"Protect Yourself And Your Investment"
OWNER'S MANUAL
MODEL: C-4SRS
COPYRIGHT: OMEGA RESEARCH & DEVELOPMENT 1999
Introduction
Welcome to the convenience and security offered by your new vehicle security
system. This system is designed and manufactured by Omega Research and
Development, a world leader in vehicle convenience and security since 1975. Your
system offers easy, carefree operation, and the modular design allows its many
impressive features to be customized to suit your needs
Therefore, please note that this guide is written to reflect:
-
that a power doorlock interface is installed with your system. This interface may
vary from one vehicle to the other, and in some cases may involve optional
components.
-
that the optional electronic siren for the audible output is used in place of the
option of using the vehicle's horn. This Guide's use of "chirp" applies to both.
-
the Programmable Features in the default settings; the operations of these
features, if selected otherwise, are also explained in detail.
The addition of an optional sensor also affects the exact operations, as several types
of auxiliary threat-detection sensing devices are available.
This sophisticated, state-of-the-art product deters theft of your vehicle, and its
contents, and can provide remote control convenience in operating the door locks,
trunk release, and engine starting. This system is designed for professional
installation.
Page - 3
Introduction
Remote Transmitter, LED Status Light & Valet Switch
Active Arming & Arming Bypass ..............................................................................
Passive Arming ........................................................................................................
Disarming .................................................................................................................
The Armed System .................................................................................... 9-10
.........................................................................................................
Selectable Code Override ..................................................................................
Remote Panic .......................................................................................... 14-15
Remote Starting ....................................................................................... 15-18
Option Output and Additional Output ........................................................ 18-19
The LED Status Light
System Status, ATV
Audible and Visual Indicators ................................................................... 21-24
Shock Sensor Port with Prewarn ................................................................... 25
Programming Transmitters ....................................................................... 25-28
Programming Features ............................................................................. 28-31
Programming Features Checklist ...................................................... Centerfold
Programmable Features ........................................................................... 32-43
Limited Lifetime Warranty ............................................................... Back Cover
Your system has three principal user components: the Remote Transmitter, the
red LED Status Light and the Valet Switch.
The Remote Transmitter: Each system is capable of being operated by up to four
different remote transmitters. The remote transmitter has four push-button switches,
each being labeled as to function. These are:
-
The LOCK button arms the security system, which also locks the doors. This
button can also operate an additional "option" output.
-
The UNLOCK button disarms the security system, unlocking the doors. This
operation can be configured to unlock the driver's door only upon one press of the
button; then, if desired, all of the doors upon a second press of the button.
-
The OPTION button is used to silently arm or disarm the system, and can also
operate an additional remote control function such as trunk release.
-
The PANIC button is used to easily engage and disengage the panic feature.
-
Pressing both the LOCK and UNLOCK buttons together for 2 seconds activates
the remote starting feature.
The Red LED Status Light: Informs you at a glance of the different conditions the
security system is in and also serves as a visual deterrent to break-ins and theft.
The Valet Switch: Is used to access Valet Mode, which allows the operator to
suspend some of the system's normal functions. The valet switch may also be used,
instead of the remote transmitter, to override an armed and activated system.
..................
) ................................ 5
TM
& Zone Violation ......................
Page - 4
3-4
6-7
7-8
8-9
11-12
12-14
19-21
