PRIMERGY T850
System Configurator and Order Information Guide
October 2003
Contents
Instructions
Configuration diagram
Configurator
0
System software
I
Basic unit
II
III
Memory
IV
V
VI
VII SCSI / Fibre Channel controller
IX
X
XI
XV Communikation / Network for PCI Extension Box
XVI Communikation / Network for PCI Extension Box
PRIMERGY Server

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu PRIMERGY T850

Summary of Contents for Fujitsu PRIMERGY T850

  • Page 1: Table Of Contents

    PRIMERGY T850 System Configurator and Order Information Guide October 2003 Contents Instructions Configuration diagram Configurator System software Basic unit Processor Memory Graphics Accessible drives Hard disk drives VII SCSI / Fibre Channel controller VIII Disk Array Communication / Network System Management Products (RemoteView)
  • Page 2 System configurator and order-information guide PRIMERGY T850 Status 2003-09-23 Instructions This document contains basic product and configuration information that will enable you to configure your system via PC-/ SystemArchitect. Only these tools will ensure a fast and proper configuration of your PRIMERGY server or your complete PRIMERGY Rack system.

  • Page 3: Processor

    System configurator and order-information guide PRIMERGY T850 Status 2003-09-23 Configuration diagram PRIMERGY T850 TOP VIEW FRONT/REAR VIEW System unit ( I ) 1st System Board 2nd System Board Xeon MP Xeon MP Xeon MP Xeon MP Xeon MP Xeon MP...
  • Page 4 System configurator and order-information guide PRIMERGY T850 Status 2003-09-23 Start "PRIMERGY T850" SW Configurator with OEM-Software without OEM-Software for PRIMERGY Server for PRIMERGY Server Later use of OEM operating system Microsoft does not allowe software is not allowed, Vmware-Software the use of OEM-software apart from OEM software by - ESX Server 1.5 (OEM)
  • Page 5 3. Power cord Software: - ServerStart packet incl. ServerBooks CD, ServerSupport CD and ServerView Mounting kit for PRIMERGY T850 is part of the basic unit - 1 pair of telescopic rails (710-815mm) - 1 pair of carrier rails - 1 bracket PC-Rack - 1 cable management PC-racks Mounting kit for mounting of servers in in FSC 19"...
  • Page 6 System configurator and order-information guide PRIMERGY T850 Status 2003-09-23 Rack Basic Unit (4U), 8-way Rack Basic Unit (4U), 4-way including 2x Xeon MP processor including 2x Xeon MP processor 2 system boards 1 system board upgradable to 8 CPUs upgradable to 4 CPUs...
  • Page 7 Status 2003-09-23 Section Processor The PRIMERGY T850 can carry up to 2 system boards. The basic units include either one or two system boards. Please note that the basic units already includes two processors. Each system board requires at least 1 processor can be upgraded to max. 4 processors.
  • Page 8 System configurator and order-information guide PRIMERGY T850 Status 2003-09-23 Section Memory There are 16 memory slots available (4 banks with 4 modules each) on each system board. Mixing different modules within a bank is not support, therefore only complete banks with 4 modules are offered...
  • Page 9 System configurator and order-information guide PRIMERGY T850 Status 2003-09-23 Section Accessible Drives The Basic Unit includes one Floppy Disk and one DVD Drive. Other integrated accessable drives are not supported. Section Hard Disk Drives while stocks last SNP:SY-F2336E118-P SNP:SY-F2336E136-P Hard disk 18GB Hard disk 36GB 10000rpm, <7ms, min.
  • Page 10 System configurator and order-information guide PRIMERGY T850 Status 2003-09-23 Section SCSI/Fibre Channel Controller Inclusive The two HD SCSI drives are connected to one on-board SCSI channel. The 2nd channel of the Dual- The second on-board SCSI channel can be used for external devices.
  • Page 11 System configurator and order-information guide PRIMERGY T850 Status 2003-09-23 VIII Section Disk Array Mixing DPT/Adaptec and Mylex / LSI controllers is not supported 1-channel Ultra 160 SCSI controller for internal and external hard disks S26361-F2406-E16 1-channel RAID Controller U160 Mylex / LSI...
  • Page 12 System configurator and order-information guide PRIMERGY T850 Status 2003-09-23 Section Communication, Network Controller S26361-F2732-E1 S26361-F2730-E1 Gigabit Ethernet Contr. 1000SX Gigabit Ethernet Contr. 1000TX Intel Pro/1000 XF Server Adapter Intel Pro/1000 XT Server Adapter Adapter Teaming Support Adapter Teaming Support PCI-X (all PCI slots), min 163 mm PCI-X (all PCI slots), min 163 mm Connector: ext.

  • Page 13: System Management Products (Remoteview)

    System configurator and order-information guide PRIMERGY T850 Status 2003-09-23 Section System Management Products Inclusive in Basic Unit RemoteView Service Board occupies 1 PCI slot RemoteView external Power Supply max. 1x per system S26361-F2425-L300 incl. power cord (with cold device- and Euro plug)

  • Page 14: Miscellaneous

    S26361-K874-V406 PCI Extension Box Upgrade Upgrade from 12 to 18 PCI-X slots max. 1x per PCI Extension Box S26361-F2739-E412 End of PRIMERGY T850 SNP:SY-F1647E301-P "Rack-mounting ex factory" Installation ex works for one This service is to be ordered once server or subsystem.

  • Page 15: Scsi/Fibre Channel Controller For Pci Extension Box

    System configurator and order-information guide PRIMERGY T850 Status 2003-09-23 Section SCSI/Fibre Channel Controller for PCI Extension Box Controller for the connection of an external storage system: S26361-F2399-E1 not released for SCSI 160 controller VMware ESX Server Adaptec SCSI card 29160 1 channel: LVD+Fast/Ultra (decoup.)

  • Page 16: Disk Array For Pci Extension Box

    System configurator and order-information guide PRIMERGY T850 Status 2003-09-23 VIII Section Disk Array for PCI Extension Box Mixing DPT/Adaptec and Mylex / LSI controllers is not supported S26361-F2569-E64 2-channel RAID Controller U160 Mylex / LSI AcceleRAID 352 (Leopard) 64MB SDRAM ECC Cache BBU optional Connector:ext.
  • Page 17 - Japan, SW: VLAN, Fast Etherchannel - New Zealand, max. 2x per system - Norway, - Poland, - Switzerland, - United States End of PRIMERGY T850 with PCI Extension Box Fujitsu Siemens Computers 17 of 18 Enterprise Products - PRIMERGY Server...

  • Page 18: Change Report

    System configurator and order-information guide PRIMERGY T850 Status 2003-09-23 Change report Date Order number Change 2003-08-13 SNP:SY-F1647E301-P Service "Installation ex works" for PCI Extension Box (3U) - now available 2003-07-25 S26361-F3011-E1 Gigabit Ethernet Controller dual 1000TX, in Extension Box: - now available...
