RS-X70
Quick Reference - Installation Overview
Choose a discreet mounting location for the module and locations
1
for any accessories (siren, sensors, interface module, etc.). Do not
mount the module yet
Identify vehicle connection points and plan harness routing from
your mounting location. Avoid any moving vehicle parts or parts that
2
generate heat. Also avoid any sharp metal edges. See wiring details
on pages 3-9.
Cut system wires to length, prep your harnesses, and make all wire
connections to the vehicle.
3
NOTE: DATA/MUX WIRES ARE SENSITIVE and MUST BE SPLICED DIRECTLY.
QUICK TAPS ARE NOT RECOMMENDED.
If you are using either of the system's data ports for accessories
4
or modules using DBI protocol, connect these modules now and
configure them for DATA MODE.
Perform VEHICLE LEARN (see pages 7 and 10 for instructions).
This automatically matches the IGN/ACC/START outputs to the vehicle's ignition switch,
5
auto-detects data protocols, chooses the best engine detection method, decides whether
neutral safety circuit is required, and allows you to quickly set engine and transmission
types. FASTER THAN PROGRAMMING!
6
Test the system for all functions.
7
Secure the module(s) and harnesses to the vehicle.
8
Reassemble the vehicle.
9
Test the system for all functions again
WIRE DIAGRAM: CENTER OF THIS BOOKLET
FEATURE CHART: BACK COVER
V1.3 INSTALLATION GUIDE
(you might anger the install gods)
.
(keep the install gods happy)
.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Omega Excalibur RS-X70
Summary of Contents for Omega Excalibur RS-X70
- Page 1 REMOTE START & SECURITY PERFECTED RS-X70 V1.3 INSTALLATION GUIDE Quick Reference - Installation Overview Choose a discreet mounting location for the module and locations for any accessories (siren, sensors, interface module, etc.). Do not mount the module yet (you might anger the install gods) Identify vehicle connection points and plan harness routing from your mounting location.
-
Page 2: Table Of Contents
Table Of Contents Installation Considerations ..............3 6 Pin Main Wire Harness ................. 3 Red & Red/White Wires - Constant Power (+) Input ......3 Pink Wire - IGNITION/ACC/START (+) Input/Output ......3 Orange Wire - ACCESSORY/IGN/START (+) In/Out ......4 Violet Wire - Start (+) Input/Output ............ -
Page 3: Installation Considerations
Installation Considerations BEFORE STARTING THE INSTALLATION, READ THIS ENTIRE MANUAL TO DETERMINE INSTALLATION REQUIREMENTS • VERIFY EACH CIRCUIT WITH A DIGITAL MULTIMETER • IDENTIFY REQUIRED CIRCUITS FOR THE VEHICLE • TAPE OFF OR REMOVE ANY UNUSED WIRING TO PREVENT POSSIBLE SHORT CIRCUITS •... -
Page 4: Orange Wire - Accessory/Ign/Start (+) In/Out
6 Pin Main Wire Harness (cont’d) ORANGE WIRE - ACCESSORY/IGN/START (+) IN/OUT This circuit is designed to power additional IGNITION, ACCESSORY, or START circuits. By default, it functions as an ACCESSORY output & turns on when remote start is activated (slightly earlier than the ignition output), turns off during engine cranking, &... -
Page 5: Black/White Wire - Neutral Safety (-) Input
14 Pin Secondary Wire Harness (cont’d) BLACK/WHITE WIRE - NEUTRAL SAFETY (-) INPUT REQUIRED. This input is a critical safety circuit which allows remote start opera- tion whenever the gear selector is in park or neutral (automatic transmission), or when the parking brake is applied (manual transmission). Remote start will not oper- ate unless this wire sees chassis ground. - Page 6 Wiring Overview Diagram 14 PIN HARNESS Remote Start Activation (-) In - WHITE/BLUE Starter Interrupt (-) Out - ORANGE Alarm Ign. Control (+) - YELLOW Flashing Light (-) Out - WHITE/BLACK OEM Arm (-) Out - LT. GREEN/RED Trunk Release/CH2 (-) Out - RED/WHITE System Ground (-) In - BLACK OEM Disarm (-) Out - LT.
- Page 7 TEMPERATURE SENSOR 4 PIN DOOR LOCK PORT Lock (-) Out - GREEN Constant 12v (+) Out - PIN Unlock (-) Out - BLUE WINDOW-MOUNT ANTENNA MODULE Status Light Valet / Programming Button 3 PIN SAT. RELAY PORT (RED) Start (-) Out - GREEN Constant 12v (+) Out - RED Status (-) Out - BLUE...
-
Page 8: Pin Secondary Wire Harness (Cont'd)
14 Pin Secondary Wire Harness (cont’d) MANUAL TRANSMISSION CONNECTION: The Gray wire also serves as a door pin input (must see all doors) which is required to perform the “manual transmission setup procedure” (detailed in the operation guide). Diode isolate the hood input from the door input using two 1 or 2 amp diodes facing the cathodes (stripes) towards the vehicle wires. -
Page 9: Pin Satellite Relay Port (Red)
CENTER PIN (EMPTY) - CONSTANT (+) OUTPUT This output provides a 500mA positive output to drive the positive pin of added relay coils. It is used for Omega prewired doorlock interfaces. BLUE WIRE - UNLOCK (-) OUTPUT This provides a 0.8 second 250mA negative pulse for any unlocking operations. -
Page 10: Window Mount Antenna Module
Window Mount Antenna Module Be sure to clean the glass before adhering the antenna. Mount it high in the windshield avoid- ing metal parts of the vehicle . Metal based window tint can decrease performance. Route the harness to the antenna module avoiding sharp objects that could compromise the harness jacket. 3D Motion Sensor Some models are equipped with a motion sensor that provides added protection for remote start by shutting down the engine if motion is detected during the START output. -
Page 11: Tach Programming
A matrix of all programmable features and their options are on the next page. For feature explanations, refer to the operation manual. Use the procedure below to make changes. NOTE: You can program features via your computer with Omega Weblink. Visit www.omegaweblink.com for more information Step 1 Turn the ignition key “ON”, then “OFF”... - Page 12 User Feature Programming: Ignition on, off, press valet 5 times Lock + Trunk Lock Button Unlock button Trunk button Start button # Feature Unlock + Start (Brake 1x) (Brake 2x) (Brake 3x) (Brake 4x) (Brake 5x) (Brake 6x) 1 Remote Start Run Time 3 min 10 min 15 min...
