   Summary of Contents for D-Link DVX-2000MS-10P - VoiceCenter IP Phone Sys 10P

  • Page 2

    Note: Using a power supply with a different voltage rating than the ones included will cause damage and void the warranty for this product. If any of the above items are missing, please contact your reseller. D-Link VoiceCenter Quick Install Guide...

  • Page 3

    Ethernet cable to a Local Area Network via switch or hub. The LAN LED will light up to indicate proper connection. When you have connected the DVX-2000MS to your network, it should look like the diagram below: D-Link VoiceCenter Quick Install Guide...

  • Page 4

    Phone and connect the other end of the Ethernet cable to your Local Area Network using a hub or switch. Repeats steps for additional DPH-125MS IP Phones. When you have connected the IP Phones to your network it should look like the diagram below. D-Link VoiceCenter Quick Install Guide...

  • Page 5

    Connect the phone cable to an available PSTN (FXO) Port on the back of the gateway and connect the other end to a phone jack. When you have made all the connections to your network, it should look like the diagram below: D-Link VoiceCenter Quick Install Guide...

  • Page 6

    Response Point Administrator only operates with ® ™ Windows XP SP2 or Windows Vista ® ™ When the autorun screen appears, select Install Microsoft Response Point Administrator and click Next to continue. Click Next to continue. D-Link VoiceCenter Quick Install Guide...

  • Page 7

    Accept the License Agreement and click Next to continue. Click Install to begin the installation. Please wait while the InstallShield wizard installs Microsoft Response ® Point Administrator. ™ Installation is complete, click Finish to exit the wizard. D-Link VoiceCenter Quick Install Guide...

  • Page 8

    Administrator program is running, is not connected properly to the LAN. Make sure all cables and power cords are connected. Another potential problem is that the DVX-2000MS base unit is not turned Note: If a Security Alert dialog box comes up, click Unblock. D-Link VoiceCenter Quick Install Guide...

  • Page 9

    Connect. Note: It’s recommended that you change this password after logging in for security purposes. You have successfully logged onto the DVX-2000MS base unit. You may now configure your IP Phones and Gateway. D-Link VoiceCenter Quick Install Guide...

  • Page 10

    Click the Phone System tab at the top of the screen if necessary. In the Tasks panel, under Phones, click Add Phone to launch the Configure Phone Wizard. Select the check box confirming the IP Phone is connected and plugged in. Click Next to continue. D-Link VoiceCenter Quick Install Guide...

  • Page 11

    Select one of the D-Link DPH-125MS IP Phones you just connected and click Next to continue. For this step, you will add a new user and assign that user to the phone you just selected. Click Assign User to open the New User screen.

  • Page 12

    OK to continue. You have now assigned the person’s name to Line 1 with the extension number you specified. You can assign up to 3 additional users to this phone or click Next to continue. D-Link VoiceCenter Quick Install Guide...

  • Page 13

    The owner and phone name have automatically been created for you. Click Finish to continue. The IP Phone has been successfully added to the phone system. Click Close to exit the configuration wizard. Repeat instructions on pages 10 through 13 to add additional phones. D-Link VoiceCenter Quick Install Guide...

  • Page 14

    Click the Phone System tab at the top of the screen if necessary. In the Tasks panel, under Phone Service, click Add Phone Service to launch the Configure Phone Service Wizard. Select the check box confirming the gateway is connected and plugged in. Click Next to continue. D-Link VoiceCenter Quick Install Guide...

  • Page 15

    Select the D-Link DVG-3104MS Gateway you just connected and click Next to continue. Select the This Port Is Active check box. Enter in a phone number or name associated with this line in the Description box. Click Next to continue.

  • Page 16

    Response Point Assistant only operates with ® ™ Windows XP SP2 or Windows Vista ® ™ When the autorun screen appears, select Install Microsoft Response Point Assistant and click Next to continue. Click Next to continue. D-Link VoiceCenter Quick Install Guide...

  • Page 17

    Assistant. ™ Installation is complete, click Finish to exit the wizard. Now take the VoiceCenter CD to other computers, where DPH-125MS IP Phones are located and install Microsoft Response Point Assistant on them as well. D-Link VoiceCenter Quick Install Guide...

  • Page 18

    In the Password box, type the password of the user. The default password is 9999. Click Log On to logon to Microsoft Response Point Assistant. For more information on using Microsoft Response Point Assistant, see the VoiceCenter User Manual. ™ D-Link VoiceCenter Quick Install Guide...

  • Page 19

    If the phones did not work, the likely cause is a loose connection. Make sure all cables and cords are properly seated into their respective ports, jacks, and outlets. Please see the VoiceCenter user manual for more information. D-Link VoiceCenter Quick Install Guide...

  • Page 20

    Version 1.2 October 16, 2008 ©00 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, the D-Link logo, and the VoiceCenter logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States and/or other countries. Microsoft Response Point is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.
