- Page 1 D8024/D10024A Fire Alarm Control Panels User Manual...
- Page 2 D8024/D10024A User Manual 50618B Page 2 © 2002 Radionics...
-
Page 3: Table Of Contents
Enable or Disable Delayed Day Modes ......................20 5.4.1.12 Enable or Disable Outputs..........................20 5.4.1.13 Print................................. 21 5.4.2 View ................................21 Delayed Day Mode Operation ................23 Stage 1................................23 Stage 2................................23 D8024/D10024A User Manual © 2002 Radionics Page 3 50618B... - Page 4 Log Book......................27 REFERENCE DATA ............................27 EVENT DATA..............................28 Figures Figure 1: D8024/D10024A Controls and Displays........................9 Figure 2: Control Keys ................................9 Figure 3: Alphanumeric and Interactive Control Keys ......................10 Figure 4: System Control LED Display ..........................10 Figure 5: Zone LED Display ..............................
-
Page 5: Other Literature Referenced
These instructions cover the use and operation of the Fire Alarm Control Panel. Refer to the D8024/D10024A Operation and Installation Manual (P/N 50616) for details of how to install the system and for information on programming and Level 3 functions. -
Page 6: Ul/National Approvals
Increase the separation between the equipment and the receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. D8024/D10024A User Manual 50618B Page 6... -
Page 7: User Control Levels
User Control Levels Level Definition • The D8024 and D10024A Fire Alarm Control Panels have three user control levels. • At all three levels, the LED Displays indicate the condition of the installation, the Zone LED Displays indicate the location of any fire alarm or trouble and the alphanumeric display gives more detailed fire alarm or trouble information. - Page 8 D8024/D10024A User Control Levels Notes: D8024/D10024A User Manual 50618B Page 8 © 2002 Radionics...
-
Page 9: Controls And Displays
On the D8024, opening the hinged panel gives access these keys. This is located Figure 1: D8024/D10024A Controls and Displays below the Zone LED Display. The alphanumeric keys normally function as a numeric keypad. During programming, these keys can be toggled to Letter Keys by pressing the [Change] key. -
Page 10: Alphanumeric/Interactive Control Keys
• The standard Zone LED Indicators provide identification for up to 20 zones. On the D10024A panel, this can be extended by adding either a further 20 zones (to give a total of 40 zones) or a further 60 zones (to give a total of 80 zones). -
Page 11: Zone Led Displays
Zone LED indicators shows the location of a fire alarm or trouble. The standard Zone LED Indicators provide identification for up to 20 zones. On the D10024A panel, this can be extended by adding either a further 20 zones (to give a total of 40 zones) or a further 60 zones (to give a total of 80 zones). -
Page 12: Lcd Display Indications
• Pressing the SHIFT key will show a list of optional functions or prompt for the level 2 password. Figure 8: Enable Control Keys? D8024/D10024A User Manual 50618B Page 12 © 2002 Radionics... -
Page 13: Level 1 Display Functions
• If more than one trouble condition is present, the alphanumeric display will either automatically scroll through or, can be manually scrolled through, the troubles registered. D8024/D10024A User Manual © 2002 Radionics Page 13 50618B... - Page 14 D8024/D10024A Level 1 Display Functions Notes: D8024/D10024A User Manual 50618B Page 14 © 2002 Radionics...
-
Page 15: Level 2 Control Functions
• After correcting the problem, press the RESET key. The SYSTEM TROUBLE, TROUBLE SILENCE and other appropriate system status LED Indicators will be turned off. The alphanumeric display returns to normal. D8024/D10024A User Manual © 2002 Radionics Page 15 50618B... -
Page 16: Fire Alarm Conditions
The LEDs on the front panel display The alphanumeric (liquid crystal) display The detection and alarm initiating devices connected to the signaling loop. The NAC outputs and other alarm condition output devices connected to the system D8024/D10024A User Manual 50618B Page 16 © 2002 Radionics... -
Page 17: Leds Test
If an alarm signal is received from a zone other than those under test, then all NAC output and relay output circuits will activate as programmed for the zone in alarm. The NACs will continue to ring until silenced from the panel. • Press [No] to terminate the walk test. D8024/D10024A User Manual © 2002 Radionics Page 17 50618B... -
Page 18: Output Test
The options available in each menu are identical. This allows the user to enable or disable: Zones Individual devices Panel Keys Day Modes Outputs (NACs or relays) 5.4.1.7 Enable or Disable Zones • To enable or disable input devices by zone, select option 1. D8024/D10024A User Manual 50618B Page 18 © 2002 Radionics... -
Page 19: Enable Or Disable Inputs
• Enter the required loop number (1-2 for D8024 or 1-5 for D10024A) and the display will prompt for the numeric address of the device: • Enter the address of the device required. If the address is less than 3-digits long (for example address 34), this can be entered as either [0]+[3]+[4] or [3]+[4] followed by [Enter]. -
Page 20: Enable Or Disable Delayed Day Modes
A warning message will also be shown on the alphanumeric display. • The NACs can only be disabled after confirmation by re-entering the Level 2 password. D8024/D10024A User Manual 50618B Page 20 © 2002 Radionics... -
Page 21: Print
To select the print menu, press [6] from the user main, option menu. The display then shows: • This menu controls the operation of the optional front panel printer on the D10024A panel only. The user options are as follows: Options Description Devices prints out the present status and text assigned to all devices on a loop. - Page 22 D8024/D10024A Level 2 Control Functions Notes: D8024/D10024A User Manual 50618B Page 22 © 2002 Radionics...
-
Page 23: Delayed Day Mode Operation
If the panel is not reset, using the [ System Reset ] key, within the time allowed then a full fire alarm condition will be raised and the NAC outputs will activate. Manual Stations will always generate an immediate fire alarm condition regardless of an delayed day mode settings. D8024/D10024A User Manual © 2002 Radionics Page 23 50618B... - Page 24 D8024/D10024A Delayed Day Mode Operation Notes: D8024/D10024A User Manual 50618B Page 24 © 2002 Radionics...
- Page 25 D8024/D10024A Level 3 Programmer Functions Level 3 Programmer Functions Refer to the D8024/D10024A Operation and Installation Manual (PN 50616) for complete information on commissioning and programming the D8024 and D10024A Fire Alarm Control Panels. D8024/D10024A User Manual © 2002 Radionics...
- Page 26 D8024/D10024A Level 3 Programmer Functions Notes: D8024/D10024A User Manual 50618B Page 26 © 2002 Radionics...
-
Page 27: Log Book
Responsible Person: Date Date Date Date The system was installed by: Date And is maintained under contract by: Until Contact Telephone Number: If Service is Required. Table 9: Logbook Reference Data D8024/D10024A User Manual © 2002 Radionics Page 27 50618B... -
Page 28: Event Data
Action Required Date Initials Reading Completed Table 10: Logbook Event Data © 2002 Radionics, a division of Detection Systems, Inc. 50618B 7/02 PO Box 80012, Salinas, CA 93912-0012, USA User Manual D8024/D10024A Customer Service: (800) 538-5807 Page 28 of 28...
