TROUBLESHOOTING continued
UNDERSTANDING THE INDICATORS
Your DFE-670TXD PC Card has indicator lights that can give you
information about your network traffic and help you determine
problems when troubleshooting.
The DFE-670TXD PC Card has two LED indicators listed
under LINK Activity:
1.
100 Indicator: indicates data transmittal rate is at a fast
2.
10 Indicator: indicates data transmittal rate is at
100Mbps
100Mbps.
10Mbps.
10Mbps
5
Link Activity
