AviStart 3001 Installation Manual

14 Pin Connector (Revised)

Pin Number

Wire Color

1 BLUE/WHITE
2 GREEN/WHITE
3 ORANGE/BLACK
4 WHITE/BLACK
5 BLACK
6 WHITE/GREEN
7 YELLOW
8 YELLOW/BLACK
9 TAN
10 RED/BLACK
11 GRAY/BLACK
12 GRAY/WHITE
13 RED/WHITE
14 RED
© 1999 Avital Technologies, Inc., A Division of Clifford Electronics
Supplement 001

Description

Lock (-) Output
Unlock (-) Output
Glow Plug Light (+) Input
Dome Light (-) Output for Factory Alarm Rearming
Battery (-)
Tachometer Input
Brake Switch (+) Input
Reverse Light (+) Input
Hood Switch (-) Input
Parking Light Output
Remote Start Activated (-) Output
Factory Alarm Disarm (-) Output
Parking Light Polarity Input (+) or (-) Select
Battery (+)
Part Num ber: 32-3001-1
