Selecting Options And Entering Data; Using The Status Bar - Garmin GPSMAP 60Cx Owner's Manual

Selecting Options and Entering Data

To enter data and select options, use the ROCKER to
highlight, select, or choose an item in a list or a field
on the screen.
To select and activate an option:
1. From any page, press MENU. An Options
Menu appears with a list of additional options
for that page.
2. Use the ROCKER to move the highlight up,
down, right, or left on the menu to highlight the
option you want, and press ENTER to select it.
To exit a menu or return to the previous
setting:
Press QUIT. The QUIT key moves backward
through your steps. Press QUIT repeatedly to
return to the starting page.

Using the Status Bar

At the top of each page, the status bar provides status
information for several unit features.
Status Bar
GPSMAP 60Cx Owner's Manual
• Power to the unit is provided by either batteries
or from an auxiliary source (AC, DC or USB
Adapter). The Battery Power icon (
the remaining power as the battery is depleted.
• The Auxiliary Power icon (
the unit is powered by an external source such
as the USB Data Cable provided with your
unit or optional Serial Data/Power Cable or
Cigarette Lighter Adapter.
• Satellite signal status is shown when searching
for or acquiring satellites (
( ) is attained and when a 3D fix (
attained (four or more satellites are received.)
• The Backlight icon (
backlight is on. Backlighting is off when
you turn the unit on. The Backlight uses a
significant amount of battery power.
• The USB Cable Connection icon (
appears when the unit is in communication with
a PC Universal Serial Bus.
G S >
ETTING TARTED
) shows
) appears when
), when a 2D fix
) is
) appears when the
)
7
