Summary of Contents for Manhattan DJ-1997
-
Page 1: User Manual
User Manual Of Digital Set Top Box Manhattan DJ-1997 Please read this User Manual carefully to ensure proper use of this product and keep this manual for future reference. -
Page 2: Table Of Contents
Table of Contents Important Safety Instructions……................1 Front and Rear Panel Illustration................2 Remote Controller.....................3 Connections.....................5 Quick Installation....................6 DTV Operation....................9 Multimedia......................19 DVR........................21 Troubleshooting ...................24 Specifications....................25... -
Page 3: Important Safety Instructions
Important Safety Instructions *Warning: To reduce the risk of electric shock, do not remove the cover or back. There are no user-serviceable parts inside. Refer servicing to qualified personnel. *Warning: To prevent fire or electric shock hazard, do not expose the unit to rain or moisture. -
Page 4: Front And Rear Panel Illustration
Front and Rear Panel Illustration 1. Front Panel 1. USB JACK: Used to connect to an external USB 2.0 device. 2. LED DISPLAY: Used to display the time or channel information. 3. STANDBY: Used to switch the set top box to on or standby. 4. -
Page 5: Remote Controller
Remote Controller 1. LED display lights to verify remote operation 2. Enter the Manual Timer Setting menu 3. Display Media Player for Videos / Photos / Music 4. Page Down in a List and DVR Scan Rewind 5. Skip Rewind 6. - Page 6 Remote Controller Installing the Batteries Remove the battery cover from the remote control and put 2xAAA size batteries inside the compartment. The diagram inside the battery compartment shows the correct way to install the batteries. 1. Open the cover 2. Install batteries 3.
-
Page 7: Connections
Connections Caution: Make sure to check the voltage specification of the wall outlet is the same rating with the receiver. To prevent the risk of electric shock, do not open the cover or the back of the receiver. Note: When connecting the receiver to other equipment, e.g., TV, VCR and amplifier, make sure to refer to relevant user manual for instruction. -
Page 8: Quick Installation
Quick Installation (1) Unplug the set-top box and television. (2) Connect the antenna to the RF input of the box with coaxial cable. (3) Connect the audio out port and video out port on the box to the audio in port and video in port on the television respectively using audio/video cables. - Page 9 Channel Scanning 1. Automatic Sat Scan With the Auto SAT Scan function, you can perform TV-channel scanning on one or more satellites. Before proceeding, you need to make sure all the parameters for satellite connections are set correctly. For the satellite parameter setting for a dedicated connection mode.
- Page 10 3. Satellite/TP Management This manager provides features including add, delete, and edit for you to manage your satellites and TPs thereof. (1)Move the focus to your desired satellite name and then press the color key to open the satellite manager page. (2)Press <...
-
Page 11: Dtv Operation
DTV Operation Main menu When your set-top box is power on, a press on the Menu button will bring out the Main Menu. In this menu, press <Exit> button to switch into the TV's Normal Play mode. Here, you can further select the operation mode for your set-top box using the <TV/Radio>... - Page 12 3.Lock: Press <Green> to set/cancel tv/radio list lock status. 4.Del:Press <Yellow> to set/cancel tv/radio list del status ,when you exit TV/Radio list edit , the result will saved. 5.Top: Press <Blue> to set/cancel tv/radio list lock status. Guide The Guide page, also known as EPG (Electronic Program Guide), provides you not only the program guide and program information but also the feature for you to make an appointment to watch and schedule the program recording.
- Page 13 (1)Wired Network If you want to use Wired Network, you first enter main menu to set Network interface in Wired Network, and there are two modes. [AUTO], it will automatically get IP address to connect. [Manual], you need manually input IP address, Net Mask address, Gateway address and DNS address.
- Page 14 2. Set Date: If the internet connection is not available, you can set the system date here. (1) The setting range is from 1970/01/01 to 2038/03/31. Any date before 1970/01/01 will be set to 1970/01/01, and any date after 2038/03/31 will be set to 2038/03/31. (2) Any change made here will be immediately reflected to the system.
- Page 15 (2) When this feature is set to HDMI, the available resolution options for PA L mode are 720p_50Hz, 1080i_50Hz,1080p_50Hz, and AUTO, and for NTSC mode are 720p_60Hz, 1080i_60Hz, 1080p_60Hz, and AUTO, while you are not allowed to switch to the resolutions not supported by your T V. (3) If there is HDMI connection between your box and TV, the default setting of TV Resolution is AUTO;...
- Page 16 (4)There are two advance timer modes, Schedule and Recorder. Schedule: as soon as the scheduled start time is reached, your set-top box will switch to Normal Play mode, and start playing the scheduled program. If Recorder: if the scheduled program and the program currently playing are received from the same TP, then the recording will start in background.
- Page 17 4. Change Password You can change your password here. After restoring to factory default, this feature will be set to NO, and the password will be 0000 again. Update& Backup In the Update&Backup submenu, you can choose to update your set-top box software applications.
- Page 18 Playback You can select to watch TV or listen to the radio in Normal Play mode. Since watching TV and listening to the radio in Normal Play mode are identical in their ways of operating, in this section we will focus on how to watch TV. In Normal Play mode, Press <TV/Radio>...
- Page 19 (4) Press <Left/Right> to select the search mode, Search Forward or Search Backwards. (5) Press<OK>to start your search. Notice: (1)If your search completes successfully, the channel you search for will be highlighted and start playing in the screen window. If your search fails, the highlight will stay on the current channel playing in the screen window.
- Page 20 Notice: (1) Any change in Audio Language setting will also trigger an appropriate change in Audio PID field. (2) The options for Sound Mode are LL, RR, and LR. Switch among Your Favorites In Normal Play mode, you can press <Fav Up/Down> button to switch among your favorite lists.
-
Page 21: Multimedia
Multimedia Movie Movie Thumbnail/ Folder In Main menu, select Multimedia > Movie, and press <OK>. In the thumbnail page, the available button operations are as followed: <Menu>: this allows you to go back to Main menu. <Red>: enter Movie play option setting. (1)Random: Random play movie order on /off (2)Repeat: Repeat play movie order all / off/ one (3)Text Encode: You can specify the coding for the add-on subtitle files. - Page 22 Music Music Thumbnail/Folder In Main menu, select Music from the MULTIMEDIA, and then press <OK> to enter into the music Folder mode In the thumbnail /Folder page, the available button operations are as followed: <Menu>: this allows you to go back to Main menu. <Red>: enter Music play option setting.
-
Page 23: Dvr
DVR Features DVR provides following features: 1. Support one-path TS recording. 2. Support time-shift function. Support program playback functions including pause, fast forward/backward (2x, , 32x) , and slow forward/ backward (1/2, 1/4). 4. Support background recording in same TP. 5. - Page 24 Timeshift Timeshift feature Multimedia -> Recorder Setting ->Timeshift ( Auto/Pause/Off). Auto: the system automatically enters timeshift status when you go into Normal Play mode. Pause: While watching live program in Normal Play mode, you can pause the playback with <Pause> button. Then once you restore the playback by pressing <Play>...
- Page 25 Record List Page This page will list out all the available recorded files. The available buttons here are listed as below: Button Functions Red button Rename a recorded file Green button Format an external device and set the device type, slot, and partition Yellow button Selected...
- Page 26 IPTV Manual The IP media player in the DJ-1997 is a simple unit that is both IP and MAC addressable. You will find your IP and MAC addresses in the Multimedia Icon. Select “Network” and it will display your addresses and activate your wireless or wired connection. To set a wireless setting, you need to install the wireless antenna into the USB port on the back of the DJ-1997.
- Page 27 Add IP channel manually: >Hit Yellow IPTV button. >Hit RED (Edit) > Hit Yellow button “Add” to add the channel. >Hit Edit again to enter name of channel with Keyboard. Hit Edit to save name or "Confirm by pressing red button or OK on remote." >Cursor down to Program URL.
-
Page 28: Troubleshooting
Troubleshooting Problem Potential Reasons What to do No picture Power isn't connected Connect the power The power switch is not on Switch on the power Screen shows Not connect DVB-S cable Plug in the DVB-S cable No Signal Incorrect setting Set up correct parameter No sound from No or incorrect connection... -
Page 29: Specifications
Specifications Item Specification Tuner Frequency Range 950MHz to 2150MHz Input Impedance 75Ohms unbalanced Signal Input Level -65 ~ -25dBm Symbol Rate 2-45Mbps 13/18V,Max 500mA LNB Power Demodulation Demodulator QPSK/8PSK 1/2,2/3,3/4,5/6,7/8,8/9,9/10 LNB IN F connector Connections LOOP OUT F connector Y/Pb/Pr Connect to your TV component input terminals SPDIF digital audio output...
