Page 1: Lcd Display
4-430-596-11 (1) LCD Display Instructions for Use Before operating the unit, please read this manual thoroughly and retain it for future reference. LMD-DM30C LMD-DM20C © 2012 Sony Corporation... - Page 2 Refer servicing to qualified personnel If you have any questions about this product, you may only. call; No modification of this apparatus is allowed. Sony Customer Information Service Center 1-800-222- 7669 or http://www.sony.com/ WARNING Declaration of Conformity THIS APPARATUS MUST BE EARTHED.
- Page 3 For the customers in Europe WARNING on power connection The manufacturer of this product is Sony Corporation, Use a proper power cord for your local power supply. 1-7-1 Konan, Minato-ku, Tokyo, 108-0075 Japan. 1. Use the approved Power Cord (3-core mains lead) /...
- Page 4 Warning The use of accessories and cables other than those specified, with the exception of replacement parts sold by Sony Corporation, may result in increased emissions or decreased immunity of the LMD-DM30C/DM20C. Guidance and manufacturer’s declaration-electromagnetic emissions The LMD-DM30C/DM20C is intended for use in the electromagnetic environment specified below.
- Page 5 Guidance and manufacturer’s declaration - electromagnetic immunity The LMD-DM30C/DM20C is intended for use in the electromagnetic environment specified below. The customer or the user of the LMD-DM30C/DM20C should assure that it is used in such as environment. IEC 60601 test Immunity test Compliance level Electromagnetic environment - guidance...
- Page 6 Guidance and manufacturer’s declaration - electromagnetic immunity The LMD-DM30C/DM20C is intended for use in the electromagnetic environment specified below. The customer or the user of the LMD-DM30C/DM20C should assure that it is used in such as environment. IEC 60601 test Immunity test Compliance level Electromagnetic environment - guidance...
- Page 7 Recommended separation distances between portable and mobile RF communications equipment and the LMD- DM30C/DM20C The LMD-DM30C/DM20C is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the LMD-DM30C/DM20C can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (Transmitters) and the LMD-DM30C/DM20C as recommended below, according to the maximum output power of the communications equipment.
-
Page 8: Table Of Contents
Table of Contents Precaution .............. 9 On Safety ............9 On Installation ............ 9 About the LCD Panel ......... 9 Protective Filter ..........9 On Burn-in ............9 On Long Periods of Use ........10 On Cleaning ............. 10 Disposal of the Unit ......... 10 Recommendation to Use More Than One Unit ............ -
Page 9: Precaution
• Do not leave the LCD screen facing the sun as it can Precaution damage the LCD screen. Take care when you place the unit by a window. • Do not push or scratch the LCD screen. Do not place a heavy object on the LCD screen. -
Page 10: On Long Periods Of Use
The surface is very delicate. Do not rub or hit accumulation inside the unit may cause fire or electric with hard objects. shock. Have an authorized Sony dealer clean the unit’s interior at least once a year. Disposal of the Unit About this manual •... -
Page 11: Features
To display the resolutions above, an appropriate The LCD panel can also be used in portrait orientation. graphics card is required. Hardware-based pivoting is, unlike graphics card- or For details, consult your Sony dealer. software-dependent pivoting, much faster with less noise. High luminance, high contrast... -
Page 12: Location And Function Of Parts And Controls
Standby Blinking amber Advanced power save mode Blinking amber Error detected. Turn off the unit twice and consult your Sony dealer. Blinking amber Error detected. Turn off the unit three times and consult your Sony dealer. c LCD luminance sensor Monitors the LCD luminance. -
Page 13: Rear Panel
Rear Panel a + (plus) button Press to display the information (or present operating state) screen. (page 18) b – (minus) button Press to display the information (or present operating state) screen. (page 18) DOWN (USB downstream) ports (×2) Connect the calibration sensor supplied with the optional calibration kit. -
Page 14: Adjusting The Stand Height
Flip the tool down towards “LOCK” to lock. Adjusting the Stand Note Height For your safety, make sure the tilt stand is locked after adjusting the stand height. The tilt stand is locked at the factory. Follow the instructions below to adjust the stand height. Press the tip of the metal rod tool until it clicks. -
Page 15: Removing The Connector Cover
Removing the Connecting the Cables Connector Cover Turn off the computer. Unlock the slide latch on the connector cover. Connect the supplied DVI cable between the unit’s DIGITAL (DVI input) connector and the Slide the connector cover to the side to remove. computer’s DVI output connector. -
Page 16: Routing The Cables
Secure the cables along the groove at the rear of the Routing the Cables tilt stand, and put the cable cover back in place. Follow steps 3 and 4 to attach the cable cover. The cables can be stowed along the tilt stand under the cable cover. -
Page 17: Adjusting The Lcd Panel Angle
Adjusting the LCD Panel Switching the LCD Panel Angle Orientation The LCD panel turns approx. 70° sideways, approx. 3° The LCD panel is locked in portrait orientation when downward, and approx. 17° upward. packed at the factory. Hold the LCD panel with both hands and adjust the Follow the instructions below to switch the LCD panel angle slowly. -
Page 18: Displaying The Information Screen
Rotate the LCD panel 90°. Displaying the Information Screen Press the + or – button on the rear panel of the unit so that the information screen appears. Pressing either button repeatedly changes the display as follows: Information t present operating state t display off. -
Page 19: Changing The Display Setting
Press and hold the + and – buttons simultaneously Changing the Display for more than 2 seconds. The SWITCHING EDID screen appears. Setting From the on-screen menu, you can change the three settings below. For detailed instructions on each setting, see the following pages. -
Page 20: Switching Configuration Data
Press either the + or – button on the rear panel. change, press and hold the + and – buttons simultaneously for more than 2 seconds after The information (or present operating state) screen moving the cursor. appears. • The setting change will be canceled if there is no Pressing either button repeatedly changes the menu operation for more than 15 seconds. - Page 21 Press either the + or – button to move the B Note (cursor), and select a configuration number. To set and save configurations other than above, the optional calibration kit is required. Switching configuration data Press either the + or – button on the rear panel. The information (or present operating state) screen appears.
-
Page 22: Operating The Menu With No Image Input
To set the function Operating the Menu with Use the screensaver function (equipped with a calibration kit) for use with Windows. No Image Input If no signal is input, the unit usually enters the standby mode due to the power management function. Normal power can be temporarily restored for menu operations by the following method. -
Page 23: Using A Usb Hub
Connect the supplied USB cable between the 1st Using a USB Hub unit’s UP (USB upstream) port and the computer’s USB down (USB downstream) port. Connect the supplied USB cable between the 1st The unit has a USB hub. Connect the supplied USB unit’s DOWN (USB downstream) port and the cable between the unit and the computer. -
Page 24: Connector Pin Assignment
DisplayPort Connector Pin DisplayPort receptacle connector Assignment DIGITAL DVI 24-pin (female) connector Pin number Functions ML_Lane 3(n) ML_Lane 3(p) ML_Lane 2(n) Pin number Functions ML_Lane 2(p) TMDS Data 2– ML_Lane 1(n) TMDS Data 2+ TMDS Data 2/4 Shield ML_Lane 1(p) TMDS Data 4–* ML_Lane 0(n) TMDS Data 4+*... - Page 25 DOWN (USB) USB A-type receptacle connector Pin number Functions –DATA +DATA Available display resolution LMD-DM30C LMD-DM20C Fv = 60 Hz US TEXT US TEXT 640 × 480 640 × 480 800 × 600 800 × 600 1024 × 768 1024 × 768 1280 ×...
-
Page 26: Troubleshooting
Troubleshooting Check the following chart before consulting your Sony dealer. Symptom Cause and Solution The unit will not turn on. • Make sure the unit is plugged in (page 15). (The LED indicator is off.) • Check if the ?/a (power) switch is turned on. -
Page 27: Attaching An Arm Stand
ISO M4 × 10 (Originally used) Below 1.5 mm ISO M4 × 8 Sony is not liable for any damage or injury resulting from changing stands. How to attach an arm stand Place a soft cloth or cushioning material over a stable, even surface. -
Page 28: Anti-Theft Security Slot
Anti-Theft Security Slot Specifications Picture performance The unit is equipped with a security slot supported by MicroSaver Security Lock System by Kensington Panel a-Si TFT Active Matrix LCD Technology Group. MicroSaver locks are available at Picture size (diagonal) PC supply stores. inches Effective picture size (H ×... - Page 29 USB hub UP stream (×1) Note DOWN stream (×2) Always verify that the unit is operating properly before use. SONY WILL NOT BE LIABLE FOR General DAMAGES OF ANY KIND INCLUDING, BUT NOT LIMITED TO, COMPENSATION OR Power requirements REIMBURSEMENT ON ACCOUNT OF THE LOSS AC 100 V to 240 V, 50/60 Hz, 1.5 A to...
-
Page 30: Dimensions
Side (landscape) Dimensions Front (portrait) 38.7 (1 95.5 (3 Unit: mm (inches) 367 (14 Side (portrait) 220 (8 Front (landscape) 474 (18 Dimensions... - Page 31 Sony Corporation...
