Parts Manual / Manuel de pièces / Manual de piezas
Single Stage, Belt Drive, Electric Air Compressor
D'une seule étape, actionnement pour courroie, compresseur d'air électrique
De una sola etapa, accionamiento por correa, compresor de aire eléctrico
Specification Chart____Tableau des spécifications___Cuadro de especificaciones
ITEM #
RUNNING
(ARTICLE)
H.P.
(ARTÍCULO)
(CV)
215921
1.6
?
Questions? See back pages.__Questions ? Consultez la pages final.__¿Preguntas? Vea la páginas final.
Printed in U.S.A.
TANK CAPACITY
GALLONS
(CAPACITÉ DU
RÉSERVOIR - LITRES)
(CAPACIDAD DEL
TANQUE - LITROS)
30 (114)
Item # / Article / Artículo
VOLTAGE/
KICK-IN
AMPS/PHASE
PRESSURE
(TENSION/
(PRESSION
AMPS/PHASE)
D'OUVERTURE)
(VOLTAJE
(PRESION DE
AMP/FASE)
CONEXION)
115/15/1
(8,62 bar)
215921
KICK-OUT
PRESSURE
(PRESSION DE
FERM.)
(PRESION DE
DESCONEXION)
125
155
(10,69 bar)
200-2625_ Rev B_5-07
Advertisement
Related Manuals for Kobalt 215921
Summary of Contents for Kobalt 215921
- Page 1 Item # / Article / Artículo 215921 Parts Manual / Manuel de pièces / Manual de piezas Single Stage, Belt Drive, Electric Air Compressor D’une seule étape, actionnement pour courroie, compresseur d’air électrique De una sola etapa, accionamiento por correa, compresor de aire eléctrico Specification Chart____Tableau des spécifications___Cuadro de especificaciones...
- Page 2 PARTS DRAWING / DESSIN DES PIÈCES / ESQUEMA DE LA PIEZAS NOTES: Torque to 130-180 lb-in. Torque to 20-30 lb-in. Serrez de 130 À 180 lbs-in. Serrez de 20 À 30 lbs-in. Torsión hasta 14,7-20,3 N•m Torsión hasta 2,3-3,4 N•m Note: Tighten compression nut Torque to 25-50 lb-ft.
- Page 3 PARTS LIST / LISTE DE PIÈCES / LISTA DE LAS PIEZAS Item Part No Article Qté Artículo Núm / P Cant Description Description Descripción 125-0175 Beltguard, outer ........Garant ..........Protector 103-0073 Fastener, 1/4 turn .......Attache ..........Sujetador 007-0010 V-Belt, 4L-460........Courroie ..........Correa 146-0016 Key............Clé...........Chaveta Setscrew, 5/16”-18......Vis d’arrêt ........Tornillo fajador 006-0018...
- Page 4 PARTS DRAWING / DESSIN DES PIÈCES / ESQUEMA DE LA PIEZAS 200-2625...
- Page 5 LPV5145 Pump Assy -- Ensemble du pompe -- Conjunto de bomba Item Part No Article Qté Artículo Núm / P Cant Description Description Descripción 145-0486 Tube, with compression nuts ........Tube ..................Tubo 065-0107 Elbow ................Coude ..................Codo Socket head cap screw, M6 x 40mm ......Vis....................Tornillo Washer, M6..............Rondelle ..................Arandela 042-0121 Head, cylinder .............Tête ..................Cabezal...
- Page 6 PARTS DRAWING / DESSIN DES PIÈCES / ESQUEMA DE LA PIEZAS NOTES: Torque to 125-150 lb-in. Serrez de 125 À 150 lbs-ft. Torsión hasta 14,1-17,0 N•m Note: Tighten compression nut handtight plus 1 full turn. Note: Serrez l'écrou de compactage solide plus 1 plein tour. Nota: Apriete la tuerca de la compresión handtight más 1vuelta completa.
-
Page 7: Parts And Service
PARTS AND SERVICE Replacement parts and service are available from your Attach your sales receipt at bottom right. nearest authorized Service Center. If the need arises, contact Product Service as listed at right. When needing service, please contact the nearest authorized Service Center or call: When consulting with a Service Center or Product Service, refer to the model number and serial number... - Page 8 DO NOT RETURN TO STORE! CALL US FIRST! IMPORTANT - Please Read Thank you for purchasing this product. This compressor was built to meet the highest quality standards and factory tested to assure satisfactory use. If you have any questions which are not addressed in the owner’s manual, or need service information, call us toll free at 1-866-307-4104.
