked-based booting to boot using industry standard protocols. http://www.tyan.com...
- Page 111 NVIDIA s (graphics communications processing units) and NVIDIA MCPs (media and processors). application Depending on the , NVIDIA SLI can deliver as much as two times the performance of a single GPU configuration. http://www.tyan.com...
- Page 112 CPUs without damaging the sensitive CPU pins. The CPU is lightly placed in an open ZIF socket, and a lever is pulled down. This shifts the processor over and down, guiding it into the board and locking it into place. http://www.tyan.com...
-
