AND CC-Link Interface AD-4402-OP-20 Instruction Manual

Cc-link interface
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ふ
Interface
WM : PD4000299A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CC-Link Interface AD-4402-OP-20 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AND CC-Link Interface AD-4402-OP-20

Summary of Contents for AND CC-Link Interface AD-4402-OP-20

  • Page 1 ふ Interface WM : PD4000299A...
  • Page 2 This is a hazard alert mark. This mark informs you about the operation of the product. Note This manual is subject to change without notice at any time to improve the product. No part of this manual may be photocopied, reproduced, or translated into another language without the prior written consent of the A&D Company.

  • Page 3: Table Of Contents

    Contents Compliance..................2 1.1.1. Compliance with FCC rules ............2 1.1.2. Compliance with European Directives........2 Outline and Features ................. 3 2.1. Precautions..................3 Panel ....................4 3.1. Installing the Option............... 5 Functions ................... 6 4.1. Remote I/O and Remote Registers..........6 4.1.1.

  • Page 4: Compliance

    1. 1. 1. 1. Compliance Compliance Compliance Compliance 1.1.1. 1.1.1. 1.1.1. 1.1.1. Compliance with FCC rules Compliance with FCC rules Compliance with FCC rules Compliance with FCC rules Please note that this equipment generates, uses and can radiate radio frequency energy.

  • Page 5: Outline And Features

    2. 2. 2. 2. Outline and Feature Outline and Features s s s Outline and Feature Outline and Feature The CC link (Control & Communication link) is used to connect factory automation devices and control it by a master unit. Refer to the CC-link partner association vender regarding the details of this open system and each device.

  • Page 6: Panel

    3. 3. 3. 3. Panel Panel Panel Panel Station number switch (Address number switch) Baud rate switch Status LED Signal terminals Connector Connector F5210A-5P Shield terminal CC-Link OP-20 Signal ground terminal Frame ground terminal Station number switch Station number range: 1 to 61. Set the CC-link station number (address number).

  • Page 7: Installing The Option

    3.1. Installing the Option 3.1. Installing the Option 3.1. 3.1. Installing the Option Installing the Option Caution Remove the power cord before installing the option. Do not install the same options. Do not touch any inside parts within ten seconds after removing the power cord because you may receive an electric shock.

  • Page 8: Functions

    4. 4. 4. 4. Functions Functions Functions Functions The installed option can read the AD-4402 weighing data and write parameters to control it from the master station (EX. program controller of CC-link). There are two ways to operate the option. Direct operation of the remote input and output with the remote registers.
  • Page 9 Master Unit to AD-4402 Description Station No. Remote register Buffer RWw000 Final, 24 bits RWw001 Material code to store, 8 bits RWw002 Optional preliminary 32 bits RWw003 RWw004 Preliminary 16 bits RWw005 Free fall 16 bits RWw006 Over 16 bits RWw007 Under 16 bits...

  • Page 10: Address Map Of The Remote Input / Output

    4.1.2. 4.1.2. 4.1.2. 4.1.2. Address Map of the Remote Input / Output Address Map of the Remote Input / Output Address Map of the Remote Input / Output Address Map of the Remote Input / Output Flags (bits) and CC-link handshake in the remote input, AD-4402 to Master Unit Assumed that station No.
  • Page 11 Flags (bits) and CC-link Station No. Buffer Description Handshake of Remote Input RX002B Mixing RX002C Discharge RX002D Batch finish RX002E Recipe finish RX002F Discharge finish RX0030 Mixture finish RX0031 Nozzle down RX0032 Online RX0033 Weighing sequence in process RX0034 Input acknowledged RX0035 Weighing sequence error RX0036...
  • Page 12 Flags (bits) and CC-link Station No. Buffer Description Handshake of Remote Input RX0060 to Not used RX006F RX0070 to Not used RX0077 RX0078 Request flag of initialization RX0079 Reply flag of initial data setting RX007A Error status flag RX007B Remote READY flag RX007C to Not used RX007F...
  • Page 13 Flags (bits) and CC-link Station No. Buffer Description Handshake of Remote Input RY0028 Internal reservation RY0029 Manual free fall compensation RY002A Total command RY002B Cancel the last total RY002C Emergency stop Clear total of each material code that specified RY002D at the storing command No.33.

  • Page 14: Communication Commands

    4.2. Communication Commands 4.2. Communication Commands 4.2. 4.2. Communication Commands Communication Commands 4.2.1. 4.2.1. 4.2.1. 4.2.1. Reading Commands Reading Commands Reading Commands Reading Commands Command code Command name Description at RWw000E Material name 1 (character no. 1 to 4) Material name 2 (character no. 5 to 8) Material name 3 (character no.

  • Page 15: Storing Commands

    4.2.2. 4.2.2. 4.2.2. 4.2.2. Storing Commands Storing Commands Storing Commands Storing Commands Data of Command code Command name RWw000C, Description at RWw000E RWw000D Material name 1 (character no. 1 to 4) Material name 2 (character no. 5 to 8) Characters Material name 3 (character no.
  • Page 16 Data of Command code Command name RWw000C, Description at RWw000E RWw000D Zero Zero clear Tare Tare clear Batch start Recipe start Discharge start Mixing start Manual free fall compensation Total Cancel the last result Emergency stop Set the material code at storing Clear total of each material code command No.33 before use...

  • Page 17: Timing Chart

    4.3. Timing Chart 4.3. Timing Chart 4.3. 4.3. Timing Chart Timing Chart 4.3.1. 4.3.1. 4.3.1. 4.3.1. When Turning on the Indicator When Turning on the Indicator When Turning on the Indicator When Turning on the Indicator When initializing the interface from the indicator, use the following procedure. When initializing the interface from the master unit, refer to "4.3.3.

  • Page 18: Requesting Interface Initialization From The Master Unit

    4.3.3. 4.3.3. 4.3.3. 4.3.3. Requesting Interface Initialization from the Requesting Interface Initialization from the Requesting Interface Initialization from the Requesting Interface Initialization from the Master Unit Master Unit Master Unit Master Unit When initializing the interface from the master unit, use the following procedure. When initializing the interface from the indicator, refer to "4.3.1.

  • Page 19: Reading Commands

    Step 3 Step 4 Setpoints (RWw0000 to RWw000B) Request flag to store setpoint (RY0000) Reply flag to store setpoints (RX0000) 4.3.5. 4.3.5. 4.3.5. 4.3.5. Reading Commands Reading Commands Reading Commands Reading Commands 1 Set a material code (No. 33) or recipe code (No. 57) in the storing command (RWw000E). 2 Turn on the Read/Write selection (RY0003).

  • Page 20: Cpu Signal

    4.3.7. 4.3.7. 4.3.7. 4.3.7. CPU Signal CPU Signal CPU Signal CPU Signal When the AD-4402 indicator status is normal, the CPU normal operation flag register (RX0006) outputs the following signal. CPU normal operation flag (RX0006) 0.5 ~ 1sec. 4.3.8. 4.3.8. Error Detection Flag Error Detection Flag 4.3.8.

  • Page 21: Maintenance

    5. 5. 5. 5. Maintenance Maintenance Maintenance Maintenance 5.1. 5.1. Monitor Mode 5.1. 5.1. Monitor Mode Monitor Mode Monitor Mode The monitor mode is used to check the indicator during the weighing sequence. 5.1.1. 5.1.1. 5.1.1. 5.1.1. Operation and Display Operation and Display Operation and Display Operation and Display...
  • Page 22 MEMO Page 20 AD-4402-20...
  • Page 23 [ Blank page ]...
