REQUIRED TOOLS
AND MATERIALS:
• 2 People
• Tape Measure
• Step Ladder - 8ft.
(2.4 m)
• (2 each) Wrenches
and/or Socket Wrenches
and Sockets (Deep-Well
Sockets are
Recommended).
1/2"
AND/OR
1/2"
• Extension is
Recommended.
OPTIONAL TOOLS
AND MATERIALS:
• Large and Small
Adjustable Wrenches
© COPYRIGHT 2005 by HUFFY SPORTS
A DIVISION OF RUSSELL CORPORATION
Backboard and Rim
Owners Manual
Customer Service Center
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
WARNING!
READ AND UNDERSTAND
OPERATOR'S MANUAL
BEFORE USING THIS UNIT.
FAILURE TO FOLLOW
OPERATING INSTRUCTIONS
COULD RESULT IN INJURY
OR DAMAGE TO
PROPERTY.
Toll-Free Customer Service Number for U.S: 1-800-558-5234,
For Canada: 1-800-284-8339,
For Europe: 00 800 555 85234 (Sweden: 009 555 85234),
For Australia: 1-800-632 7921
Internet Address: http://www.huffysports.com
1
CAUTION:
THIS BACKBOARD AND GOAL ARE NOT DESIGNED TO
SUPPORT A PLAYER HANGING FROM THE GOAL OR NET.
FAILURE TO OBSERVE THIS CAUTION MAY CAUSE
BODILY INJURY AND / OR PROPERTY DAMAGE.
Write Model Number
From Box Here:
05/05
ID#
M800001
