Parts Manual / Manuel de pièces / Manual de piezas
Single Stage, Belt Drive, Electric Air Compressor
D'une seule étape, actionnement pour courroie, compresseur d'air électrique
De una sola etapa, accionamiento por correa, compresor de aire eléctrico
Specification Chart____Tableau des spécifications___Cuadro de especificaciones
ITEM #
RUNNING
(ARTICLE)
H.P.
(ARTÍCULO)
(CV)
137603
4.5
?
Questions? See back pages.__Questions ? Consultez la pages final.__¿Preguntas? Vea la páginas final.
Printed in U.S.A.
TANK CAPACITY
GALLONS
(CAPACITÉ DU
RÉSERVOIR - LITRES)
(CAPACIDAD DEL
TANQUE - LITROS)
80 (302,8)
Item # / Article / Artículo
VOLTAGE/
KICK-IN
AMPS/PHASE
PRESSURE
(TENSION/
(PRESSION
AMPS/PHASE)
D'OUVERTURE)
(VOLTAJE
(PRESION DE
AMP/FASE)
CONEXION)
240/22/1
(8,62 bar)
137603
KICK-OUT
PRESSURE
(PRESSION DE
FERM.)
(PRESION DE
DESCONEXION)
125
155
(10,69 bar)
200-2663_ Rev A_5-07
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kobalt 137603
Summary of Contents for Kobalt 137603
- Page 1 Item # / Article / Artículo 137603 Parts Manual / Manuel de pièces / Manual de piezas Single Stage, Belt Drive, Electric Air Compressor D’une seule étape, actionnement pour courroie, compresseur d’air électrique De una sola etapa, accionamiento por correa, compresor de aire eléctrico Specification Chart____Tableau des spécifications___Cuadro de especificaciones TANK CAPACITY VOLTAGE/...
- Page 2 PARTS DRAWING / DESSIN DES PIÈCES / ESQUEMA DE LA PIEZAS NOTES: Torque to 40-65 lb-in. Serrez de 40 À 65 lbs-in. Torsión hasta 4,5-7,3 N•m Torque to 45-65 lb-in. Serrez de 45 À 65 lbs-in. Torsión hasta 5,1-7,3 N•m Torque to 70-80 lb-ft.
- Page 3 PARTS LIST / LISTE DE PIÈCES / LISTA DE LAS PIEZAS Item Part No Qté Núm / P Cant Description Description Descripción 145-0488 Transfer tube........Tube..........Tubo 058-0016 Compression nut ......Écrou de compression ....Tuerca de compressión 031-0060 Check valve .........Soupape ........Válvula 064-0003 Elbow ...........Coude ........Codo 145-0495 Bleeder tube.........Tube..........Tubo...
- Page 4 PARTS DRAWING / DESSIN DES PIÈCES / ESQUEMA DE LA PIEZAS 14CFM Pump Assembly NOTES: Torque to 9-12 lbs-ft Serrez de 9 À 12 lbs-ft Torsión hasta 12,2-16,3 N•m Torque to 14-16 lbs-ft Serrez de 14 À 16 lbs-ft. Torsión hasta 19,0-21,7 N•m Torque to 97 lb-in.
- Page 5 PARTS LIST / LISTE DE PIÈCES / LISTA DE LAS PIEZAS 14CFM Pump Assy -- Ensemble du pompe -- Conjunto de bomba Item Part No Qté Núm / P Cant Description Description Descripción Screw, M8 x 65 ........Vis ...........Tornillo Washer, M8 ........Rondelle ..........Arandela 042-0117 Head ...........Tête ..........Cabezal 019-0222...
- Page 6 PARTS DRAWING / DESSIN DES PIÈCES / ESQUEMA DE LA PIEZAS NOTES: Torque to 3-5 lb-in. Serrez de 3 À 5 lbs-in. Torsión hasta .34-,56 N•m Torque to 125-150 lb-in. Serrez de 125 À 150 lbs-ft. Torsión hasta ,14,1-17,0 N•m Torque to 20-30 lb-in.
- Page 7 PARTS AND SERVICE Replacement parts and service are available from your Attach your sales receipt at bottom right. nearest authorized Service Center. If the need arises, contact Product Service as listed at right. When needing service, please contact the nearest authorized Service Center or call: When consulting with a Service Center or Product Service, refer to the model number and serial number...
- Page 8 DO NOT RETURN TO STORE! CALL US FIRST! IMPORTANT - Please Read Thank you for purchasing this product. This compressor was built to meet the highest quality standards and factory tested to assure satisfactory use. If you have any questions which are not addressed in the owner’s manual, or need service information, call us toll free at 1-866-307-4104.
