Installation Instructions
Over the Range Microwave Oven
BEFORE YOU BEGIN
Read these instructions
completely
and carefully.
IMPORTANT
-- Save these instructions
for
local inspector's
use.
IMPORTANT
-- Observe
all governing
codes
and ordinances.
Note to Installer-
Be sure to leave these
instructions
with the Consumer.
Note to Consumer-
Keep these instructions for
future reference.
Skill
level - Installation
of this appliance
requires
basic mechanical
and electrical
skills.
Proper installation
is the responsibility
of the
installer.
Product failure due to improper
installation
is not
covered
under the Warranty.
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
