DESKPOWER 2000 Series User's Manual
Fujitsu endeavours to ensure that the information in this document is correct,
but accepts no liability for any error or omission in the same. Any procedures
described in this document for operating Fujitsu products should be read and
understood by the operator before such products are used. To ensure that Fujitsu
products function without risk to safety and health, such procedures should
be strictly observed by the operator. The development of Fujitsu products and
services is continuous and published information may not be up to date.
Any particular issue of a product may contain facilities not described herein.
It is important to check the current position with Fujitsu. Specifications and
statements as to performance in this document are Fujitsu estimates intended for
general guidance. They may require adjustment in particular circumstances and
should therefore not be taken as formal offers or commitments.
DESKPOWER is a trademark of Fujitsu Limited. The following are registered
®
®
trademarks of Microsoft Corporation: MS, MS-DOS, Windows
NT, Windows
for
®
®
Workgroups, Windows
98. Pentium
and MMX™ technology are trademarks of
Intel Corporation. Award is the registered trademark of Award Software
International Inc.
All other products are trademarks or registered trademarks of their respective
companies.
© Copyright 1999 Fujitsu Limited. All rights reserved. No part of this publication
may be copied, reproduced, or translated without the prior written consent of
Fujitsu Limited. No part of this publication may be stored or transmitted in any
electronic form without the written consent of Fujitsu Limited.
© Copyright Fujitsu PC (Asia) Pte Ltd
Fujitsu PC (Asia) Pte Ltd
200 Pandan Loop
#05-03 Pantech 21
The Computer Centre
Singapore 128388
Tel: 65-776 0688
Fax: 65-776 0788
i
Advertisement
Table of Contents
Related Manuals for Fujitsu 2000
Summary of Contents for Fujitsu 2000
- Page 1 © Copyright 1999 Fujitsu Limited. All rights reserved. No part of this publication may be copied, reproduced, or translated without the prior written consent of Fujitsu Limited. No part of this publication may be stored or transmitted in any electronic form without the written consent of Fujitsu Limited.
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions carefully. Save these instructions for future reference. 2. Follow all warnings and instructions marked on the product. 3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 4. - Page 3 10. If an extension cord is used with this product, make sure that the total ampere rating of the equipment plugged into the extension cord does not exceed the extension cord ampere rating. Also, make sure that the total rating of all products plugged into the wall outlet does not exceed 15 amperes.
- Page 4 Starting your PC for the first time...
-
Page 5: Starting Your Pc For The First Time
Starting your PC for the first time Booting the System When you turn on your PC for the first time, it will display a Fujitsu logo on the screen. If you do nothing, the system will read the hard drive for the operating system software, flash the system configuration information on the screen, and then Setup Wizard Screen will appear. - Page 6 License Agreement Read the license agreement carefully. You can scroll through the text using the mouse to activate the scroll bar or use the up arrow ↑ and down arrow ↓ keys to move up and down the text one line at a time or use the Page Up or Page Down keys to move the text one screen at a time.
- Page 7 Time Zone When your PC has completely identified all of the installed hardware, it will display a dialog box entering which time zone you wish to set the clock to. ® Windows Messaging Once you have selected a time zone, you will see a screen announcing that ®...
- Page 8 Software Drivers and Application You will find a Composite CD packet in your accessories box. Please store the packet in a safe place in case there is a loss of data and it becomes necessary to reinstall your operating system and/or applications. The Composite CD will contain all the necessary drivers for re-loading.
-
Page 9: About This Manual
About this manual... - Page 10 About this Manual Purpose This user’s guide aims to give you all the necessary information to enable you to operate the system properly. Manual Structure This user’s guide consists of two chapters. Chapter 1 System Board This chapter describes the system board and all its major components. It contains the system board layout, jumper settings, cache and memory configuration, and information on other internal devices.
- Page 11 Conventions The following are the conventions used in this manual: Text entered by user Screen messages a, e, s, etc. Represents text input by the user. Denotes actual messages that appear on the screen. Represents the actual keys that you have to press on the keyboard.
-
Page 12: Table Of Contents
Chapter 1 SYSTEM BOARD MAINBOARD FEATURES ... 3 1.2. MAINBOARD LAYOUT ... 6 1.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS ... 7 CASE CONNECTOR: JFP1 ... 8 1.4.1 Power Switch ... 9 1.4.2 Reset Switch ... 9 1.4.3 Power LED ... 9 1.4.4 Speaker ... - Page 13 POWER SAVING SWITCH CONNECTOR: JGS1 ... 20 1.9.1 POWER SAVING LED CONNECTOR: JGL1 ... 21 1.10 Onboard Audio Enabled/Disabled Jumper: JP4 ... 22 1.11 MODEM WAKE UP CONNECTOR: JMDM1 ... 23 1.12 MODEM-IN: J6 ... 24 1.13 AUX LINE IN CONNECTOR: J5 ... 25 1.14 CD-IN CONNECTOR: J8 ...
- Page 14 INTEGRATED PERIPHERALS ... 40 POWER MANAGEMENT SETUP ... 44 RELOAD GLOBAL TIMER EVENTS ... 47 PNP/PCI CONFIGURATION SETUP ... 47 2.10 FREQUENCY/VOLTAGE CONTROL ... 49 2.11 LOAD FAIL-SAFE/OPTIMIZED DEFAULTS ... 50 2.12 SET SUPERVISOR/USER PASSWORD ... 51...
- Page 16 INTRODUCTION The DESKPOWER 2000 is a high-performance computer based on Intel chipset. The board is designed for the Intel inexpensive business/personal desktop markets. ® The Intel 810 chipset is the first generation Integrated Graphics chipset for the ® Intel Celeron processor.
-
Page 17: Mainboard Features
MAINBOARD FEATURES • Suppor t Socket370 for Intel Chipset ® • Intel 810 (GMCH/GMCH0) chipset. (421 BGA) - Integrated Graphics Controller - Intel DDM Architecture - SDRAM memory Independent of System Bus - Support 4MB Display Cache (only for GMCH) ®... - Page 18 On-Board Peripherals • On-Board Peripherals include: - 1 floppy port supports 2 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes. - 2 serial port (COMA + COMB) - 1 parallel port supports SPP/EPP/ECP mode - 2 USB ports - 1 VGA port Video •...
- Page 19 System Hardware Monitor • CPU Fan Revolution Detect • CPU Fan Control (the fan will automatically stop when the system enters suspend mode) • System Voltage Detect • CPU Overheat Warning. • Display Actual Current Voltage Other Features • Keyboard Password Wake-Up (reserved) •...
-
Page 20: Mainboard Layout
VGA Port CPUFAN Top: Midi/ Game Port Bottom: CD_IN Line-Out Line-In AUX_IN MODEM_IN CODEC Aureal Vortex 8810 (optional) DESKPOWER 2000 Mainboard Power Supply Intel chipset (GMCH) SDRAM SDRAM PCI SLOT 1 PCI SLOT 2 JMDM1 PCI SLOT 3 JWOL1 JBAT1 BATT... -
Page 21: Quick Reference For Jumpers & Connectors
1.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS Table 1-1 I/O Ports Connector USB port. IDE1 For Primary IDE port. IDE2 For Secondary IDE port. PS/2 For PS/2 Keyboard / Mouse port. For Floppy port. COMA For Serial port1 (COM A). COMB For Serial port2 (COM B). -
Page 22: Case Connector: Jfp1
CASE CONNECTOR: JFP1 The Keylock, Power Switch, Reset Switch, Power LED, Speaker, and HDD LED are all connected to the JFP1 connector block. Reset Switch Dual Speaker Color Power LED Buzzer (short pin) Keylock JFP1 Power Switch Single Color... -
Page 23: Power Switch
1.4.1 Power Switch Connect to a 2-pin push button switch. This switch has the same feature with JRMS1. 1.4.2 Reset Switch Reset switch is used to reboot the system rather than turning the power ON/OFF. Avoid rebooting while the HDD LED is lit. You can connect the Reset switch from the system case to this pin. -
Page 24: Clear Cmos Jumper: Jbat1/J26
CLEAR CMOS JUMPER: JBAT1/J26 A battery must be used to retain the mainboard configuration in CMOS RAM. Short 1-2 pins of JBAT1/J26 to store the CMOS data. Keep Data Note: You can clear CMOS by shorting 2-3 pin, while the system is off. Then, return to 1-2 pin position. -
Page 25: Bios Flash Jumper: Jp3
1.5.1 BIOS FLASH JUMPER: JP3 This jumper is used to locked/unlocked BIOS Flash. This Jumper should be unlock when flashing/programming the BIOS. BIOS Flash Unlocked BIOS Flash Locked... -
Page 26: Installation Precautions
INSTALLATION PRECAUTIONS Before you install any system component, we recommend that you read the following sections. These sections contain important ESD precautions, pre- and post installation instructions. 1.6.1 ESD PRECAUTIONS Electrostatic discharge (ESD) can damage your processor, disk drives, expansion boards, and other components. -
Page 27: Post-Installation Instructions
Do not attempt the procedures described in the following section unless you are a qualified service technician. 1.6.3 POST-INSTALLATION INSTRUCTIONS Obser ve the following after installing a system component: 1. See to it that the components are installed according to the step-by-step instructions in their respective sections. -
Page 28: Hardware Installation
HARDWARE INSTALLATION 1.7.1 CENTRAL PROCESSING UNIT: CPU The mainboard operates with Intel ® Celeron TM processor. The mainboard uses a CPU socket called Socket 370 for easy CPU installation. The CPUshould always have a Heat Sink and a cooling fan attached to prevent overheating. 1.7.2 CPU INSTALLATION PROCEDURES 1. -
Page 29: Cpu Core Speed Derivation Procedure
1.7.3 CPU CORE SPEED DERIVATION PROCEDURE The mainboard CPU Bus Frequency can be set through BIOS setup Default setting enables auto detection of CPU speed. 1.7.4 OVERCLOCKING JUMPER: J2 Overclocking is operating a CPU/Processor beyond its specified frequency. J2 jumper is used for overclocking. Function Short Automatically detect CPU Bus Frequency... -
Page 30: Fan Power Connector: Cpufan
1.7.5 FAN POWER CONNECTOR: CPUFAN This connector support system cooling fan with + 12V. It supports three pin head connector. When connecting the wire to the connector, always take note that the red wire is the positive and should be connected to the +12V, the black wire is Ground and should be connected to GND. -
Page 31: Memory Installation
MEMORY INSTALLATION 1.8.1 MEMORY BANK CONFIGURATION The mainboard supports a maximum memory size of 256MB(64-bit technology) or 512MB(128-bit technology for SDRAM: It provides two 168-pin unbuffered DIMMs (Double In-Line Memory Module) sockets. It supports 8 MB to 128 Mbytes DIMM memory module. -
Page 32: Memory Installation Procedures
1.8.2 MEMORY INSTALLATION PROCEDURES A. How to install a DIMM Module Single Sided DIMM Double Sided DIMM 1. The DIMM slot has 2 Notch Keys “VOLT and DRAM”, so the DIMM memory module can only fit in one direction. 2. Insert the DIMM memory module vertically into the DIMM slot. Then push it in. DRAM VOLT 3. -
Page 33: Memory Population Rules
1.8.3 MEMORY POPULATION RULES 1. Suppor ts only SDRAM DIMM. 2. To operate properly, at least one 168-pin DIMM module must be in-stalled. 3. This mainboard suppor ts Table Free memory, so memory can be installed on DIMM1 or DIMM 2 in any order. 4. -
Page 34: Power Saving Switch Connector: Jgs1
POWER SAVING SWITCH CONNECTOR: JGS1 Attach a power saving switch to JGS1. When the switch is pressed, the system immediately goes into suspend mode. Press any key and the system wakes up. JGS1... -
Page 35: Power Saving Led Connector: Jgl1
1.9.1 POWER SAVING LED CONNECTOR: JGL1 JGL1 can be connected with an LED. There are two types of LED that you can use: 3-pin LED or 2-pin LED(ACPI request). When the 2-pin LED is connected to JGL1, the light will turn green, when system is On. During sleep mode, the 2-pin LED will change color from Green to Orange. -
Page 36: Onboard Audio Enabled/Disabled Jumper: Jp4
1.10 ONBOARD AUDIO ENABLED/DISABLED JUMPER: JP4 This jumper is used to Enabled/Disabled the onboard audio. Enabled Disabled... -
Page 37: Modem Wake Up Connector: Jmdm1
1.11 MODEM WAKE UP CONNECTOR: JMDM1 The JMDM1 connector is for used with Modem add-on card that supports the Modem Wake Up function. JMDM1 Note: Modem wake-up signal is active “low”. Note: To be able to use this function, you need a power supply that provide enough power for this feature. -
Page 38: Modem-In: J6
1.12 MODEM-IN: J6 The connector is for Modem with internal voice connector. SPK IN GND MIC OUT Modem_In SPK_IN is connected to the Modem Speaker Out connector. MIC_OUT is connected to the Modem Microphone In connector. -
Page 39: Aux Line In Connector: J5
1.13 AUX LINE IN CONNECTOR: J5 This connector is used for DVD Add on Card with Line In connector. LGND R AUX_IN... -
Page 40: Cd-In Connector: J8
1.14 CD-IN CONNECTOR: J8 This connector is for CD-ROM audio connector. LGND R CD_In... -
Page 41: Expansion Cards
1.15 EXPANSION CARDS 1.15.1 INSTALLING A PCI CARD To install a PCI card: Locate the PCI slot(s) on the slot board. Remove the bracket on the housing opposite to the empty PCI slot. Insert a PCI card into the slot. Make sure that the card is properly seated. Secure the card to the housing with a screw. -
Page 43: Chapter 2 Award ® Bios Setup
® AWARD BIOS SETUP ® Award BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed RAM (CMOS RAM), so that it retains the Setup information when the power is turned off. -
Page 44: Getting Help
GETTING HELP 2.2.1. MAIN MENU The on-line description of the highlighted setup function is displayed at the bottom of the screen. 2.2.2. STATUS PAGE SETUP MENU / OPTION PAGE SETUP MENU Press F1 to pop up a small help window that describes the appropri-ate keys to use and the possible selections for the highlighted item. - Page 45 • Advanced Chipset Features Use this menu to change the values in the chipset registers and optimize your system’s performance. • Integrated Peripherals Use this menu to specify your settings for integrated peripherals. • Power Management Setup Use this menu to specify your settings for power management. •...
-
Page 46: Standard Cmos Setup
STANDARD CMOS SETUP The items in Standard CMOS Setup Menu are divided into 10 catego-ries. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. - Page 47 • PrimaryMaster/PrimarySlave SecondaryMaster/Secondary Slave Press PgUp/<+> or PgDn/<-> to select Manual, None, Auto type. Note that the specifications of your drive must match with the drive table. The hard disk will not work properly if you enter improper information for this category. If your hard disk drive type is not matched or listed, you can use Manual to define your own drive type manually.
-
Page 48: Advanced Bios Features
ADVANCED BIOS FEATURES CMOS Setup Utility - Copyright(C) 1984-1999 Award Software Anti-Virus Protection CPU Internal Cache External Cache CPU L2 Cache ECC Checking Quick Power On Self Test First Boot device Second Boot device Third Boot device Boot other device Swap Floppy Drive Boot Up Floppy Seek Boot Up Numlock Status... - Page 49 • External Cache Choose Enabled or Disabled. This option enables the level 2 cache memory. • CPU L2 Cache ECC Checking Choose Enabled or Disabled. This option enables the level 2 cache memory ECC(error check correction). • Quick Power On Self Test This category speeds up Power On Self Test (POST) after you power on the computer.
- Page 50 • Typematic Rate Setting Key strokes repeat at a rate determined by the keyboard controller. When enabled, the typematic rate and typematic delay can be selected. The settings are: Enabled/Disabled. • Typematic Rate (Chars/Sec) Sets the number of times a second to repeat a key stroke when you hold the key down.
-
Page 51: Advanced Chipset Features
ADVANCED CHIPSET FEATURES The Advanced Chipset Features Setup option is used to change the values of the chipset registers. These registers control most of the system options in the computer. Choose the “ADVANCED CHIPSET FEATURES” from the Main Menu and the following screen will appear. - Page 52 • SDRAM CAS latency Time When synchronous DRAM is installed, the number of clock cycles of CAS latency depends on the DRAM timing. The settings are: 2 and 3. • SDRAM Cycle Time Tras/Trc Select the number of SCLKs for an access cycle. The settings are: 5/7 and 6/8.
- Page 53 • Delayed Transaction The chipset has an embedded 32-bit posted write buffer to support delay transactions cycles. Select Enabled to support compliance with PCI specification version 2.1. The settings are: Enabled and Disabled. • On-Chip Video Window Size Select the on-chip video window size for VGA driver use. The settings are: 32MB, 64MB, Disabled.
-
Page 54: Integrated Peripherals
INTEGRATED PERIPHERALS CMOS Setup Utility - Copyright(C) 1984-1999 Award Software OnChip Primary PCI IDE OnChip Secondary PCI IDE IDE Primary Master PIO IDE Primary Slave PIO IDE Secondary Master PIO IDE Secondary Slave PIO IDE Primary Master UDMA IDE Primary Slave UDMA IDE Secondary Master UDMA IDE Secondary Slave UDMA USB Controller... - Page 55 • OnChip Primary/Secondary PCI IDE The integrated peripheral controller contains an IDE interface with support for two IDE channels. Select Enabled to activate each channel separately. The settings are: Enabled and Disabled. • IDE Primary/Secondary Master/Slave PIO The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4) for each of the four IDE devices that the onboard IDE inter face supports.
- Page 56 • IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read/write. If your IDE hard drive supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read/writes per sector the drive can support.
- Page 57 • Onboard Parallel Mode SPP : Standard Parallel Port EPP : Enhanced Parallel Port ECP : Extended Capability Port SPP/EPP/ECP/ To operate the onboard parallel port as Standard Parallel Port only, choose “SPP.” To operate the ECP+EPP onboard parallel port in the EPP modes simultaneously, choose “EPP.”...
-
Page 58: Power Management Setup
POWER MANAGEMENT SETUP The Power Management Setup allows you to configure you system to most effectively save energy while operating in a manner consistent with your own style of computer use. CMOS Setup Utility - Copyright(C) 1984-1999 Award Software Power Management Video Off Method Video Off In Suspend Suspend Type... - Page 59 • Power Management This category allows you to select the type (or degree) of power saving and is directly related to the following modes: 1. Suspend Mode 2. HDD Power Down There are three selections for Power Management, two of which have fixed mode settings.
- Page 60 • Suspend Mode When enabled and after the set time of system inactivity, all devices except the CPU will be shut off. The settings are: 1/2/4/8/12/20/30/40 Min, 1 Hour, and Disabled. • HDD Power Down When enabled and after the set time of system inactivity, the hard disk drive will be powered down while all other devices remain active.
-
Page 61: Reload Global Timer Events
PCI PIRQ[A-D] # PNP/PCI CONFIGURATION SETUP This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components. - Page 62 • Reset Configuration Data Normally, you leave this field Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system can not boot.
-
Page 63: Frequency/Voltage Control
2.10 FREQUENCY/VOLTAGE CONTROL This section is for setting CPU Frequency/Voltage Control. CMOS Setup Utility - Copyright(C) 1984-1999 Award Software Auto Detect DIMM/PCI Clk CPU Clock/Spread Spectrum CPU Ratio ↑ ↓ → ←:Move Enter:Select +/-/PU/PD:Value F10:Save F5:Previous Values Figure 2-9: Frequency/Voltage Control Menu •... -
Page 64: Load Fail-Safe/Optimized Defaults
2.11 LOAD FAIL-SAFE/OPTIMIZED DEFAULTS • Load Fail-Safe Defaults When you press <Enter> on this item, you get a confirmation dialog box with a message similar to: Load Fail-Safe Defaults (Y/N) ? N Pressing ‘Y’ loads the BIOS default values for the most stable, minimal- performance system operations. -
Page 65: Set Supervisor/User Password
2.12 SET SUPERVISOR/USER PASSWORD You can set either supervisor or user password, or both of them. The differences are: Supervisor password : can enter and change the options of the setup User password : ENTER PASSWORD: Type the password, up to eight characters in length, and press <Enter>. The password typed now will clear any previously entered password from CMOS memory. - Page 66 Fujitsu PC (Asia) Pte Ltd 200 Pandan Loop #05-03 Pantech 21 The Computer Centre Singapore 128388 Tel: 65-776 0688 Fax: 65-776 0788 Fujitsu PC (Asia) Pte Ltd (Malaysia Branch) 8th Floor Wisma Damansara Jalan Semantan 50490 Kuala Lumpur Malaysia Tel:...
