Convection Fan Assembly - Maytag AMV6167BDS Repair Parts List Manual

Hide thumbs

Advertisement

Section:

CONVECTION FAN ASSEMBLY

No.
Part No.
Description
1
DE47-00030A
HEATER-CONVECTION
2
DE47-00031A
HEATER-CONVECTION
3
6021-001149
NUT-HEXAGON FLANGE
4
DE47-20029A
THERMOSTAT
5 N DE60-00032A
SPACER-BEARING;SMV9165,SILICON
6
DE60-40019A
WASHER-DOOR
7
DE61-00550A
BRACKET-AIR GUIDE
8
DE61-00602A
HOLDER-HEATER
9
DE61-00619A
HOLDER-BEARING
10
DE61-00690A
BRACKET-GUIDE
11 N DE61-00718A
BRACKET-CASING
12
DE62-00032A
ADIABATIC CASING
13
DE63-00176A
COVER-CASING
14
DE66-00137A
SHAFT-FAN
15
DE66-00155A
PULLEY-FAN CASING
16
DE66-10017A
BEARING-FAN
17 N DE69-00361A
BAND-RUBBER
*Color Code (-)=Not Shown
#=Series, Serial Prefix or Run No., N=Not Available
8
Series Qty
10
1
10
1
10
2
10
1
10
1
10
2
10
3
10
1
10
2
10
1
10
1
10
1
10
1
10
1
10
1
10
2
10
1
