REQUIRED TOOLS
AND MATERIALS:
• 2 People
• Tape Measure
• Wood Board
(scrap)
• Sawhorse or
Support Table
• Safety Glasses
• Step Ladder - 8ft.
(2.4 m)
• (2 each) Wrenches and/or Socket
Wrenches and Sockets (Deep-
Well Sockets are Recommended).
• Extension is Recommended.
7/16"
1/2"
9/16"
3/4"
AND/OR
7/16"
1/2"
9/16"
3/4"
• Garden Hose or Sand
OPTIONAL TOOLS
AND MATERIALS:
•
Large and Small Adjustable
Wrenches
© COPYRIGHT 2005 by SPALDING
Portable Basketball System
Owners Manual
Customer Service Center
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
WARNING!
READ AND UNDERSTAND
OPERATOR'S MANUAL
BEFORE USING THIS UNIT.
FAILURE TO FOLLOW
OPERATING
INSTRUCTIONS COULD
RESULT IN INJURY OR
DAMAGE TO PROPERTY.
Toll-Free Customer Service Number for U.S: 1-800-558-5234,
For Canada: 1-800-284-8339,
For Europe: 00 800 555 85234 (Sweden: 009 555 85234),
For Australia: 1-800-632 7921
Internet Address: http://www.huffysports.com
1
Write Model Number
From Box Here:
11/05
ID# M730131
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Huffy M730131
Summary of Contents for Huffy M730131
-
Page 1: Owners Manual
Toll-Free Customer Service Number for U.S: 1-800-558-5234, For Canada: 1-800-284-8339, For Europe: 00 800 555 85234 (Sweden: 009 555 85234), • Large and Small Adjustable For Australia: 1-800-632 7921 Wrenches Internet Address: http://www.huffysports.com 11/05 ID# M730131 © COPYRIGHT 2005 by SPALDING... -
Page 2: Safety Instructions
Failure to follow instructions could result in SERIOUS INJURY. It is NOT acceptable to devise a makeshift weight system. IMPORTANT! Remove all contents from boxes. Be sure to check inside pole sections, hardware and additional parts are packed inside. ID# M730131 11/05... -
Page 3: Height Adjustment
• Use extreme caution if placing system on sloped surface. System may tip over more easily. In the U.S.: 1-800-xxx-xxxx In the U.S.: 1-800-xxx-xxxx Canada: 1-800-xxx-xxxx Canada: 1-800-xxx-xxxx In the U.S.: 1-800-xxx-xxxx In the U.S.: 1-800-xxx-xxxx Canada: 1-800-xxx-xxxx Canada: 1-800-xxx-xxxx ID#: 556790 01/05 11/05 ID# M730131... -
Page 4: Before You Start
RESULT IN SUDDEN BREAKAGE. IF BACKBOARD IS DAMAGED IN ANY WAY PRIOR TO OR AFTER ASSEMBLY, CALL TOLL-FREE NUMBER: U.S. 1-800-558-5234; CANADA: 1-800-284-8339; http://www.huffysports.com WARRANTY CARD: Please remember to complete your product registration form either on-line at: www.huffysports.com/customer_support/product_registration or mail-in the enclosed postcard. ID# M730131 11/05... - Page 5 Get to know the basic parts of your basketball system... FRONT VIEW BACKBOARD ELEVATOR ADJUSTMENT POLE SUPPORT STRUT BASE 11/05 ID# M730131...
- Page 6 Plug Cap 201257 Label, Height Adjustment and Moving HARDWARE IDENTIFIER (BOLTS AND SCREWS) Item #32 (2) Item #8 (1) Item #36 (5) Item #11 (1) Item #15 (2) Item #35 (1) Item #31 (4) Item #34 (1) ID# M730131 11/05...
- Page 7 Item #16 (8) Item #39 (5) HARDWARE IDENTIFIER (STEEL SPACERS) Item #33 (2) HARDWARE IDENTIFIER (PLASTIC SPACERS, CAPS, CLIPS AND OTHER) Item #30 (1) Item #17 (4) Item #20 (1) Item #23 (4) Item #7 (1) Item #39 (1) 11/05 ID# M730131...
-
Page 8: Section A: Assemble The Base
(2) 1/2” and (2) 9/16" Wrenches AND/OR (2) Socket Wrenches and Sockets 1/2” 9/16” Correctly identify each pole section. Poles have an identification sticker that will be used as a reference point in the next step. IDENTIFICATION STICKER MIDDLE BOTTOM ID# M730131 11/05... - Page 9 IMPORTANT! Align dimple of top pole section (4) into trough of middle pole section (5) as shown. pole middle Trough 5” (12.7 cm) Dimple pole middle 1.5” ID Sticker (3.81 cm) Dimple HOLE Wood Scrap (NOT SUPPLIED) 11/05 ID# M730131...
- Page 10 3-1/2" (9 CM) MINIMUM OVERLAP. IMPORTANT! Align dimple of middle pole section (5) into trough of bottom pole section (6) as shown. Dimple Trough 1.5” (3.81 cm) Bottom pole 5” (12.7 cm) ID Sticker Bottom pole Wood Scrap (NOT SUPPLIED) ID# M730131 11/05...
- Page 11 TWO PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. IMPORTANT! DO NOT OVER TIGHTEN IMPORTANT! THE SPACER (17) WILL FIT LOOSELY UNTIL SECURED INTO THE CAVITY OF THE BASE. 11/05 ID# M730131...
- Page 12 (10) as shown. TIGHTEN BOLT (11) IN LOCK NUT (13) UNTIL FLUSH (EVEN) WITH LOCK NUT’S OUTER EDGE. Secure tank struts (10) to the base using bolt (15), washers (12), and nut (16). ID# M730131 11/05...
-
Page 13: Section B: Attach The Backboard
Fit spacer (33) into pawl (27). Then continue to assemble as shown. Tighten completely. IMPORTANT! Test fit bolts into holes of backboard brackets (29) and carefully rock them in a circular motion to ream out paint from holes if necessary. 11/05 ID# M730131... - Page 14 BROOM HANDLE IMPORTANT! Test fit bolts into holes of backboard brackets (29) and carefully rock them in a circular motion to ream out paint from holes if necessary. ID# M730131 11/05...
- Page 15 Secure pawl (27) in place with clevis pin (30) and washers (18) as shown. Stretch spring (37) into position with pliers. WARNING! EOPP03.EPS 205612 USE EYE PROTECTION WHEN INSTALLING SPRINGS. EOPP04.EPS 205612 11/05 ID# M730131...
- Page 16 (29) to line up with holes in backboard and secure with bolts (32) and nuts (16). Tighten completely. WARNING! TWO PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. ID# M730131 11/05...
- Page 17 Support pole on sawhorse. Attach upper and lower elevator tubes (38) to upper pole section (4) using bolts (36) and nuts (39) as shown. Attach pole cap (22) as shown. EOPP211997.EPS WARNING! TWO PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. 11/05 ID# M730131...
- Page 18 2 GALLONS OF ANTI-FREEZE IS NOT REQUIRED. WARNING! DO NOT LEAVE ASSEMBLY UNATTENDED WHEN EMPTY; IT MAY TIP OVER. WARNING! TWO PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. ID# M730131 11/05...
- Page 19 Install net (26) as shown. Apply the height adjustment and moving label (25) to the front of the pole as shown. WARNING! DO NOT ALLOW CHILDREN TO ADJUST HEIGHT. 10 ft. (3.05 m) 11/05 ID# M730131...
