Configuring the USB Wireless Adapter with GXV3140
1.1
How to Enable Wifi Features
1.1.1
Configuring using the web configuration interface
Type the IP address of the GXV3140 (as shown on the phone LCD screen, see figure
1-1 below) in the URL bar of a web browser to log into the web configuration interface.
The user will be prompted for the login credentials. By default, the username and
password are both set to admin. (See figure 1-3 below).
Grandstream Networks, Inc.
http://www.grandstream.com
Figure 1-1
Figure 1-2
Configuring the USB Wireless Adapter with GXV3140
Page 1 of 7
Updated 12/2009

Advertisement

loading

Related Manuals for Grandstream Networks GXV3140

Summary of Contents for Grandstream Networks GXV3140

  • Page 1 1.1.1 Configuring using the web configuration interface Type the IP address of the GXV3140 (as shown on the phone LCD screen, see figure 1-1 below) in the URL bar of a web browser to log into the web configuration interface.
  • Page 2 If users are not using the Wifi function, please leave it as the default setting. Wireless Mode: The setting used to configure the GXV3140 wireless mode. These are the modes supported: 802.11b/g, 802.11b, 802.11g, 802.11n, 802.11g/n, 802.11 b/g/n.
  • Page 3 “Wifi” (see figure 2-4). Configure the Wifi settings and press F3 to save the settings. Figure 2-1 Figure 2-2 Grandstream Networks, Inc. Configuring the USB Wireless Adapter with GXV3140 Page 3 of 7 http://www.grandstream.com Updated 12/2009...
  • Page 4 Key: The key configured for the wireless network, should be corresponding to the key configured on the wireless router. Show Pwd：If selected, the password will be shown in plain text. Grandstream Networks, Inc. Configuring the USB Wireless Adapter with GXV3140 Page 4 of 7 http://www.grandstream.com Updated 12/2009...
  • Page 5 When the Wifi functions is enabled, plug the 802.11n Wifi USB dongle into the USB port on the GXV3140. After 10-15 seconds, when the USB Wifi dongle has successfully connected to the phone, the small icon will be shown on the phone LCD...
  • Page 6 Wifi network in a few seconds. Users can also configure the keys from the web configuration interface (see figure 4-4 below). Grandstream Networks, Inc. Configuring the USB Wireless Adapter with GXV3140 Page 6 of 7 http://www.grandstream.com...
  • Page 7 Figure 4-3 Figure 4-4 Grandstream Networks, Inc. Configuring the USB Wireless Adapter with GXV3140 Page 7 of 7 http://www.grandstream.com Updated 12/2009...
