BODY/BLOWER MOTOR
No.
Part No.
Description
1
4713-001165
LAMP-HALOGEN
2
DE47-00032A
SOCKET-LAMP HALOGEN
3
DE96-00400A
ASSY NOISE FILTER;SN-UF12A,250
4
DE61-00493A
BRACKET-DUCT(U)
5
DE67-00177A
DUCT-UPPER
6
DE96-00557A
ASY-WIRE HARNESS C
7
DE60-30063A
NUT-MOUNTING
8
DE31-00028C
MOTOR VENTILATION
9
DE63-00367D
FILTER-CHARCOAL
10
DE96-00218A
ASSY-POWER CORD
11
DE92-90508A
ASSY-HOLDER NUT
-
DE97-00433A
ASSY-PANEL BACK;SMV9165,ASSY-A
12
DE64-01144A
PANEL-OUTER (BLK)
13 N DE71-60051A
COVER-DAMPER
14
DE72-40022A
DAMPER-MAIN
15
DE70-00378A
PLATE-MOUNTING
-
DE61-00525A
HOLDER-SENSOR
16
DE32-60011A
SENSOR-GAS
17
DE61-00486A
BRACKET-OVEN
18
DE97-00426A
ASSY-COVER ADIBATIC UPPER
19
DE67-00186A
DUCT-EXHAUST
20
DE31-00032A
MOTOR CONVECTION
21 N DE61-00601A
GUIDE-AIR (HEATER)
22
DE47-20007A
THERMOSTAT
23
DE64-01088A
GLASS-OVEN LAMP
24
DE97-00433A
ASSY-PANEL BACK;SMV9165,ASSY-A
25
DE66-00135A
PULLEY-FAN MOTOR
*Color Code (-)=Not Shown
#=Series, Serial Prefix or Run No., N=Not Available
6
Series Qty
10
1
10
1
10
1
10
1
10
1
10
1
10
2
10
1
10
1
10
1
10
1
10
1
10
1
10
1
10
1
10
1
10
1
10
1
10
1
10
1
10
1
10
1
10
1
10
1
10
1
10
1
10
1
