Page 1: Operation Manual
OPERATION MANUAL English SPLIT SYSTEM Air Conditioner Español MODELS (Ceiling suspension type) FH(Y)35BVE FH(Y)71BVE FH(Y)50BVE FH(Y)100BVE FH(Y)60BVE FH(Y)125BVE... - Page 2 Thank you for purchasing this Daikin air condi- tioner. Carefully read this operation manual before using the air conditioner. It will tell you how to use the unit properly and help you if any trouble occurs. After reading the manual, file it away for future reference.
-
Page 4: Table Of Contents
The unit is individually operated. NOTE 1. WHAT TO DO BEFORE OPERA- • Contact your Daikin dealer in case of changing TION the combination or setting of group control and two remote controller control systems. This operation manual is for the following systems with standard control. -
Page 5: Safety Considerations
The refrigerant in the air conditioner is safe 2. SAFETY CONSIDERATIONS and normally does not leak. If the refrigerant leaks inside the room, the contact with a fire We recommend that you read this instruction man- of a burner, a heater or a cooker may result in ual carefully before use to gain full advantage of the a harmful gas. -
Page 6: Operation Range
Neither place a flammable spray bottle near the air conditioner nor perform spraying. 3. OPERATION RANGE Doing so may result in a fire. To clean the air conditioner, stop operation, If the temperature or the humidity is beyond the fol- and unplug the power cord from the outlet. -
Page 7: Installation Site
Regarding drainage of drain piping D B: Dry bulb temperature WB: Wet bulb temperature • Is the drain piping executed to perform com- plete drainage? The setting temperature range of the remote con- If proper drainage is not carried out from the out- troller is 16°C to 32°C. -
Page 8: Operation Procedure
DISPLAY “ ” (FAN SPEED) • Operating procedure varies with heat pump type This display shows the set fan speed. and cooling only type. Contact your Daikin dealer DISPLAY “ ” (AIR FLOW FLAP) to confirm your system type. • To protect the unit, turn on the main power switch Refer to “ADJUSTING THE AIR FLOW... - Page 9 (a fan to circulate the air inside the A. UP AND DOWN DIRECTION room). For details, consult your dealer. • The movable limit of the flap is changeable. Con- tact your Daikin dealer for details. ADJUSTMENT For programming TEMPERATURE, FAN SPEED Press the AIR FLOW DIRECTION ADJUST...
-
Page 10: Optimum Operation
MOVEMENT OF THE AIR FLOW FLAP PROGRAMMING TIME For the following conditions, micro computer con- Press the PROGRAMMING TIME button and set trols the air flow direction so it may be different from the time for stopping or starting the system. the display. -
Page 11: Maintenance (For Service Personnel)
• Never place objects near the air inlet and the air Fig. 4 outlet of the unit. It may cause deterioration in the effect or stop in the operation. • Turn off the main power supply switch when it is not used for long periods of time. - Page 12 4. Fix the air filter. 5. Fix the air filter. Set the hatch of the air filter to the fook of the Refer to “HOW TO CLEAN THE AIR FILTER ”. suction grille, and fix the air filter. 6. Fix the suction grille. (Refer to Fig.
-
Page 13: Not Malfunction Of The Air Conditioner
If the inside of an indoor unit is extremely contam- inated, the temperature distribution inside a room becomes uneven. It is necessary to clean the inside of the indoor unit. Ask your Daikin dealer for details on cleaning the unit. This operation requires a qualified service person. -
Page 14: Trouble Shooting
• If direct sunlight enters the room (when cooling). Use curtains or blinds. • When there are too many inhabitants in the Measure: Notify your Daikin dealer and inform room (when cooling). him/her of the display. Cooling effect decreases if heat gain of the room is too large. -
Page 15: Specifications
