- Page 1 PLAZA MODELS ST 250 / ST 350 Digital Satellite Receiver Instruction Manual (English) http://www.plaza-st.com ISSUE3...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION .............................2 FEATURES .............................3 FRONT PANEL CONNECTORS ........................4 CONTROLS AND DEFINITIONS..........................4 INSTALLATION ............................5 TUNING YOUR TV TO OUTPUT SIGNAL ....................5 MAIN MENU ............................5 SYSTEM INFORMATION............................6 INSTALL Menu............................6 CONFIGURING YOUR ANTENNA .........................6 CONFIGURING DiSEqC ANTENNA POSITIONER ..................7 DiSEqC 1.2 menu (Manual positioner) ......................7 DiSEqC USALS menu (Automatic Positioner) ....................7 CHANNEL SEARCH -- Automatic Scan and Search ..................7 CHANNEL SEARCH: Manual Scan and Search....................8... -
Page 3: Features
Welcome to the world of Manhattan digital satellite receiver that will make your life closer to your dream. Before using your new receiver, we suggest that you carefully read this manual and the following safety notice. The PLAZA model is an advanced digital satellite receiver with the unique option of Blind Search Facility and is designed to cope with the many different operating requirements of broadcast standards worldwide. -
Page 4: Front Panel Connectors
CONNECTORS AND DEFINITIONS Please do not connect the power to the receiver until all other connections have been made and checked. (100-240 Volts AC, 50/60 Hz, 0.2Amps / 0.15Amps) R1: AC IN (Power Cord) Connect this lead to the mains outlet R2: LNB IN (IF Input) Connect the IF cable from your LNB to this connector. -
Page 5: Installation
We recommend that you familiarize yourself with the remote control handset prior to installing the receiver. OPERATION IN PROGRAMMING MODE The menus are designed to assist you from the moment you switch on the receiver. Follow the help messages at the bottom of the menu. INSTALLATION For digital quality picture, connect the receiver to your TV using a fully wired SCART lead. -
Page 6: System Information
TV Settings TV Standard: Select the output for your TV. Example: for USA select NTSC M. If your TV supports ‘Auto Sensing’ then select Auto. Screen Format: Select the picture format for your TV. STORE: After above settings move to store and press OK key. Time Settings In standby mode, the front display and channel banner will indicate the time after setting as below. -
Page 7: Configuring Diseqc Antenna Positioner
EXAMPLE: To configure four antennas EXAMPLE: To configure MONOBLOCK LNB Astra 2 (28.2E), select Antenna 1 and set DiSEqC to 1 Astra 1(19.2E), select Antenna 1 and set DiSEqC to Mini-A Hotbird 1-6(13E), select Antenna 2 and set DiSEqC to Mini- Astra 1 (19.2E) select Antenna 2 and set DiSEqC to 2 Hotbird 1-6 (13E), select Antenna 3 and set DiSEqC to 3 Thor 2, 3 (1W), select Antenna 4 and set DiSEqC to 4... -
Page 8: Channel Search: Manual Scan And Search
TP All + D -- Selected TP for all Video, Radio and Data channels. TP FTA -- Selected TP for Free to Air Video and Radio channels. Manual All – Single TP for all Video and Radio channels. To select go to TP Data and press OK for sub menu. -
Page 9: Advance Search: Special Feature
CHANNEL SEARCH Go to Channel Search and configure following Search Index: Select index 1 Antenna: Select reference 1 Satellite: Select satellite name. Search Mode: Select search option. TP Data: Select a lower band TP. LNB Skew: Adjust skew for maximum Signal and Quality. After this go to Index search and set as below. ... -
Page 10: Sorting The Channel List
SORTING THE CHANNEL LIST Press Green key to sort channels alphabetically. Press Yellow key to sort channels Free To Air first followed by Scrambled. Press Red key to return to normal list. TO SELECT A CHANNEL FROM ANOTHER SATELLITE Press SAT key and the combined channel and satellite list will appear. ... -
Page 11: To Select Subtitles On A Channel
TO SELECT SUBTITLES ON A CHANNEL Press SUB.T (Blue) key. Select required language and press OK. The subtitles will appear after a few seconds. If not transmitted, it will state No Subtitles available. TO SELECT AUDIO LANGUAGE You can select an audio by pressing LANG key. The screen will display options on the top left. Select required language and press OK. -
Page 12: To Lock Menu And Channels
TO LOCK MENU AND CHANNELS Go to INSTALL menu and select Parental Lock. Lock: Press VOL up / down to turn it on. Old Password: Use 0-9 keys and enter 0000. This is the default password. New Password: Use 0-9 keys and enter four digits of your choice. Confirm: Use 0-9 keys and re- enter four digits of your choice. -
Page 13: To Sort Satellite List
TO SORT SATELLITE LIST After adding a satellite select Sort and press OK. The list will be sorted by satellite positions in degrees. TO EDIT A TP --- Select TP option and press OK The cursor will move to TP list. Select the TP you want to edit and press OK. Cursor will move to Edit TP. -
Page 14: To Record Programs
Format Hard Disk: After fitting Hard Disk or to erase previously recorded events, press OK on this menu. A message Formatting will erase all data will come up. To format press OK. Play / Edit: When you want to playback or edit the events recorded, press OK on this menu and follow steps in PLAYBACK AND EDITTING section below. -
Page 15: Trouble Shooting Guide
Bad picture with blocking or frozen --- Signal weak or noisy. Check signal quality. Antenna not in correct position Not responding to remote control --- Check the batteries in your remote control. Replace with new. You have lost or forgotten your password --- Apply master password or contact your Manhattan dealer. SPECIFICATI SPECIFICATIONS... -
Page 16: Master Password
Size (W X H X D) 380 X 68 X 296 mm ® ® Eurosat and Manhattan are registered trademarks of Eurosat Distribution Ltd. Eurosat reserves the right to alter product specifications without prior notice. E&OE ---------------------------------------------------------------------------------------------------------------- MASTER PASSWORD This is the master password for your receiver. Cut this section out and keep it in a safe place. It will be useful...
