Packing List
Before first using the 10BASE-T LAN adapter, check that the package contains the
following components:
• 10BASE-T LAN adapter
• IF cable
Appearance and names of parts
Figure 1.1 illustrates the 10BASE-T LAN adapter. For details of the necessary connections, see
Chapter 2, "Connections."
2
1
1
LAN connector
LAN
LAN ADAPTOR
IF connector
Figure 1.1 10BASE-T LAN adapter
10BASE-T
COM PORT
