INSTALLING THE REFRIGERATOR

REFRIGERATOR LOCATION
Do not install the refrigerator where the
temperature will go below 60°F (16°C) because
it will not run often enough to maintain proper
temperatures.
Do not install the refrigerator where the
temperature will go above 100°F (37°C) because
it will not perform properly.
Install it on a floor strong enough to support it
fully loaded.
CLEARANCES
Allow the following clearances for ease of
installation, proper air circulation and plumbing
and electrical connections:
23'/25'
CustomStyle
Sides
1/8" (4 mm)
Top
1" (25 mm)
Back
1/2" (13 mm)
DIMENSIONS AND SPECIFICATIONS
24" (61 cm)
Cabinet
Installation Instructions
23' (33" wide),
25', 26', 27', 29'
1/8" (4 mm)
1" (25 mm)
-1" (25 mm)
Water
Electrical
3/4" (19 mm)
Airspace
(1/2" [13 mm] Gap
25" (63.5 cm)
+ 1/4" [6 mm] Wall
Countertop
Plates)
DIMENSIONS AND SPECIFICATIONS (for
23' CustomStyle
DIMENSIONS AND SPECIFICATIONS (for
25' CustomStyle
72
* 72
/
" (183.5 cm) required for full adjustment
1
4
of mobility wheels. If cabinets installed above
refrigerator have doors that are flush to the
top of the opening for the refrigerator, then
an additional 1/8" may be required to provide
clearance for cabinet doors to open freely.
23
models)
70
" (178.4 cm)
1 4
36"
(91.4 cm)
24" (61 cm)
models)
" (183.5 cm)*
1 4
36"
(91.4 cm)
24" (61 cm)
