- Page 1 Model 3100L ➤ Owner s Guide...
- Page 2 Limited Lifetime Consumer Warranty For a period of one calendar year from the date of purchase of this auto-security device, Directed Electronics, Inc. promises to the ORIGINAL PURCHASER to repair or replace (with a comparable reconditioned model), free of cost, any electronic control module which proves to be defective in workmanship or material under normal use, SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS ORIGINALLY...
- Page 3 Terms and Conditions. Available only in the USA. In the event that your vehicle is stolen and not recovered, Directed Electronics, Inc. will refund to the original pur- chaser of the Avital system up to $2,500 of your insurance deductible. This vehicle protection guarantee is valid only if: (1) The installation was performed by an authorized Avital dealer.
- Page 4 Once Avital Technologies verifies that all the above listed terms and conditions have been met, a check for the insurance deductible (up to $2,500) will be mailed within thirty (30) days.
-
Page 5: Table Of Contents
Table of Contents Limited Lifetime Consumer Warranty What Is Included ..........3 Important Information . - Page 6 2008 Directed Electronics ©...
-
Page 7: What Is Included
What is Included ■ A control module ■ Two 3-button remote transmitters ■ A zone 2 impact sensor on-board the control module ■ A high-powered siren ■ A fault-proof starter interrupt on-board the control module ■ An LED system status indicator ■... -
Page 8: Your Warranty
when using the remote transmitter. To access the battery for replacement, remove the rear cover of the remote with a small, flat-blade screwdriver. Your Warranty Your warranty card must be returned and the barcode serial num- ber must not be removed. If the warranty card is not returned, no warranty will be honored on your unit. -
Page 9: Transmitter Functions
Remote Functions This system is programmable, making it possible to assign any remote button to any specific receiver function. The remote initial- ly comes programmed with Standard Configuration, but may also be customized by an authorized dealer. The buttons in all of the instruc- tions in this manual correspond to a Standard Configuration remote. -
Page 10: Using Your System
Using Your System The remote buttons indicated in this manual correspond to a stan- dard configuration remote, unless otherwise specified. Arming You can arm the security system by pressing When the system arms, you will hear a short siren sound (chirp) and the parking lights will flash once. -
Page 11: Disarming
time a sensor is triggered during the Passive Arming countdown, the countdown starts over. Arming your security system protects your vehicle to the following degrees: ■ Light impacts trigger a warn-away response, causing the siren to chirp and the parking lights to flash for a few seconds. ■... -
Page 12: Disarming Without A Transmitter
disarming indicates Tamper Alert, which is described in the Diagnostics section of this guide. Disarming Without a Remote If your remote is lost or damaged, you can manually disarm your vehicle security system. To disarm the system without a remote, you must have the vehicle's ignition key and know where the Valet switch is located. -
Page 13: Remote-Controlled Silent Arm/Disarm
Remote-Controlled Silent Arm/Disarm Use remote-controlled silent arm/disarm to temporarily turn off the arm or disarm chirps by briefly pressing arming or disarming. The confirmation chirp(s) will then be elimi- nated for that one operation only. To permanently turn off the arm and disarm chirps, contact your installation dealer. -
Page 14: Remote-Controlled Valet
Remote-Controlled Valet You can also enter or exit Valet Mode by using the remote: 1. Open any vehicle door. 2. Press 3. Press 4. Press again. The LED system status indicator will light solidly if you have entered Valet Mode and will turn off if you have exited Valet Mode. Nuisance Prevention ®... -
Page 15: Diagnostics
rity system is triggered by an open door for three, full 30-second cycles (one and one half minutes), the system will bypass the doors until the trigger ceases. NOTE: Arming and disarming the system does not reset the NPC only ways to reset a bypassed zone are for that zone not to be triggered for 60 minutes or to turn the ignition key on. -
Page 16: Disarming Diagnostics
your vehicle has an interior light exit delay and you arm the sys- tem before the light turns off, you may hear a Bypass Notification chirp. Three seconds after the light turns off, however, normal monitoring resumes. NOTE: Bypass Notification does not occur when the system is in remote- controlled silent arm/disarm mode or if the chirps have been programmed not to sound. -
Page 17: Code Hopping Technology
ZONE (Number of DESCRIPTION LED Flashes) Instant trigger for optional sensor, hood or trunk pins A heavier impact detected by the on-board impact sensor Door switch trigger Ignition trigger NOTE: The LED does not report when the warn-away response has been activated;... -
Page 18: High Frequency
High Frequency Your system transmits and receives at 434 MHz. This provides a cleaner spectrum with less interference and a more stable signal. Enjoy a phenomenal increase in range, even in areas with high radio interference. Programming Options Programming options control your system's normal, operational set-up. -
Page 19: Security & Convenience Expansions
key is turned on, and unlock when the ignition is turned off. The system also prevents the doors from locking when the ignition is turned on while any vehicle door is open. Security & Convenience Expansions Listed below are some of the many expansion options available for use with your system. -
Page 20: Installation Options
Power Trunk Release: The output of the system can operate a factory power release for the vehicle's trunk or hatch. An optional relay is required. If the factory release is not power-activated, then DEI's 522T trunk release solenoid can be added in most cases. Power Window Control: Automatic power window control is pro- vided with the 529T and 530T systems. -
Page 21: Glossary Of Terms
Glossary of Terms Control Module: The "brain" of your security system. Usually hid- den underneath the dash area of the vehicle. It houses the micro- processor that monitors your vehicle and controls all of the secu- rity system’s functions. Fault-Proof Starter Interrupt: Located on-board the control mod- ule, this is an automatic switch controlled by the security system that prevents the starter from cranking whenever the system is armed. - Page 22 Trigger or Triggered Sequence: The "setting off" or "tripping" of the alarm. A triggered sequence consists of the siren sounding and the parking lights flashing for 30 seconds. Valet Switch: A small, push-button switch mounted inside the vehicle, at a location determined by the installer. This switch is used to override the alarm when a remote is lost or damaged, or can be used to put the system into Valet Mode.
-
Page 23: Quick Reference Guide (Removable)
QUICK REFERENCE GUIDE To arm using your remote: ■ Press on your remote for one second. When the system arms, you will hear a short siren sound, or chirp, and see the parking lights flash once. If the vehicle's power door locks are controlled by the system, the doors will lock. - Page 24 The company behind this system is Directed Electronics Since its inception, DEI ® has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, DEI is ISO 9001 registered.
